Manufactured by (LWYE) for ROOMS TO GO
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts. Which may have come loose inside the carton during shipment. Identify and count all parts and
compare with the hardware list below :
No.
Hardware List
Parts List
B
C
* Mirror Back Support Pack with Mirror
Notes :
* All JCBC with Capture are pre-install onto the mirror bracket
* Hardware pack in carton - SKU # 32247315 / 32247339
ASSEMBLY INSTRUCTIONS
LWYE 4731 / 4733 - 121 MIRROR
1
A
B
A
SKU # 32247315 / 32247339
Description
M4 ALLEN WRENCH
Description
DRESSER
MIRROR
MIRROR BACK
SUPPORT
Page 1 of 2
Version 1.0 5/2024
Dimension
4 x 65MM
C
HARDWARE PACK
WRAP AT MIRROR
BACK SUPPORT
Qty
1 PC
Qty
1 PC
1 PC
2 PCS
Advertisement
Related Manuals for ROOMS TO GO LWYE 4731
Summary of Contents for ROOMS TO GO LWYE 4731
- Page 1 Page 1 of 2 ASSEMBLY INSTRUCTIONS LWYE 4731 / 4733 - 121 MIRROR SKU # 32247315 / 32247339 Version 1.0 5/2024 Manufactured by (LWYE) for ROOMS TO GO Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts.
- Page 2 Page 2 of 2 ASSEMBLY STEP STEP 1 : Assembly mirror (B) and mirror back support (C) to the dresser (A). Hardware List Description M4 ALLEN WRENCH 1 PC TOP ARROW BACK OF THE MIRROR BACK OF THE DRESSER...
