5 DRAWER CHEST
Important:
Be sure to check all packing material carefully for small parts which may come loose inside carton
during shipment. Separate, identify and count all parts and metal hardware.
Compare with parts list and hardware illustrations to be sure all parts are present. If any part(s) are missing or
damage, contact your dealers customer services deparment. For efficient and fast service, please indicate
the model number and the parts needed.
ATTENTION:
Some lettered parts listed on the instruction sheets may not be in the parts bag, they
may already be assembled.
TOOLS REQUIRED
(Not included)
Phillips Screwdriver
Pull
Part No. HBJ-01-03690
5 Pcs
INSTALLED
WARNING INSTALL FURNITURE TIPPING RESTRAINT KIT
Remove pull from interior
of the drawers
ASSEMBLY INSTRUCTIONS
MODEL No.
HARDWARE:
Bolt 8-32 x 3/4" Zinc
Part No.HCPP-03
10 Pcs
INSTALLED
STEP 1
Then put pull facing outside
LIN50-216 / 32621600
ANTI TIP
Part No.HB-488
1 Pc
STEP 2
PAGE 1 OF 2
