Manufactured for Rooms To Go
Caution: Please read instructions thoroughly before unpacking assembly parts. Sharp,
exposed staple tips can cause injury, therefore, for your protection, please remove any
exposed staple used in packing
1. We recommend that you should assemble this product with the assistance of another
person; this will make assembly easier, and will help to eliminate damage to the product or
injury to person during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose
inside the carton during shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps
to assemble your newly purchased product correctly and efficiently.
PART LISTS
STT
DESC
1
CHAIR BACK
2
SEAT FRAME
CHAIR LEG
3
(LEFT)
CHAIR LEG
4
(RIGHT)
SIDE STRETCHER
5
(LEFT)
SIDE STRETCHER
6
(RIGHT)
SCREW DRIVER NEEDED BUT NOT INCLUDED ON THE HARDWARE POUCH
This product is manufactured by LFST for
ASSEMBLY INSTRUCTIONS
LFST
9619-4 SIDE CHAIR
OUTLOOK
Q'TY
1pc
1pc
1pc
1pc
1pc
1pc
PAGE: 1 OF 2
SKU: 42496198
HARDWARE LISTS
STT
OUTLOOK
Ø1/4" x 18 x 70 mm L BOLT
Ø1/4" x 13 mm
A
SPRING WASHER
Ø1/4" x 19 mm x 2mm
LOCK WASHER
Ø1/4" x 18 x 45 mm L BOLT
Ø1/4" x 13 mm
B
SPRING WASHER
Ø1/4" x 19 mm x 2mm
LOCK WASHER
4mm ALLEN WRENCH
C
M4*45mm WOOD SCREW
D
SIZE
Q'TY
8pcs
8pcs
8pcs
2pcs
2pcs
2pcs
2pcs
4pcs
