MX-962-2111
Manual de instrucciones
Instruction manual
Manuel d'instructions
Gebrauchsanweisungen
Manual de instruções
es
en
fr
de
pt
Advertisement
Table of Contents
Related Manuals for ENAR DINGO
Summary of Contents for ENAR DINGO
- Page 1 MOTOR DINGO - TRANSMISIONES Y AGUJAS DINGO MOTOR - FLEXIBLE SHAFT AND POKERS MOTEUR DINGO - TRANSMISSIONS ET AIGUILLES DINGO MOTOR - ÜBERSETZUNGSGETRIEBE UND LANZEN MOTOR DINGO – TRANSMISSÕES E AGULHAS Manual de instrucciones Instruction manual Manuel d'instructions Gebrauchsanweisungen Manual de instruções...
- Page 2 13 INSTRUCTIONS TO ORDER SPARE PARTS 13.1 INSTRUCTIONS TO ORDER SPARE PARTS 13.2 INSTRUCTIONS TO REQUEST WARRANTIES 14 RECOMENDATIONS OF USE OF CONCRETE VIBRATOR DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58 TDX1m, TDX1-5m, TDX2m, TDX3m, TDX4m, TDX5m, TDX6m...
- Page 3 The effective longevity of the equipment will increase if the manual instructions are followed. We will glad to help you with any comments or suggestions in reference to our equipment. DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58...
- Page 4 CONECTION TYPE........…LEFT THREAD BELT HOOK POSITION SWITCH INPUT CABLE LEFT THREADS INPUT AIR COVER WITH FILTER OUTPUT AIR COVERS DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58 TDX1m, TDX1-5m, TDX2m, TDX3m, TDX4m, TDX5m, TDX6m...
- Page 5 CHARACTERISTICS OF FLEXIBLE SHAFT AND POKERS The flexible shaft connected to the DINGO power unit sends the movement to an eccentric placed in the poker, and so it is produced the vibration for the compacting of the concrete. CENTRÍFUGAL Sound Sound DIÁMETER...
- Page 6 D) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58...
-
Page 7: Specific Safety Rules
DO NOT OPERATE in the motor shaft when this is working and without transmission. DON NOT WORK with transmission or poker in bad conditions, the motor overheats. DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58... -
Page 8: Usage Conditions
FLEXIBLE SHAFT LENGTH: UP TO 6 MTS (TDX 1M, TDX 1,5M, TDX 2M, TDX3M, TDX 4M, TDX5M AND TDX6M) VIBRATOR DIAMETER: DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58 TDX1m, TDX1-5m, TDX2m, TDX3m, TDX4m, TDX5m, TDX6m... -
Page 9: Earth Connection
Allowing to interchange of a poker to other quickly and without a special tool. The model AX25, AX32 due to the diameter need a special transmission. (TDXE). DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58... - Page 10 (96203) and replace with another new one. Then mount the grating, firstly inserting the bottom into its guide and then the upper part whilst pressing the “PRESS” indications. DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58...
- Page 11 9.-Every 12 months or more frequently, depending on the usage conditions. It is recommended an inspection be done by an authorized dealer. 9.1 STORAGE When the DINGO motor has not been used for long periods of time, it should always be stored in a clean, dry, stable and protected area. 9.2 TRANSPORTATION When transporting by vehicles, ensure the DINGO motor is safe against slipping, overturning and blows.
-
Page 12: Earthing Connection
2. Defective bearings 3. The rotor might be touching the stator 4. Outer housing is broken or has loose bolts DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58 TDX1m, TDX1-5m, TDX2m, TDX3m, TDX4m, TDX5m, TDX6m... -
Page 13: Instructions To Order Spare Parts
ENARCO, S.A. or not authorized by it. ENARCO, S.A., reserves the right to modify any part of this manual without prior notice. DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58 TDX1m, TDX1-5m, TDX2m, TDX3m, TDX4m, TDX5m, TDX6m... - Page 14 The concrete has to be carefully prepared to get the best effects of the vibration in terms of consistency and resistance DINGO MOTOR - FLEXIBLE SHAFT AND POKERS DINGO - AX25, AX32, AX40, AX48, AX58 TDX1m, TDX1-5m, TDX2m, TDX3m, TDX4m, TDX5m, TDX6m...
