EVA EVAstream Mounting Manual

Hide thumbs Also See for EVAstream:

Advertisement

Table of Contents

EVAstream
MOUNTING MANUAL
A step-by-step guide to mounting the EVAstream

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVAstream and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EVA EVAstream

Summary of Contents for EVA EVAstream

  • Page 1 EVAstream MOUNTING MANUAL A step-by-step guide to mounting the EVAstream...
  • Page 2 Symmetrical placement EVAstream Scan for EVAstream Spanish Mounting manual Mounting the EVAstream Mounting drawings Scan for 5.2 Remove the ribs EVAstream Italian Mounting manual 5.3 Mounting the EVAstream turbine 2 | EVAstream | Mounting manual EVAstream | Mounting manual | 3...

  • Page 3: About This Manual

    The original language of this Electrical installation manual is English. All versions of this manual in other languages are translations of Connect the EVAstream turbine to the Motor Control Unit the original manual. 6.2 Optional: EVAstream Cable connection box 6.3 Connect the ECA Control to the Motor Control Unit (MCU)
  • Page 4 Only after WARNING written approval by EVA Tech B.V. may the EVAstream be applied in any other way than Electrical shock hazard. Risk of electric shock due to incorrect mounting.
  • Page 5 3.1 EVAstream turbine 3.2 Motor Control Unit (MCU) 3.3 ECA control 3.4 On/off switch 3.5 Remote control 3.6 Antenna 3.7 EVA Experience web app 3.8 EVA LED underwater lighting 8 | EVAstream | Mounting manual EVAstream | Mounting manual | 9...
  • Page 6 3.1 + 3.2 EVAstream turbine + MCU Recreational swimmer EVAstream NEXT 175 EVAstream NEXT 225 Motor Control Unit Dimensions 284 x 90 x 82 mm (lxbxh) 290 x 105 x 91 mm (lxbxh) IP rating IP 20 IP 20 Working temperature -20°C to 32°C, dry and...
  • Page 7 3.1 + 3.2 EVAstream turbine + MCU Experienced swimmer EVAstream NEXT 275 EVAstream NEXT 450 Motor Control Unit Dimensions 380 x 90 x 96 mm (lxbxh) 360 x 182 x 117 mm (lxbxh) IP rating IP 20 IP 20 Working temperature -20°C to 32°C, dry and...
  • Page 8 Cable length 8 meter, extendable to 8 meter, extendable to EVAstream was built for speed and safety. Safety measures were taken to ensure max. 25 meters max. 25 meters safety of fingers, toes and also hair. EVAstream complies to safety standards DIN...
  • Page 9 Lighting control output Not available DMX - EVA DMX - EVA Fan output 5W Not available 24 Vdc 5W 24 Vdc 5W 24 Vdc 5W (power box ventilation) 16 | EVAstream | Mounting manual EVAstream | Mounting manual | 17...

  • Page 10: General Specifications

    3.4 On/off switch 3.6 Antenna If the EVAstream is permanently connected to 230V mains, the installation must additionally be equipped with an on/off switch mounted near the swimming pool General specifications where the EVAstream is located. Frequency 433.92 MHz After use, the power must be switched off.
  • Page 11 When a turbine is not placed symmetrically in the pool, the circulation of the current is not equal on both sides of the pool. The current of the EVAstream is still just as powerful, but it creates a kind of vortex in the middle of the pool.
  • Page 12 5.1 Mounting drawings EVAstream installation niche PP Mounting depth: 250 mm below water level (centre of the turbine). • • Mount the EVAstream horizontally in the middle of the poolwall. Stainless steel: 467mm ABS: 472mm Side view Top view 22 | EVAstream | Mounting manual...
  • Page 13 EVAstream installation niche POLY - Mounting depth: 250 mm below water level (centre of the turbine). - Mount the EVAstream horizontally in the middle of the poolwall. 449mm Side view Top view 24 | EVAstream | Mounting manual EVAstream | Mounting manual | 25...
  • Page 14 2. The bracket is still adjustable The installation niche is now completely empty and ready for mounting the turbine. Make sure the bracket can be moved forwards and backwards. 26 | EVAstream | Mounting manual EVAstream | Mounting manual | 27...
  • Page 15 4. Mount the turbine to the bracket 6. Mount the adjusting plate to the niche Use the M6x10 screws. To ensure the correct horizontal position of the turbine. 28 | EVAstream | Mounting manual EVAstream | Mounting manual | 29...
  • Page 16 This was only used to ensure the correct horizontal position of the turbine. Use the M5x12 screws with a stainless steel frontplate. Use the M5x16 screws with an ABS frontplate. 30 | EVAstream | Mounting manual EVAstream | Mounting manual | 31...

  • Page 17: Electrical Installation

    Electrical installation 6.1 Connect the EVAstream turbine to the Motor Control Unit 11. Earth the installation niche The installation niche needs to be connected to the pool earthing on the top of the niche.
  • Page 18 If the cables are not long enough, they can be extended. You can extend the cable from the Turbine to the Motor Control Unit using the EVA connection box. 1. Choose your cable (flexible cable of fine copper wire stands) •...
  • Page 19 2. If the supplied cable is not long enough, a longer cable can be installed The cables need to be placed in separate conduits and the connection box closed. Important: connect plus to plus and minus to minus. 36 | EVAstream | Mounting manual EVAstream | Mounting manual | 37...
  • Page 20 6.4 Optional: Connect the EVA LED underwater lighting Power Supply Unit (PSU) to the ECA Control 3. Install the antenna to the ECA control 1. The PSU can accommodate 2, 3, or 4 underwater lights If you use the remote control, install the antenna outside the technical room for optimal range.
  • Page 21 4. Connect the DMX cable from the PSU to the ECA Control 6. Optinal: installation with more than 4 lights in the pool Use the supplied DMX cable. Link the PSU to an additional PSU using the DMX output. 40 | EVAstream | Mounting manual EVAstream | Mounting manual | 41...
  • Page 22 1. Connect to the mains If the wireless connection is too weak, a wired connection can be made by connecting a Connect the EVAstream Motor Control Unit, the ECA Control, and the EVA LED underwater UTP cable from the router to the ECA Control.

  • Page 23: Control Options

    8. DISPOSAL 7. 1 EVA Experience web app 8.1 Decommissioning Especially for the EVAstream, we have developed a complete training program for WARNING swimmers of every age and every skill level. The workouts consist of interval, sprint and endurance elements and increase in duration and intensity. Use the EVA Experience web Electrical shock hazard.
  • Page 24 Water Values EN 55032 (CISPR32) Class A, B EN 62368-1 The user of the EVAstream is responsible for providing the right conditions for an EN 60364-7-702 optimal product life cycle. To fulfil the warranty conditions, the EVAstream should only be used in basins with a water composition within the following limits: EMC Electromagnetic Compatibility •...
  • Page 25 EVA Optic De Velde 1 8064 PH Zwartsluis The Netherlands +31 (0)38 - 33 75 067 info@evaoptic.com evaoptic.com 48 | EVAstream | Mounting manual EVAstream | Mounting manual | v25.1...

This manual is also suitable for:

Evastream next 175Evastream next 225Evastream next 275Evastream next 450Evastream next 350Evastream next 550
