- Page 1 EVAstream MOUNTING MANUAL A step-by-step guide to mounting the EVAstream...
- Page 2 Symmetrical placement EVAstream Scan for Mounting the EVAstream EVAstream Spanish Mounting manual Mounting drawings 5.2 Remove the ribs Scan for 5.3 Mounting the EVAstream turbine EVAstream Italian Mounting manual 2 | EVAstream | Mounting manual EVAstream | Mounting manual | 3...
-
Page 3: About This Manual
Electrical installation This manual is meant for qualified installers. Read and understand the information Connect the EVAstream turbine to the Motor Control Unit in this manual before mounting and using this product. The original language of this 6.2 Optional: EVAstream Cable connection box manual is English. - Page 4 Only after WARNING written approval by EVA Tech B.V. may the EVAstream be applied in any other way than Electrical shock hazard. Risk of electric shock due to incorrect mounting.
- Page 5 Overview EVAstream turbine 3.2 Motor Control Unit (MCU) 3.3 On/off switch 3.4 Remote control Optional products: 3.5 Antenna 3.6 EVA Experience web app 3.7 EVA LED underwater lighting 8 | EVAstream | Mounting manual EVAstream | Mounting manual | 9...
-
Page 6: General Specifications
EVAstream PRO EVAstream MAX EN61000-4-2/3/4/5/6/8/11, EN55024, EN61204-3, EN61000-6-2, BSMI CNS13438. The EVAstream is a counter-current machine. Water suction takes place through the grids around the machine. Always make sure that the suction parts are completely free 3.2 Motor Control Unit (MCU) of obstacles. -
Page 7: Working Temperature
General specifications 3.3 On/off switch Frequency 433.92 MHz If the EVAstream is permanently connected to 230V mains, the installation must Weight 426 grams additionally be equipped with an on/off switch mounted near the swimming pool where the EVAstream is located. - Page 8 When a turbine is not placed symmetrically in the pool, the circulation of the current is not equal on both sides of the pool. The current of the EVAstream is still just as powerful, but it creates a kind of vortex in the middle of the pool.
- Page 9 5.1 Mounting drawings EVAstream installation niche PP Mounting depth: 250 mm below water level (centre of the turbine). • • Mount the EVAstream horizontally in the middle of the poolwall. Stainless steel: 467mm ABS: 472mm Side view Top view 16 | EVAstream | Mounting manual...
- Page 10 EVAstream installation niche POLY - Mounting depth: 250 mm below water level (centre of the turbine). - Mount the EVAstream horizontally in the middle of the poolwall. 449mm Side view Top view 18 | EVAstream | Mounting manual EVAstream | Mounting manual | 19...
- Page 11 2. The bracket is still adjustable The installation niche is now completely empty and ready for mounting the turbine. Make sure the bracket can be moved forwards and backwards. 20 | EVAstream | Mounting manual EVAstream | Mounting manual | 21...
- Page 12 4. Mount the turbine to the bracket 6. Mount the adjusting plate to the niche Use the M6x10 screws. To ensure the correct horizontal position of the turbine. 22 | EVAstream | Mounting manual EVAstream | Mounting manual | 23...
- Page 13 This was only used to ensure the correct horizontal position of the turbine. Use the M5x12 screws with a stainless steel frontplate. Use the M5x16 screws with an ABS frontplate. 24 | EVAstream | Mounting manual EVAstream | Mounting manual | 25...
-
Page 14: Electrical Installation
Electrical installation 6.1 Connect the EVAstream turbine to the Motor Control Unit 11. Earth the installation niche The installation niche needs to be connected to the pool earthing on the top of the niche. - Page 15 30 meters • (total maximal 35 meters including the existing cable). Connect the cables from the EVAstream Turbine to the Motor Control Unit: • Make sure the cables are properly finished. Dismantling length should be 16 mm.
- Page 16 Connect an on/off button (power switch) to the socket and install near to the pool. 4. Mount the conduits The cables need to be placed in separate conduits and the connection box closed. 30 | EVAstream | Mounting manual EVAstream | Mounting manual | 31...
- Page 17 6.4 The EVAstream is now ready to use 6.5 Optional: connect the antenna to the Motor Control Unit The remote control is now automatically connected to the EVAStream. WARNING The EVA Remote control has the following functions: Electrical shock hazard. Risk of electric shock and injury. The product must be installed by a certified electrician.
-
Page 18: Control Options
To set up the EVA Experience web app, watch the video EVA Piezo (optional): With the EVA Piezo, the swimming machine can be controlled from within the pool. For instructions on how to install the EVA Piezo, scan the QR code... - Page 19 EN 61000-4-8 EN 61000-4-11 EN 55024 EN 615204-3 EN 61000-6-2 Specific standards EN 13451-1 EN 13451-3 EN 16582-1 EN 16582-2 EN 16582-3 EN 16713-2 EN 15288-1 EN 60204-1 36 | EVAstream | Mounting manual EVAstream | Mounting manual | 37...
- Page 20 ATTACHMENT 3 Water Values The user of the EVAstream is responsible for providing the right conditions for an optimal product life cycle. To fulfil the warranty conditions, the EVAstream should only be used in basins with a water composition within the following limits: •...
- Page 21 EVA Optic De Velde 1 8064 PH Zwartsluis The Netherlands +31 (0)38 - 33 75 067 info@evaoptic.com evaoptic.com 40 | EVAstream | Mounting manual EVAstream | Mounting manual | v24.1...
