Summary of Contents for National Instruments 9344

  • Page 1 NI NI-9344 C Series User Interface Module Limited Availability New From Surplus Stock Open Web Page https://www.artisantg.com/83910-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
  • Page 2 GETTING STARTED GUIDE NI 9344 4 Switch Input/4 LED Output...
  • Page 3: Safety Guidelines

    This document explains how to connect to the NI 9344. Before you begin, complete the software and Note hardware installation procedures in your chassis documentation. The guidelines in this document are specific to Note the NI 9344. The other components in the system might not meet the same safety ratings.
  • Page 4: Safety Guidelines For Hazardous Locations

    Safety Guidelines for Hazardous Locations The NI 9344 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4 and Ex nA IIC T4 hazardous locations; and nonhazardous locations only.
  • Page 5 Zone 2 hazardous locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI 9344 in Gas Group IIC hazardous locations, you must use the device in an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
  • Page 6: Electromagnetic Compatibility Guidelines

    Furthermore, any changes or modifications to the product not expressly approved by National Instruments could void your authority to operate it under your local regulatory rules. NI 9344 Getting Started Guide | © National Instruments | 5...
  • Page 7: Special Conditions For Marine Applications

    In addition, take precautions when designing, selecting, and installing measurement probes and cables to ensure that the desired EMC performance is attained. 6 | ni.com | NI 9344 Getting Started Guide...
  • Page 8: Preparing The Environment

    Preparing the Environment Ensure that the environment in which you are using the NI 9344 meets the following specifications. Operating temperature -40 °C to 70 °C (IEC 60068-2-1, IEC 60068-2-2) Operating humidity 10% RH to 90% RH, (IEC 60068-2-78) noncondensing...
  • Page 9 NI 9344 Front Panel User LEDs User Switch 0 User Switch 1 User Switch 2 User Switch 3 8 | ni.com | NI 9344 Getting Started Guide...
  • Page 10 Table 1. Front Panel Descriptions Front Panel Description User LEDs User-programmable LEDs User Switch User-programmable switch NI 9344 LEDs 1. User LED0 3. User LED2 2. User LED1 4. User LED3 NI 9344 Getting Started Guide | © National Instruments | 9...
  • Page 11 Table 2. LED Indicators LED Pattern Indication Solid The channel has been programmed to be in the ON state. The channel has been programmed to be in the OFF state. 10 | ni.com | NI 9344 Getting Started Guide...
  • Page 12 User Software Vint User NI 9344 • You can program the user LEDs as indicators for your software application. • You can program the LEDs and the switches independently. NI 9344 Getting Started Guide | © National Instruments | 11...
  • Page 13: General Characteristics

    Power Requirements Power consumption from chassis Active mode 145 mW maximum Sleep mode 25 μW maximum Thermal dissipation (at 70 °C) Active mode 145 mW maximum Sleep mode 25 μW maximum 12 | ni.com | NI 9344 Getting Started Guide...
  • Page 14: Physical Characteristics

    C Series module and connectors, visit ni.com/dimensions and search by module number. Weight 150 g (5.3 oz) Safety Voltages Isolation Channel-to-channel None Channel-to-earth None ground NI 9344 Getting Started Guide | © National Instruments | 13...
  • Page 15: Hazardous Locations

    UL 61010-1, CSA 61010-1 • EN 60079-0:2012, EN 60079-15:2010 • IEC 60079-0: Ed 6, IEC 60079-15; Ed 4 • UL 60079-0; Ed 5, UL 60079-15; Ed 3 • CSA 60079-0:2011, CSA 60079-15:2012 14 | ni.com | NI 9344 Getting Started Guide...
  • Page 16: Electromagnetic Compatibility

    In the United States (per FCC 47 CFR), Class A Note equipment is intended for use in commercial, light- industrial, and heavy-industrial locations. In Europe, Canada, Australia and New Zealand (per CISPR 11) NI 9344 Getting Started Guide | © National Instruments | 15...
  • Page 17 CE Compliance This product meets the essential requirements of applicable European Directives, as follows: • 2014/35/EU; Low-Voltage Directive (safety) • 2014/30/EU; Electromagnetic Compatibility Directive (EMC) • 94/9/EC; Potentially Explosive Atmospheres (ATEX) 16 | ni.com | NI 9344 Getting Started Guide...
  • Page 18: Online Product Certification

    5 g, 10 Hz to 500 Hz 60068-2-6) Operating shock (IEC 30 g, 11 ms half sine; 50 g, 3 ms 60068-2-27) half sine; 18 shocks at 6 orientations NI 9344 Getting Started Guide | © National Instruments | 17...
  • Page 19 Ingress protection IP40 Operating humidity 10% RH to 90% RH, (IEC 60068-2-78) noncondensing Storage humidity 5% RH to 95% RH, (IEC 60068-2-78) noncondensing Pollution Degree Maximum altitude 5,000 m Indoor use only. 18 | ni.com | NI 9344 Getting Started Guide...
  • Page 20: Environmental Management

    EU Customers NI products must be disposed of according to local laws and regulations. For more information about how to recycle NI products in your region, visit ni.com/ environment/weee. NI 9344 Getting Started Guide | © National Instruments | 19...
  • Page 21: Worldwide Support And Services

    NI Factory Installation Services, repairs, extended warranty, and other services. Visit ni.com/register to register your NI product. Product registration facilitates technical support and ensures that you receive important information updates from NI. 20 | ni.com | NI 9344 Getting Started Guide...
  • Page 22 United States, visit the Worldwide Offices section of ni.com/niglobal to access the branch office websites, which provide up-to-date contact information, support phone numbers, email addresses, and current events. NI 9344 Getting Started Guide | © National Instruments | 21...
  • Page 23 U.S. Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015. © 2014—2016 National Instruments. All rights reserved. 376344C-01 Mar16...
