CALIBRATION PROCEDURE
NI 9269
This document contains the verification and adjustment procedures for the
National Instruments 9269. For more information about calibration solutions, visit
.
calibration
Contents
Software.................................................................................................................................... 1
Documentation.......................................................................................................................... 2
Test Equipment......................................................................................................................... 2
Test Conditions......................................................................................................................... 3
Initial Setup............................................................................................................................... 3
Verification............................................................................................................................... 3
Accuracy Verification....................................................................................................... 3
Adjustment................................................................................................................................ 5
Accuracy Adjustment ....................................................................................................... 5
EEPROM Update ..................................................................................................................... 6
Reverification ........................................................................................................................... 6
Accuracy Under Calibration Conditions .................................................................................. 6
Where to Go for Support .......................................................................................................... 7
Software
Calibrating the NI 9269 requires the installation of NI-DAQmx 9.6 or later on the calibration
system. You can download NI-DAQmx from
LabVIEW, LabWindows
need to install support for the application software that you intend to use.
™
™
/CVI
, ANSI C, and .NET. When you install NI-DAQmx, you only
ni.com/downloads
ni.com/
. NI-DAQmx supports
