CLEANSLATE XL ADVANCED

SPOT CLEANER

USER GUIDE

FACSC23M

Table of Contents

Need help?

Do you have a question about the CLEANSLATE XL ADVANCED and is the answer not in the manual?

Questions and answers

Summary of Contents for Hoover CLEANSLATE XL ADVANCED

Page 1 CLEANSLATE XL ADVANCED SPOT CLEANER USER GUIDE FACSC23M...
Page 2: Important Safety Information
Don’t over fill the dirty water tank to avoid blocking the air flow through the machine. • Only Hoover recommended tools, attachments, and accessories should be used with this machine. • Always remove the power from the machine before carrying out any maintenance or if storing unused for a long period of time.
Page 3 • To reduce the risk of fire and electric shock due to internal component damage, use only Hoover® cleaning solutions intended for use with this appliance. • To assist in reducing drying time, be certain the area is well ventilated.
Page 4: Grounding Instructions
• Should this occur, unplug the machine from the electrical outlet and turn off the switch. Allow the machine to cool for approximately one (1) hour before reusing. • Hoover recommends the use of a Residual Current Device rating of 30mA or less. support.vax.co.uk...
Page 5: General Information
GENERAL INFORMATION TECHNICAL SPECIFICATIONS Part Number FACSC23M Product Description Hoover CleanSlate XL Advanced Spot Cleaner Product Weight 5.5kg Clean Water Tank Capacity 2.8L Dirty Water Tank Capacity 2.2L Hose length 1.55m Cord length 6.5m Power 500W Voltage 220-240V~50Hz Subject to technical change without notice.
Page 6: Machine Overview
MACHINE OVERVIEW Carry handle On/Off button (located under handle) Clean water/solution tank Dirty water tank Wide Path tool Wide Path tool release button Clean water/solution tank handle Quick cord release hooks Hose self clean port Hose storage clip Tight Spot tool storage Hose Wide Path tool attachments: A.
Page 7: Getting Started
Not suitable for use on water sensitive flooring/surfaces. Only use with Hoover cleaning solution. Using other solutions may cause excess foaming. The clean water/solution tank should only be filled with warm water (max 40°C).
Page 8: Using Your Machine
USING YOUR MACHINE USING YOUR MACHINE FILLING THE CLEAN WATER/SOLUTION TANK IMPORTANT: The tank cap will not open when the tank is fitted to the machine. Remove the tank from the machine to fill. The water/solution tank should only be filled with warm water (max 40°C). Filling the tank with hot or boiling water will damage your cleaner.
Page 9 USING YOUR MACHINE USING THE TOOLS/ATTACHMENTS IMPORTANT: Always switch off the machine before connecting or disconnecting the hose. This machine is not to be used for grooming a pet. Selecting the right tool for the job 1. Wide Path tool A) Multi-purpose brush attachment for cleaning carpets, rugs, sofas and upholstery.
Page 10 USING YOUR MACHINE USING YOUR MACHINE USING THE WIDE PATH TOOL (1) OR 2-IN-1 TOOL (2) For spills, always pick up the Press the trigger on the hose Use the brush to agitate any Tilt the nozzle forward so the excess liquid before using to release water and solution.
Page 11: Cleaning And Maintenance
CLEANING AND MAINTENANCE EMPTYING AND CLEANING THE DIRTY WATER TANK IMPORTANT: Always switch off and unplug the machine before performing maintenance or troubleshooting checks. The dirty water tank is fitted with a float. When the dirty water tank is full, the float will shut off the suction on the machine.
Page 12: Cleaning The Hose
CLEANING AND MAINTENANCE CLEANING AND MAINTENANCE CLEANING THE HOSE IMPORTANT: Clean the hose after each use to remove any debris or water left in the hose. 40°C Lift the clean water/solution Lift to open the tank fill cap Close the tank fill cap and refit Press the tool release button tank handle and pull to remove and fill the clean water/solution...
Page 13 CLEANING AND MAINTENANCE REMOVING AND CLEANING TOOLS/ATTACHMENTS WARNING: Always switch off the machine before carrying out any maintenance or troubleshooting. Press the tool lock button and pull to remove the tool from the hose. Pull and lift the clip to remove To remove the nozzle on the the attachment from the wash wash tool, push and lift the...
Page 14 STORAGE IMPORTANT: Before storing away, always empty and rinse out the clean water/solution tank and dirty water tank and leave to air dry before refitting. Wrap the cord around the quick Push the carry handle into the downward position for storage and cord release hooks.
Page 15: Troubleshooting
TROUBLESHOOTING There is an accessory missing • Check the contents on the box. Why does the machine have no power? • The plug may not be fully pushed into the electrical socket. • The motor thermostat may have tripped. If this has happened, unplug the machine and allow the machine to cool for approximately 1 hour.
Page 16 HOOVER.COM.AU HOOVER.CO.NZ...
