2024
Commercial Gas Ranges
Models:
HKN-XRFG24O4A - 4 burner with oven
HKN-XRFG36O6A - 6 burner with oven
HKN-XRFG60O10A - 10 burner with 2 ovens
HKN-XRFG60O6G24A - 6 burner with oven and griddle
HKN-XRFG60O6GB24A - 6 burner with oven,
Please read this manual thoroughly prior to equipment set-up,
Note:
operation, and maintenance.
User Manual
HKN-XRFG60O6G24 6 burner with
griddle and broiler
www.equip.me
oven and griddle
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HURAKAN HKN-XRFG24O4A
Summary of Contents for HURAKAN HKN-XRFG24O4A
- Page 1 HKN-XRFG60O6G24 6 burner with oven and griddle Commercial Gas Ranges Models: HKN-XRFG24O4A - 4 burner with oven HKN-XRFG36O6A - 6 burner with oven HKN-XRFG60O10A - 10 burner with 2 ovens HKN-XRFG60O6G24A - 6 burner with oven and griddle HKN-XRFG60O6GB24A - 6 burner with oven,...
- Page 2 WARNINGS Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other equipment. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation and maintenance instructions thoroughly before installing or servicing this equipment.
-
Page 3: Table Of Contents
Commercial Gas Ranges Table of Contents Features & specifications Installation instructions Operating instructions and controls Regular maintenance Troubleshooting Instructions and images in this manual are only for reference and may differ from the actual product. Launch the E-Manual. www.equip.me... -
Page 4: Features & Specifications
Features & specificatios Griddle/Broil Model Style Open burner Oven 4 burners with HKN-XRFG24O4A 30,000BTU/pc*4 31,000BTU/pc oven 6 burners with HKN-XRFG36O6A 30,000BTU/pc*6 31,000BTU/pc oven HKN- 4 burners with 12" 30,000BTU/pc*4 31,000BTU/pc 20,000BTU/pc XRFG36O4G12A griddle +oven HKN- 2 burners with 24" 30,000BTU/pc*2... -
Page 5: Before Installation
Installation IMPORTANT! PLEASE READ BEFORE INSTALLATION: Before installation Installation of this device should be carried out by professional technicians. Installation of this unit must adhere to the provisions of gas safety, installation, and usage. Verify that the electrical (if required) and gas supply match the specifications on the rating plate located inside the kick panel of the unit. - Page 6 For an oven equipped with casters, use a connector complying with ANSI Z21.69/CSA 6.16 and a quick-disconnect device complying with ANSI Z21.4/CSA 6.9. Adequate means must be provided to limit the movement of the oven, not solely depending on the connector and quick disconnect device.
-
Page 7: Operating Instructions And Controls
OPERATING INSTRUCTIONS AND CONTROLS: When turning on for the first time, it may take longer to ignite due to air in the pipe. Burners: Turn on the gas supply and ignite the pilot flame with a lighter. Press the corresponding valve knob and rotate it counterclockwise to ignite the burner. Adjust the flame from Max to Min by further rotating the knob counterclockwise. -
Page 8: Regular Maintenance
Regular maintenance Cleaning: Check the machine daily and stop using it if any problems arise. Turn off all gas valves before cleaning. Clean burners and drip tray daily. Clean stainless steel surfaces with warm soapy water daily, avoiding abrasive cleaners. Avoid contact with corrosive substances on the surface.
