Acer Predator PT314-52s Lifecycle Extension Manual page 20

7. Remove nine (9) screws (G and H) securing the mainboard
G
Figure 1-21. Mainboard Removal
8. Release the mainboard (I) from the I/O connectors slots and the guide pins (J) on the
top assembly. Then remove the mainboard (G)
+
IMPORTANT:
Make sure to remove all traces of old liquid metal from the CPU before
removing the
J
Figure 1-22. Mainboard Removal
1-18
G
H
mainboard.
WEEE Annex VII Component:
Mainboard
I
(Figure 1-21).
G
G
(Figure 1-22).
J
Disassembly Procedures
