Acer Predator PT314-52s Lifecycle Extension Manual page 14

2. Disconnect the fingerprint FFC (B) from the mainboard and touchpad module
connectors (Figure
3. Disconnect the touchpad FFC (C) from the mainboard and touchpad module
connectors (Figure
Figure 1-10. Touchpad Module Removal
CAUTION:
!
Touchpad FFC (Flexible Flat Circuit) and fingerprint FFC can be damaged if
removed while the mainboard connector and the touchpad module
connector are locked.
4. Partially detach the conductive tape (D) from the touchpad module and top assembly
(Figure 1-11).
Figure 1-11. Touchpad Module Removal
1-12
1-10).
1-10).
C
D
B
Disassembly Procedures
