- Page 1 UM 6150 – Potato Digger User manual and Spare parts Edition 2025 Reviced 01.01.2025 Language Original user manual...
-
Page 2: Warranty
Warranty claims must be reported within the warranty period. The dealer must complete a claim form for each warranty case and send it to Underhaug's sales company/importer by the 10th of the month following the damage report. -
Page 3: Table Of Contents
Contents General Safety ....................pg. 4-8 Supplementary Safety .................. pg. 9-10 Technical Data………..................pg.11-12 Spare Parts ....................pg.13-23 EU Declaration of Conformity ............... pg. 24... -
Page 4: General Safety
Safety Before operating the machine windows and doors closed to reduce the Before operating, adjusting, or repairing the noise level around the driver machine, the user, repairer, and owner must Ensure proper tractor compatibility familiarize themselves with the safety instructions provided in this manual (Fig 1). The tractor’s weight must match the Be attentive and cautious when working machine’s maximum working weight. - Page 5 Think safety while working Hydraulics The tractor engine should be stopped and Be cautious when handling hydraulic the ignition key removed before performing systems. Wear eye protection and gloves. any repair work, lubrication, or other Oil released under high pressure can maintenance on the machine.
-
Page 7: Maintenance
When disconnecting the machine and Safety equipment leaving the tractor/machine Always carry first aid equipment in the Set all hydraulic functions to the neutral tractor. Follow public regulations position when disconnecting the regarding fire extinguishing equipment. machine. Lower the movable working When working with flammable materials components to the ground or set them such as hay and straw, fire extinguishing... -
Page 9: Supplementary Safety
Supplementary safety instructions for UM 6150 Potato Harvester This equipment is marked with this warning label . If the label is damaged, it must be replaced. Warning label 2935064 (fig. 1). Be cautious. Read and understand the instruction manual before using the equipment, and before adjusting and performing maintenance. - Page 10 Important! Before the machine is used, adjusted, or overhauled, it is crucial that this instruction manual is read thoroughly. This will ensure the highest level of safety and help the machine operate satisfactorily. All references to left and right directions refer to the positions of components when standing behind the machine and facing the direction of travel.
-
Page 11: Technical Data
Technical Data Type: 1-row three-point mounted storage harvester Working components: Cutter, belt, belt drive, shaker wheels Capacity: 1-4 da per hour Row spacing: 70 cm Belt width: 49.5 cm Effective belt length: 180 cm (Sole length) Weight: 300 kg Depth wheels: 4.00 x 4 Transport dimensions: 270 x 140 x 125 cm (L x W x H) -
Page 12: Safety Clutch
4.1 Top Link Length Short top link = Heavy sifting • Long top link = Light sifting (increased wear on the belt) • 4.2 Working Depth Adjusted using the hydraulic position control and depth wheels. Normal setting = as shallow as possible •... -
Page 13: Spare Parts
Efforts have been made to replicate the original parts as closely as possible. However, Underhaug AS reserves the right that some new parts may not fit older models (UM-2000, 550) of Underhaug Potato Harvesters, as production of these models was discontinued in 2002. - Page 14 Fig. 1: Frame...
- Page 15 SPARE PARTS UM 6150 – Fig. 1: Frame Ref. Art. No. Item Description UH150001 Frame UH150002 Side plate left UH150003 Side plate right UH150004 Front frame UH150005 Diagonal stay UH150007 Parking foot UH231414 Safety pin UH150033 Fastener UH150035 Bearing clamp...
- Page 16 Fig. 2: Belt...
-
Page 17: Item Description
SPARE PARTS UM 6150 – Fig. 2: Belt Ref. Art. No. Item Description UH281120 Belt cpl. UM6150 UH281304 Belt rod UH281303 Locking rod 3-13 UH281137 Belt roller cpl. UH281076 Belt roller 868552 Locking ring 472-52x2 UH281633 Cover UH281456 Axle 010755... - Page 18 Fig. 3: Operation...
- Page 19 SPARE PARTS UM 6150 – Fig. 3: Operation Ref. Art. No. Item Description UH150014 UH150012 Spline shaft UH866540 Bushing 8752-10x40A UH150015 Clamp plate for protective cover UH150013 Funnel UH150035 Bearing bracket UH150037 Bearing housing 870727 Ball bearing 6205-2 RS UH150009...
- Page 20 Fig. 4: Movable Strip...
- Page 21 SPARE PARTS UM 6150 – Fig. 4: Movable Strip Ref. Art. No. Item Description 1-40 UH150040 Movable strip cpl. 1-17 UH150060 Crank cpl. UH281002 Crankshaft bearing cover 868425 Locking ring 471-25x1,2 UH868605 Support ring Ø25x35x2 UH870525 Spherical ball bearing 1205...
- Page 22 Fig. 5: Dept Wheel...
- Page 23 SPARE PARTS UM 6150 – Fig. 5: Dept Wheel Ref. Art. No. Item Description 289095 Dept wheel cpl. 3-155001 Outer pipe 4-155002 Inner pipe 241285 Wheel 4,00x4 cpl. 15004 Mounting hoop 012938 Washer 9021 – 22 852167 Nylock nut 985-M20...
-
Page 24: Eu Declaration Of Conformity
EU - DECLARATION OF CONFORMITY Responsible person Name Atle Årsland Position General Manager Company Underhaug AS Address Torlandsvegen 3 4365 Nærbø, NORWAY Phone +47 51 43 49 78 Declares that the following machine: Manufacturer: Underhaug AS Type: UM 5150 Potato Planter... - Page 25 Torlandsvegen 3 – P.Box 183 N-4367 Nærbø, Norway Phone: +47 51 43 49 78 Email: post@underhaug.no www.underhaug.no/eng...
