- Page 1 SPREADING BUCKET GSK 1600 User manual and spare parts...
-
Page 2: Product Information
If you would like to learn more about our products, you can visit our website at www.underhaug.no or contact us by phone or email. Our goal is for you to be a satisfied Globus customer. To achieve this, we focus on quality and user- friendly products. -
Page 3: Declaration Of Conformity
User manual and spareparts GSK 1600 DECLARATION OF CONFORMITY Producer: Underhaug AS Address: Torlandsveien 3 4365 Nærbø N-NORWAY We hereby declare under our own responsibility that the following product: Type: GSK 1600 Spreading bucket Serial No.: Year of Manufacture: 2024->... -
Page 4: Table Of Contents
User manual and spareparts GSK 1600 CONTENT Introduction Side Welcome as customer Product information Declaration of conformity Safety User manual Causion Cruching hazard Safety labeling Product information Intended use Construction and functions Technical data Additional equipment Assembly and connection Assembly Front- and rear mounting Connection User tips... -
Page 5: Safety
User manual and spareparts GSK 1600 2 SAFETY 2.1 Operating instructions Anyone using the Globus spreading bucket GSK-1600 must familiarize themselves with the contents of the operating manual before the machine is used. 2.2 Caution Ensure that no one is in the working area of the spreading bucket. 2.3 Crushing hazard at discharge roller during standstill If the discharge roller becomes blocked by ice, stones, or other foreign objects, the oil pressure must always be disconnected, the engine stopped, and the key removed from the ignition before cleaning... -
Page 6: Safety Marking
User manual and spareparts GSK 1600 2.1 Safety Marking Globus spreading bucket are equipped with various warning signs that indicate actions to be taken to avoid injuries and accidents. The symbol appears on warning signs located in various places on the machine. -
Page 7: Product Information
2.2 Construction and Functions The Globus GSK 1600 is a simple and reliable spreading bucket for spreading sand, salt, and gravel. The working width is 2 meters, and the spreading bucket has a capacity of 900 litres. The spreading bucket is self-loading and can be mounted both in front and at the rear of the tractor. -
Page 8: Assembly And Connection
User manual and spareparts GSK 1600 2 ASSEMBLY AND CONNECTION 2.1 Assembly The spreading bucket is delivered fully assembled and ready for use unless otherwise agreed. The GSK 1600 has a replaceable coupling frame and is supplied with an optional attachment. 2.2 Rear and front mounting If the GSK-1600 is to be mounted at the rear of the tractor, a hydraulic telescopic top link must be used to maintain the self-loading capability. -
Page 9: Maintenance Retightening
User manual and spareparts GSK 1600 2 MAINTENANCE 2.1 Re-tightening After a few hours of operation with a new spreading bucket, all screw connections should be checked and re-tightened where necessary. Afterward, the screw connections should be checked regularly. The chain should be re-tightened after a few hours of operation, as it stretches when new. Tightening of the chain is done with the tightening device in the chain box. -
Page 10: Spare Parts Gsk 1600
User manual and spareparts GSK 1600 SPARE PARTS GSK 1600... - Page 11 User manual and spareparts GSK 1600 GSK 1600 POS: Art. no: Description: Add. info: 140549-2 Lock vane rubber lip ->2020 140549 Lock vane rubber lip 2021-> 129920 Internal bearing cover 140522-3 Handle 140526 Mixer 140527 Dispencer roller 140522 Dispencer adjustment 140545 Sleeve 140524...
- Page 12 User manual and spareparts GSK 1600...
- Page 13 User manual and spareparts GSK 1600 GSK 1600 POS: Art. no: QTY Description: Add. info: DIN 125 - A 17 Washer DIN 125 - A 13 45 Washer DIN 125 – A 10,5 22 Washer DIN 9021 – 8,4 Washer DIN 125 –...
-
Page 14: Warranty
3 WARRANTY TERMS 3.1 Warranty Underhaug AS guarantees that the product, including all parts, is manufactured in accordance with the applicable specifications and is free from material or manufacturing defects for a period of 12 months from the date of sale. The sales date is considered to be the invoice date. -
Page 15: Maintenance Overview
User manual and spareparts GSK 1600 Maintenance overview Stearing tie Impactor rubber Chain Date Bearing Hydraulic Sign. transmission Annual MANDATORY inspection of the machine (cf. User Directive) Date: Controller (approved) Signature... - Page 16 User manual and spareparts GSK 1600 WWW.UNDERHAUG.NO PRODUCER: Underhaug AS 4365 Nærbø N-NORWAY...
