- Page 1 GRS 300 ROLLER 1-row User manual and spare parts...
- Page 2 If you would like to learn more about our products, you can visit our website at www.underhaug.no or contact us by phone or email. Our goal is for you to be a satisfied Globus customer. To achieve this, we focus on quality and user- friendly products.
-
Page 3: Declaration Of Conformity
DECLARATION OF CONFORMITY Producer: Underhaug AS Address: Torlandsveien 3 4365 Nærbø N-NORWAY We hereby declare under our own responsibility that the following product: Type: GRS 300 Roller 1-row Serial No.: Year of Manufacture: 2023-> covered by this declaration, complies with the following standards: •... -
Page 4: Table Of Contents
CONTENT Introduction Side Welcome as customer Declaration of conformity Content Safety Instruction of use Caution Crushing hazard Safety labeling Product Information Intended use Construction and functions Technical data Assembly and Connection Assembly Connection User Tips User tips Maintenance Maintenance Retightening Replace wear parts Color code Warranty... -
Page 5: Safety
2 SAFETY 2.1 Instructions for Use Anyone using a Globus drum must familiarize themselves with the contents of the user manual before operating the machine. 2.2 Caution Ensure that no person is within the machine's working area. Stones, soil, and other foreign objects affected by the machine can cause damage to people, vehicles, buildings, and other objects. -
Page 6: Safety Labeling
2.9 Safety Labels All Globus drum models are equipped with various warning signs indicating measures that must be taken to avoid injury and accidents. The symbol appears on warning labels located in different places on the machine. These are shown in the images below. If the labels are removed from the machine, new ones can be provided by the manufacturer or dealer. -
Page 7: Product Information
3 PRODUCT INFORMATION 3.1 Area of Use The Globus single-lane drum can be used for surface treatment after sowing or for rolling meadows. All drums require skilled operation, and the user manual should be read before connection and operation, even if one has experience with similar machines. 3.2 Construction and Functions The Globus single-lane drum is equipped with Cambridge rings, built on a solid frame with a three-point hitch. -
Page 8: User Tips
5 USER TIPS 5.1 User Tips for Single-Lane Drum • Rolling should be done after sowing on a dry surface. • Assess the field to be rolled and, if possible, adjust the driving pattern to avoid excessive overlap and driving on already rolled surfaces. •... -
Page 9: Warranty
7 WARRANTY TERMS 7.1 Warranty Globus AS guarantees that the product, including all parts, is manufactured in accordance with applicable specifications and is free from material or manufacturing defects for a period of 12 months from the date of sale. The date of sale is considered the invoice date. A receipt for the paid invoice serves as the warranty certificate. -
Page 10: Spare Parts
8 SPARE PARTS... - Page 11 POS: Art. no: Qty. Description: 970800 Lift welded 970315 Frame for M48550T M5046T 130134 Shaft for side Ø60 970029 Support legs welded 970026 Top link hoop welded G-129992 Sliding ring Ø500-60 G-129993 Cog ring Ø60/Ø500 G-010567 Flange bearing FY 50 TF G-010702 Ring splint Ø6 x 45 mm G-500127...
-
Page 12: Maintenance Overwiev
Maintenance overview Date Bearing Slewing ring Infeed Chute Sign. Annual MANDATORY inspection of the machine (cf. User Directive) Date Controller (Approved) Stamp/Signature... -
Page 13: Notes
Notes... - Page 14 Notes...
- Page 15 WWW.UNDERHAUG.NO PRODUCER: UNDERHAUG AS 4365 Nærbø N-NORWAY...
