- Page 1 UM 8028 Wheel Grab Instruction and spare parts Edition 2025 Revised 01.01.2025 Language Original user manual...
-
Page 2: Warranty
Warranty claims must be reported within the warranty period. The dealer must complete a claim form for each warranty case and submit it to Underhaug’s sales company/importer by the 10th of the month following the report of the damage. - Page 3 Contents General Safety ................... pg. 4-8 Supplementary Safety ................pg. 9 Machine Applications .................pg. 10 Spare Parts ....................pg. 11-12 EU Declaration of Conformity ..............pg. 13...
- Page 4 Safety Before operating the machine Ensure proper tractor compatibility Before operating, adjusting, or repairing the The tractor’s weight must match the machine, the user, repairer, and owner must machine’s maximum working weight. Follow familiarize themselves with the safety applicable public regulations (Fig 4). instructions provided in this manual (Fig 1).
- Page 5 Think safety while working Hydraulics The tractor engine should be stopped and Be cautious when handling hydraulic the ignition key removed before performing systems. Wear eye protection and gloves. any repair work, lubrication, or other Oil released under high pressure can maintenance on the machine.
-
Page 7: Maintenance
When disconnecting the machine and Safety equipment leaving the tractor/machine Always carry first aid equipment in the Set all hydraulic functions to the neutral tractor. Follow public regulations position when disconnecting the regarding fire extinguishing equipment. machine. Lower the movable working When working with flammable materials components to the ground or set them such as hay and straw, fire extinguishing... - Page 9 Instructions for UM 8028 Wheel Grab This equipment is marked with this warning sign. If the sign is damaged, it must be replaced. Warning Sign 220532 (Fig. 1). Caution. Read and understand the instruction manual before using the equipment, and before making adjustments or performing maintenance.
- Page 10 Purpose of the Machine The UM 8028 Wheel Grabber is primarily designed for transporting and distributing silage, wet grass, treated straw, and other green fodder. It is lightweight and eliminates all manual loading and unloading tasks. The machine is constructed like a small hay fork with five specially hardened tines that support the load and a clamp that secures it in place.
- Page 11 FIG.1: WHEEL GRAB...
- Page 12 SPARE PARTS – FIG.1: WHEEL GRAB Ref. Part No. Qty. Description 240101 Frame 240117 Clamp 240124 Handle 240133 Hook 240156 Tine 850260 Hex. Nut M10 7-14 240140 Wheel 4.00x8'' Complete 7-12 240141 Rim with Bearings 240142 240143 240144 Retaining Ring 240145 Seal Lamella SKF-Z005 870625...
-
Page 13: Eu Declaration Of Conformity
EU - DECLARATION OF CONFORMITY Responsible person Name Atle Årsland Position General Manager Company Underhaug AS Address Torlandsvegen 3 4365 Nærbø, NORWAY Phone +47 51 43 49 78 Declares that the following machine: Manufacturer: Underhaug AS Type: UM 8003 Feed Wagon... - Page 14 Torlandsvegen 3 – P.Box 183 N-4367 Nærbø, Norway Phone: +47 51 43 49 78 Email: post@underhaug.no www.underhaug.no/eng...
