Monitor Accessory
User Manual
Ergo Arm | BSH01
V 1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BSH01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BenQ BSH01

Summary of Contents for BenQ BSH01

  • Page 1 Monitor Accessory User Manual Ergo Arm | BSH01 V 1.00...

  • Page 2: Copyright & Disclaimer

    Copyright & disclaimer Copyright Copyright © 2024 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any...

  • Page 3: Product Support

    Please visit http://support.benq.com for the latest version of this manual. It is the sole responsibility of the user if problems (such as data loss and system failure) occurred due to non-factory installed software, parts, and/or non-original accessories.

  • Page 4: Safety Instructions

    Safety instructions Safety precautions To ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. • Read this user manual before installation. • Keep this manual in a safe place for future reference.

  • Page 5: Disposal

    To dispose of the product, consult your local environment authorities for regulations. Servicing Scan the QR code on your product or visit the local website from Support.BenQ.com for more support. Support.BenQ.com Note The illustrations and the images shown in this document are for your reference.

  • Page 6: Table Of Contents

    Table of Contents Copyright & disclaimer..........2 Copyright .............. 2 Disclaimer ............2 Product support ............. 3 Safety instructions ..........4 Safety precautions ..........4 Disposal ..............5 Servicing ............... 5 Package contents ........... 8 Introduction ............10 Product overview ..........10 Installation requirements ........12 Installation ..............13 Mounting options ..........13...
  • Page 7 Adjusting tilt strength ........32...

  • Page 8: Package Contents

    Package contents Carefully unpack and verify that you have all of the items shown below. Some of the items may not be available depending on your region of purchase. If any of these items are missing, please contact your place of purchase. Descriptions Upper arm Lower arm (with 2 stop screws)
  • Page 9 Descriptions 6 mm Allen key Screw for clamp x 1 (M8 x 75) Screw for grommet x 1 (M8 x 150) Clamp plate Retainer (rotation stopper) 4 mm Allen key Hinge washer x 2 Hinge screw Hinge joint Screw x 4 (M4 x 12) Washer x 4 (D5) Cable clip Spare parts (stop screw, hinge washer, M4 screw,...

  • Page 10: Introduction

    Introduction Product overview Descriptions Reinforcement plates Getting ready for desk protection on page for details. Mount base Installing mount base for clamp mounting on page 17 Installing mount base for grommet mounting on page 20 for details. Lower arm Installing the lower arm on page 22 details.
  • Page 11 Descriptions Cable cover Managing the cables on page 29 details.

  • Page 12: Installation Requirements

    Installation requirements • A VESA-compliant monitor Compatible VESA mounting patterns: 75x75 mm, 100x100 mm • Weight capacity: 2 ~ 20 kg (4.4 ~ 44 lbs) Apart from the monitor weight, additional weight from peripherals such as a web cam or a monitor light should be considered as well.

  • Page 13: Installation

    Installation Mounting options Depending on your desk type, follow the steps below to assemble your monitor. A. Clamp mounting B. Grommet mounting • Φ = 12 mm ~ 70 mm Desk thickness: 17 ~ 50 mm (without • Distance to the edge: reinforcement plates) 55mm •...
  • Page 14 Note The provided reinforcement plates may not work with all desks. Use of the plates is optional yet highly recommended. Use both of them or at least the big one if possible. Tips If you tend to drill a grommet hole, the minimum grommet hole diameter is 12mm.

  • Page 15: Prior To Assembling

    Prior to assembling Checking where to install the arm The desk should be placed on a flat even area and should be stable enough to hold the weight of the ergo arm stand and the monitor. The ergo arm stand works for clamp and grommet mounting to suit your need.
  • Page 16 For grommet installation, evaluate the location of the grommet hole first. To align the plate hole with the grommet hole, you might need to flip the big reinforcement plate. Using the plate upside down does not change desk protection or arm stability, though it changes where to attach the cushion mat.

  • Page 17: Installing Mount Base For Clamp Mounting

    Installing mount base for clamp mounting 1. Attach c-clamp to the mount base. 2. Fix c-clamp and the mount base with the screw ) and the 6 mm Allen key ( ). Do not tighten the screw all the way down at this moment. Keep the c-clamp adjustable to fit your desk later.
  • Page 18 4. Place the small reinforcement plate between the c-clamp and the mount base. 5. Attach the mount base together with the small reinforcement plate to your desk. Hold the parts carefully and keep them from falling. Keep them as close to the desk edge as possible to ensure stability.

  • Page 20: Installing Mount Base For Grommet Mounting

    Installing mount base for grommet mounting Note • The provided reinforcement plates may not work with all desks. Use of the plates is optional yet highly recommended. Use both of them or at least the big one if possible. • In some cases you can mount the base and route the cable through the same grommet hole.
  • Page 21 2. Place the mount base on top of the big reinforcement plate. 3. Stack the small reinforcement plate and grommet plate ( ) under the desk as illustrated. Align all parts properly. Fully tighten the grommet screw ( ) to secure all parts together by the 6 mm Allen key (...

  • Page 22: Installing The Lower Arm

    Installing the lower arm 1. Decide the swivel range by the retainer ( ). The degree marked on the retainer indicates how far the ergo arm could go. If there is no space behind the monitor, choose 180° so the arm will not hit the wall.
  • Page 23 3. There is a stop screw attached to each side of the lower arm. Use the 4 mm Allen key ( ) to secure the lower arm and the mount base by the stop screw. Do not overtighten the screw.

  • Page 24: Installing The Display Bracket And Upper Arm

    Installing the display bracket and upper arm 1. Insert the hinge washers ( ) to the display bracket. 2. Pay attention to the direction of the display bracket and make sure the thumbscrew is facing upward. Attach the display bracket to the upper arm.
  • Page 25 3. Align the hinge joint ( ) with the holes properly and fasten it with the hinge screw ( ). Secure them with the 4 mm Allen key ( 4. Check if all parts are secured. The hinge joint and its screw should be flat without protrusions.
  • Page 26 5. Align the upper arm with the lower arm and place it properly without the metal part being seen. 6. Use the 4 mm Allen key ( ) to secure the arms by the stop screw. Do not overtighten the screw.

  • Page 27: Installing The Monitor

    Installing the monitor 1. Release the thumbscrew on the display bracket and detach the VESA plate. 2. Attach the VESA plate to the VESA holes on the rear of your VESA-compliant monitor and fasten it with washers ( ) and screws ( ) by a cross-pointed screwdriver (not included in the package).
  • Page 28 Note • The provided VESA mounting screws ( ) are M4 x 12. As the monitor designs vary, you might need longer mounting screws (purchased separately) to fix the VESA plate to your monitor to keep it stable. Check the monitor's user manual for mounting screw information.

  • Page 29: Managing The Cables

    Managing the cables 1. Insert the cable clip ( ) to the rear of the mount base. Note there is one direction to install the clip properly. 2. Remove the cable covers on the arms. 3. Route the cables properly as illustrated. Remember to leave slack in cables (near the monitor) to prevent connectors from being pulled out inappropriately during monitor angle...

  • Page 31: Tension Adjustments

    Tension adjustments The supported mounting weight of this product is from 2 to 20 kg (4.4 ~ 44 lbs). The ergo arm should be able to hold the mounting weight between 5 to 7 kg without further adjustment. Try to lift, lower, or tilt the monitor after the monitor installation.
  • Page 32 Adjusting tilt strength If the monitor keeps rising or drooping, increase tilt strength by turning the tilt adjustment screw clockwise to . If the monitor can hardly be tilted, decrease the tilt strength by turning the tilt adjustment screw counterclockwise to .
  • Page 33 © 2024 BenQ Corporation. All rights reserved. Rights of modification reserved. © 2024 BenQ Corporation. All rights reserved. Rights of modification reserved.
