Installation Manual
Be sure to read this manual thoroughly and to do the installation work safely.Keep
●
this manual available for future reference.
Sufficient expertise is required for installing this projector wall mount.
●
Do not use the projector wall mount for purposes other than for which it is designed.
●
Model: WM03G5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BenQ WM03G5
Summary of Contents for BenQ WM03G5
-
Page 1: Installation Manual
Installation Manual Model: WM03G5 Be sure to read this manual thoroughly and to do the installation work safely.Keep ● this manual available for future reference. Sufficient expertise is required for installing this projector wall mount. ● Do not use the projector wall mount for purposes other than for which it is designed. - Page 2 Important Safety Be sure to read this manual thoroughly to do the installation work. Only qualified service personnel (two or more) should carry out installation or dismounting of the projector from the projector wall mount. Use with products heavier than the maximum weights(Weight Capacity：＜15kg) indicated may result in instability causing possible injury.
- Page 3 Checking The Installation Position Regulating range 0~75mm ±5° ±5° ±5° ● According to the scale to determine the screen size .Scale parameters are for reference only. inch...
- Page 4 To Set The Projector Wall Mount On The Wall ● According to the scale to determine the installation height of the wall plate . Scale parameters are for reference only. Please refer the installation chart in projector UM and QSG for proper installation evaluation.
- Page 5 To Set The Projector Wall Mount On The Wall ● The bracket is suitable for concrete wall mounting or wooden stud wall. ● Concrete wall mounting thickness must be a minimum 100mm. Anchor bolt and screw (M6 × 55) are needed to be used for installation. ●...
- Page 6 To Set The Projector Wall Mount On The Wall All ow t o adjust the projector upward/downward by Tighten the screw “f” to wall plate but ● ● regulating l ead sc rew.You can adj ust the projector do not tighten it. Fasten it after locating upward/downward according to your need.
- Page 7 To Install The Projector On The Projector Wall Mount Move the mouting plate and adjust the leftward/rightward slide. ● Adjust the leftward/ rightward slide:30mm Adjustment direction Locking the screw e. Connect the power cable and other cables to ● ● the projector.
- Page 8 To Adjust The Horizontal Rotation Adjustment buttons Adjustment direction To Adjust The Forward/Backward Slide Adjustment direction To Put On The Decorative Cover Product Information: Net weight: 4.5kg Rated capacity: 15kg Adjustable angle: Longitudinal inclination 、Level angle、Yaw angle±5°(3 directions) Adjustable range: From the installation plate center horizontal distance 315mm 535mm Adjustable range for upward/downward slide : 75mm Adjustable range for leftward/rightward slid: 30mm...
