R
INSTRUCTION
MANUAL
TALKING CUBE
18870

Advertisement

loading
Need help?

Need help?

Do you have a question about the SNOEZELEN TALKING CUBE and is the answer not in the manual?

Questions and answers

Summary of Contents for Rompa SNOEZELEN TALKING CUBE

  • Page 1 INSTRUCTION MANUAL TALKING CUBE 18870...
  • Page 2 CONTENTS...
  • Page 3: Table Of Contents

    CONTENTS ABOUT THE PRODUCT ������������������������������������������������������������������������������������ 4 Product Description ����������������������������������������������������������������������������������������������������������������������������������������������������5 User Benefits ����������������������������������������������������������������������������������������������������������������������������������������������������������������5 TECHNICAL SPECIFICATION ��������������������������������������������������������������������������� 6 Included Parts���������������������������������������������������������������������������������������������������������������������������������������������������������������7 Technical Specification ����������������������������������������������������������������������������������������������������������������������������������������������7 SAFETY AND CARE ������������������������������������������������������������������������������������������� 8 Product Safety and Care Instructions �������������������������������������������������������������������������������������������������������������������9 ASSEMBLY & INSTALLATION GUIDE Product Assembly Guide/Installation ����������������������������������������������������������������������������������������������������������������� 13 USER GUIDE �����������������������������������������������������������������������������������������������������14 User Guide ������������������������������������������������������������������������������������������������������������������������������������������������������������������...
  • Page 4: About The Product

    ABOUT THE PRODUCT...
  • Page 5: Product Description

    Product Description The Talking Cube is a soft play cube that changes colours on Rompa Wi-Fi compatible products ® when rolled. Its wireless design enhances sensory experiences, making it ideal for therapeutic and educational settings. Safe for all ages, it encourages exploration and supports various developmental goals in classrooms, therapy sessions, and at home.
  • Page 6: Technical Specification

    TECHNICAL SPECIFICATION...
  • Page 7: Included Parts

    Included Parts Cube Specifications: • Material: PVC (colours may vary, typically orange, yellow, green, purple, blue, red) • Weight: Approximately 1.6 kg • Foam: 30cmH x 30cmW x 30cmD Power Supply (Black Plug): • Input: 230v~50Hz (110v available) • Output: 12v 300mA, double isolated (IP40) •...
  • Page 8: Safety And Care

    SAFETY AND CARE...
  • Page 9: Product Safety And Care Instructions

    Product Safety and Care Instructions Remove battery from the unit before recharging� Gently lift the PVC flap around three sides of the cube to expose the zip. Open the zip. A slit will be visible in the foam inside the cube. Reach into the slit and pull out the box: Turn the box over and slide the battery compartment lid off –...
  • Page 10 To clean the PVC: • Organise a regular cleaning schedule. • Use a soft brush to remove all loose dust/dirt. • Clean with a mild detergent (such as Lux soap flakes in luke-warm solution) applied to a sponge or damp cloth. •...
  • Page 12: Assembly & Installation Guide

    ASSEMBLY & INSTALLATION GUIDE...
  • Page 13: Product Assembly Guide/Installation

    Product Assembly Guide/Installation Connect Power Supply: Plug the round tip of the power supply into the round socket at the top of the white control box, then plug the power supply into a mains wall socket. Turn On Control Box: Press down the volume knob on the control box until you hear a click to turn it ON.
  • Page 14: User Guide

    USER GUIDE...
  • Page 15: User Guide

    User Guide Recording Connect the round tip of the power supply to the round socket at the top of the white control box. Plug in at a mains wall socket. Turn the control box ON – press down the volume knob until you hear a click (press it again to turn it OFF).
  • Page 16 Recording tips • Start talking immediately after the red light comes on. A delay at the start of recording will result in a delay in the cube ‘talking’ when it settles after being thrown. • If you don’t like your recording, start again – you can re-record the message as often as you need to.
  • Page 17: Troubleshooting

    TALKING CUBE AS PART OF WI-FI In conjunction with compatible Rompa Wi-Fi products, the Talking Cube can be used as a switch. ® Not only will the cube tell you the colour on the uppermost face of the Cube (or play your recorded message), it will also change the colour of the Wall Panel displays, Milky Way Carpets, Star Cloths, bubble tubes and fibre optics around you to the colour of the uppermost face.
  • Page 18 Check the talking cube module is powered on. Then open the zip on the cube itself and ensure that the module inside is powered on via the switch on the module: Now zip the cube back up with the module in and if you throw it on its side, it should say the name of the colour it has landed on.
  • Page 19 Unzip the cube and remove the module inside, turn the module over and look for the battery module at the bottom: Slide the battery cover down to reveal the battery: Gently remove the 9V battery: Lift the battery out and disconnect the connector from the battery: Connect the new replacement battery to the two contact points and place the battery back into the compartment.
  • Page 20 Try and record a new message. Refer to ‘User Guide’ on page 15 to record a new message. If there is still no sound coming from the speaker after trying the troubleshooting steps outlined above, then please contact Rompa customer services on +44 (0) 1246 211 777 ®...
  • Page 22: Notes

    NOTES...
  • Page 24 Rompa Limited, Goyt Side Road, ® Chesterfield, S40 2PH customer.service@rompa.com www.rompa.com 18870_240225...
