Related Manuals for Honeywell Notifier ACM-8R

Summary of Contents for Honeywell Notifier ACM-8R

  • Page 1 Annunciator Control Module ACM-8R Instruction Manual Document 15342 Rev: G1 11/14/19 ECN: 18-305...
  • Page 2 Fire Alarm & Emergency Communication System Limitations While a life safety system may lower insurance rates, it is not a substitute for life and property insurance! An automatic fire alarm system—typically made up of smoke Heat detectors do not sense particles of combustion and alarm detectors, heat detectors, manual pull stations, audible warning only when heat on their sensors increases at a predetermined rate devices, and a fire alarm control panel (FACP) with remote notifica-...

  • Page 3: Installation Precautions

    HARSH™, NIS™, and NOTI•FIRE•NET™ are all trademarks; and Acclimate® Plus™, eVance®, FlashScan®, FAAST Fire Alarm Aspiration Sensing Technology®, Honeywell®, Intelligent FAAST®, NOTIFIER®, ONYX®, ONYXWorks®, SWIFT®, VeriFire®, and VIEW® are all registered trademarks of Honeywell International Inc. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation. Chrome™ and Google™ are trademarks of Google Inc. Firefox® is a registered trademark of The Mozilla Foundation.

  • Page 4: Software Downloads

    Brief description of content you think should be improved or corrected • Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. ACM-8R — P/N 15342:G1 11/14/19...

  • Page 5: Table Of Contents

    Table of Contents Section 1: Introduction ..............................8 1.1: About This Manual ......................................8 1.2: UL 864 9th and 10th Edition .....................................8 1.2.1: Products Subject to AHJ Approval.................................8 1.3: Related Documentation .....................................8 Section 2: The ACM-8R Annunciator Control Module ....................10 2.1: Features of the ACM-8R....................................10 2.2: Mounting..........................................10 Section 3: Design Considerations ..........................
  • Page 6 Table of Contents E.4: Relay Assignment (Alarm & Trouble Mode) ..............................41 F.1: Capabilities ........................................44 F.2: Connecting the ACM-8R to the AFP-100................................44 G.1: Capabilities ........................................46 G.2: Connecting the ACM-8R to the NFS2-640/NFS-320.............................46 G.3: Connecting the ACM-8R to the AFP-300/400..............................46 G.4: Connecting the ACM-8R to the NFS-640...............................47 ACM-8R —...

  • Page 7: Table Of Contents

    Table of Contents ACM-8R — P/N 15342:G1 11/14/19...

  • Page 8: Section 1: Introduction

    Section 1: Introduction 1.1 About This Manual The ACM-8R is an element in the Notifier ACS class of annunciators. It provides the Notifier control panels with a relay control module that can be mapped on newer panels and on older panels such as the System 5000 or System 500 memory map (by groups of eight). 1.2 UL 864 9th and 10th Edition Per the UL Continuing Certification Program, UL 864 9th edition fire alarm control equipment will retain certification after the rollout of UL 10th edition (12/2/2018).
  • Page 9 Related Documentation Introduction ACM-8R — P/N 15342:G1 11/14/19...

  • Page 10: Section 2: The Acm-8R Annunciator Control Module

    Section 2: The ACM-8R Annunciator Control Module 2.1 Features of the ACM-8R The ACM-8R provides eight Form-C relays with 5 amp contacts. The relays can be employed to track any 8 point module in the System 5000 or System 500, or track any grouping of points in the AM2020 or AFP1010.
  • Page 11 Mounting The ACM-8R Annunciator Control Module ACM-8R — P/N 15342:G1 11/14/19...

  • Page 12: Section 3: Design Considerations

    Section 3: Design Considerations 3.1 Limits The ACM-8R is a member of the Notifier ACS class of annunciators. Up to 32 annunciators may be installed on an EIA-485 circuit. The actual number of annunciator modules may be larger depending on the number of expander modules employed. 3.2 Wire Runs Communication between the Control Panel and the ACM-8R is accomplished over a power-limited two-wire EIA-485 serial interface.

  • Page 13: End Of Line Resistor For Eia-485 Circuit

    End of Line Resistor for EIA-485 Circuit Design Considerations • When the EIA-485 shield is not in conduit: Terminate the shield at the outside of the FACP backbox (ground). Do not allow the shield to enter or even touch the cabinet. Between annunciators, wire-nut multiple shields together outside of the respective enclosures (see Figure 3.2).

  • Page 14: Remote Power Source For Annunciators

    Design Considerations Remote Power Source for Annunciators 3.8 Remote Power Source for Annunciators If the ACM-8R and other annunciator-type modules are to be powered from a remote supply, a common connection between the nega- tive battery terminals of each supply must be made. Fire Alarm Control Panel Annunciator in a Backbox, powered from the Control Panel...
  • Page 15 Power Requirements Design Considerations ACM-8R — P/N 15342:G1 11/14/19...

  • Page 16: Section 4: Installing The Acm-8R

    Section 4: Installing the ACM-8R 4.1 Remote Applications  For remote applications, use the ABS-8RB enclosure Select an appropriate knockout on the ABS-8RB enclosure. Mount the backbox. The enclosure must be connected to a solid Earth Ground (do not use conduit for this purpose). Pull all annunciator wiring into the enclosure. ...

  • Page 17: Configuring And Wiring The Acm-8R

    Configuring and Wiring the ACM-8R Installing the ACM-8R 4.4 Configuring and Wiring the ACM-8R SW3 Relay Assignment DIP Switches (refer to Table 4.1) ONLY ONLY MODE SELECT SW4-1: Set ON if relays are to be activated by alarms signals only. Set switch OFF for alarm and trouble activation.

  • Page 18: Powering The Acm-8R

    Installing the ACM-8R Powering the ACM-8R 4.5 Powering the ACM-8R To other devices - Common Non-supervised Non-resettable 24VDC - Common +24V Regulated, Power-Limited, +24V Compatible Power Supply Earth UL/ULC-Listed for Fire Protective Signaling Use ACM-8R Figure 4.3 ACM-8R Power 4.6 Multiple Annunciator Wiring •...
  • Page 19 Multiple Annunciator Wiring Installing the ACM-8R Control Panel or Remote Power Supply - 24 VDC + 24 VDC Common (-) Common (-) Common (-) Common (-) 24 VDC (+) 24 VDC (+) 24 VDC (+) 24 VDC (+) Last ACM-8R or other First ACM-8R or other annunciator-type device annunciator-type device...

  • Page 20: Relay Terminal Assignments

    Installing the ACM-8R Relay Terminal Assignments 4.7 Relay Terminal Assignments The ACM-8R provides eight relays with Form-C contacts rated for 5 amps. The terminal assignments are illustrated below. For selecting where in the control panel's memory map these relays will be assigned, refer to Table 4.1. For information on wiring limitations, refer to Section 4.10 “UL Power-limited Wiring Requirements”.

  • Page 21: Row And Module Arrangement (System 5000/ System 500 Only)

    Row and Module Arrangement (System 5000/ System 500 only) Installing the ACM-8R NOTE: Table 4.1 outlines relay assignments at a given EIA-485 address. A single EIA-485 address can support up to 64 points. At address '1,' the information corresponds directly with system points. However, point 1 in Table 4.1 at address '2' actually represents the 65th point in the system;...
  • Page 22 Installing the ACM-8R UL Power-limited Wiring Requirements Nonpower-limited Power-limited Circuits Circuits 1) If a mix of power-limited and nonpower- limited circuits are connected to relays, skip a set of dry contacts to maintain 0.25" spacing between power-limited and nonpower- limited circuits. 2) If only power-limited or nonpower-limited circuits are being employed, all relays may ACM-8R be used without skipping any for spacing purposes.
  • Page 23 UL Power-limited Wiring Requirements Installing the ACM-8R ACM-8R — P/N 15342:G1 11/14/19...

  • Page 24: Appendix A: System 5000

    Appendix A: System 5000 A.1 Capabilities When installed with a System 5000, the ACM-8R can follow the status of initiating and indicating circuits, relays, and several system control functions. Circuits: IZM-8 Initiating Device Circuits (alarm and trouble) ICM-4/ICE-4 Indicating Appliance Circuits (activation and trouble)* CRM-4/CRE-4 Control Relays (activation)* TCM-2 circuits (activation and trouble)* TCM-4 circuits (activation and trouble)*...

  • Page 25: A.3: Relay Assignment Example: System 5000 Alarm Only Mode

    Relay Assignment Example: System 5000 Alarm Only Mode System 5000 A.3 Relay Assignment Example: System 5000 Alarm Only Mode The ACM-8R can follow the alarm status of any module in the System 5000. To Address 01 assign the ACM-8R to a module, two switches on SW3 must be set to ON. Exam- ple: To assign the ACM-8R to the third module in the second row of a System 5000, set switches 3 and 6 on SW3 to ON, set the other six switches to OFF.

  • Page 26: A.4: Relay Assignment Example: System 5000 Alarm & Trouble Mode

    System 5000 Relay Assignment Example: System 5000 Alarm & Trouble Mode A.4 Relay Assignment Example: System 5000 Alarm & Trouble Mode The ACM-8R can follow the alarm and trouble status of any module half in the Address 01 System 5000. To assign the ACM-8R to a module half, two switches on SW3 must be set to ON.

  • Page 27: A.5.1: Mps-24A Main Power Supply

    EIA-485 Connection System 5000 A.5.1 MPS-24A Main Power Supply For the System 5000, connect the power run for the ACM-8R to MPS-24A TB3 Terminals 1 (+) and 2 (-) (1 amp max and power-lim- ited). The total amount of current drawn from these terminals cannot exceed that rating in standby or in alarm. Common (-) 24 VDC Power (+) to ACM-8R TB3-1...

  • Page 28: Appendix B: Nfs2-3030, Nca-2, Nfs-3030, Nca, Am2020/Afp1010

    Appendix B: NFS2-3030, NCA-2, NFS-3030, NCA, AM2020/AFP1010 B.1 Capabilities When installed with an AM2020/AFP1010, the ACM-8R can follow the status of addressable devices, software zones, and several sys- tem control functions: Devices The FACPs and network annunciators support a variety of intelligent addressable SLC Loop devices including detectors, control mod- ules, monitor modules, and manual pull stations refer to the SLC Wiring Manual, Document 51253.

  • Page 29: B.4: Nca Connections

    NCA Connections NFS2-3030, NCA-2, NFS-3030, NCA, AM2020/AFP1010 EIA-485. Connect EIA-485 terminals to TB7 on the CPU-3030 as shown below. EIA-485 connections are power-limited and super- vised. Power EIA-485 TB7 on CPU-3030 TB6 on CPU-3030 B.4 NCA Connections Power. Power for the ACM-8R should be drawn from the FACP’s main power supply. Refer to the appropriate FACP appendix in the manual.

  • Page 30: B.6: Multiple Eia-485 Circuits

    NFS2-3030, NCA-2, NFS-3030, NCA, AM2020/AFP1010 Multiple EIA-485 Circuits EIA-485. The EIA-485 circuit that drives the ACM-8R must be power-limited and connected as illustrated below. EIA-485 Common Earth Ground (chassis) EIA-485 Loop 1 (+) EIA-485 Loop 1 (-) EIA-485 Loop 2 (+) EIA-485 Loop 2 (-) All connections above must be power-limited...
  • Page 31 Programming the AM2020/AFP1010 for Remote Annunciation NFS2-3030, NCA-2, NFS-3030, NCA, AM2020/AFP1010 ACM-8R — P/N 15342:G1 11/14/19...

  • Page 32: C.1: Capabilities

    Appendix C: System 500 C.1 Capabilities When installed with a System 500, the ACM-8R can follow the status of initiating and notification circuits, relays, and several system control functions. Circuits: IZ-4/IZ-4A/IZ-8 Initiating Device Circuits (alarm and trouble) IC-4/ICE-4/ICR-4L Notification Appliance Circuits (activation and trouble) CR-4/CRE-4/CR-4L Control Relays (activation) TC-2/TC-4 circuits (activation and trouble) CPU Points: Activated Notification Circuits 1 and 2, the Remote Signaling Municipal Tie circuit, and the Alarm Relay.

  • Page 33: C.6: Eia-485 Connection

    EIA-485 Connection System 500 C.6 EIA-485 Connection The EIA-485 circuit that drives the ACM-8R must be power-limited and connected as illustrated below. (+) EIA-485 EIA-485 (-) to ACM-8R TB2-1 to ACM-8R TB2-4 CPU-500 C.7 MPS-24B Main Power Supply (System 500 Only) Connect the power run for the ACM-8R to MPS-24B TB2 terminals 1 (+) and 2 (-) (power-limited).

  • Page 34: Appendix D: Sfp-1024

    Appendix D: SFP-1024 D.1 Capabilities When installed with an SFP-1024 Fire Alarm Control Panel (FACP), the ACM-8R Relay Control Modules provide relay activation for each of the ten FACP zones plus special functions. Options exist to allow for alarm only or alarm and trouble activations per zone. Out- put activation for general alarm, general trouble, general supervisory, NAC fault, AC fail, system off normal, walktest start and battery trouble are also available.

  • Page 35: D.3: Acm-8R Alarm Activation Only

    ACM-8R Alarm Activation Only SFP-1024 D.3 ACM-8R Alarm Activation Only DIP switch SW3 on the ACM-8R Relay Control Module is used to determine which FACP activations will trigger relays on the Relay Control Module. When installed with an SFP-1024 Fire Alarm Control Panel, use the following tables to set SW3 switches. Note that two tables are provided;...
  • Page 36 SFP-1024 ACM-8R Alarm Activation Only SFP-1024 Zone ACM-8R Relay ACM-8R Trouble Relay SW3 Settings System Status 1= System Alarm 5= System Trouble 1st ACM-8R System Status Relay 2 not used Relay 6 not used SW3-1 = ON System Status Relay 3 not used 7= System Off Normal SW3-5 = ON All others = OFF...
  • Page 37 ACM-8R Alarm Activation Only SFP-1024 SFP-1024 Zone ACM-8R Relay Settings Relay 1 ACM-8R Relay 2 Address ‘01’ SW1 = 0, SW2 =1 Relay 3 Relay 4 SW3-3 = ON, SW3-5 = ON SW3-1, SW3-2, SW3-4, SW3-6, SW3-7, SW3-8 = OFF Relay 5 Relay 6 SW4-1 = ON (Alarm Only),...
  • Page 38 SFP-1024 ACM-8R Alarm Activation Only LED-10IM LED-10N Address ‘01’ SFP-1024 SFP-1024 SFP-1024 SFP-1024 Receive/Transmit FACP Program Level 3 Address 02 = ‘0’ LED-10N Address ‘02’ Address 03 = ‘3’ Receive/Transmit ACM-8R Address ‘03’ SW3-2 = ON SW3-3 = ON SW3-5 = ON SW3-5 = ON SW4-1 = ON SW4-1 = ON...
  • Page 39 ACM-8R Alarm Activation Only SFP-1024 LED-10IM SFP-1024 LED-10N Address ‘01’ Receive/Transmit FACP Program Level 3 Address 02 = ‘0’ Address 03 = ‘4’ LED-10N Address ‘02’ Receive/Transmit ACM-8Rs set to Address ‘03’ (Alarm Only) Receive Only Receive/Transmit SW3-2 = ON SW3-3 = ON SW3-5 = ON SW3-5 = ON...

  • Page 40: Appendix E: Afp-200

    Appendix E: AFP-200 E.1 Capabilities The AFP-200 is capable of supporting two annunciator addresses, 01 and 02. All releases of AFP-200 software can support ACM-8R modules, no special software is required. The AFP-200 sends zone information to these annunciators, each of which have 64 points. By using ACM-8R modules, it is possible to get an alarm contact or an alarm and trouble contact for each of the AFP-200's ninety-nine zones.

  • Page 41: E.3: Relay Assignment (Alarm Only Mode)

    Relay Assignment (Alarm Only Mode) AFP-200 E.3 Relay Assignment (Alarm Only Mode) Annunciator Address ‘01’ AFP-200 Zone ACM-8R Relay Settings AFP-200 Zone ACM-8R Relay Settings System Alarm Relay 1 Relay 1 Not Used Relay 2 not used Relay 2 Not Used Relay 3 not used ACM-8R Relay 3...
  • Page 42 AFP-200 Relay Assignment (Alarm & Trouble Mode) Annunciator Address ‘01’ ACM-8R AFP-200 Zone ACM-8R Alarm ACM-8R Trouble Settings AFP-200 Zone ACM-8R Relay Settings Trouble Relay 1 Relay 5 ACM-8R Relay 1 Relay 5 ACM-8R Relay 2 Relay 6 Relay 2 Relay 6 Dip Switches Dip Switches...

  • Page 43: E.4: Relay Assignment (Alarm & Trouble Mode)

    Relay Assignment (Alarm & Trouble Mode) AFP-200 ACM-8R — P/N 15342:G1 11/14/19...

  • Page 44: Appendix F: Afp-100

    Appendix F: AFP-100 F.1 Capabilities The AFP-100 is capable of supporting annunciator address 01. All releases of the AFP-100 software can support ACM-8R modules; no special software is required. The AFP-100 sends zone information to these annunciators, each of which have 64 points. By using ACM- 8R modules, it is possible to get an alarm contact or an alarm and trouble contact for each of the AFP-100's fifty-six zones.

  • Page 45: F.2: Connecting The Acm-8R To The Afp-100

    Connecting the ACM-8R to the AFP-100 AFP-100 ACM-8R — P/N 15342:G1 11/14/19...

  • Page 46: Appendix G: Nfs2-640/Nfs-320, Afp-300/400/Nfs-640

    Appendix G: NFS2-640/NFS-320, AFP-300/400/NFS-640 G.1 Capabilities The AFP-300/400 FACP (Fire Alarm Control Panel) is capable of supporting ACM-8R annunciator addresses 01 to 19. All releases of AFP-300/400 software can support ACM-8R modules; no special software is required. The ACM-8R can be assigned to any of the 576 panel annunciation points.
  • Page 47 Connecting the ACM-8R to the NFS-640 NFS2-640/NFS-320, AFP-300/400/NFS-640 G.4 Connecting the ACM-8R to the NFS-640 The EIA-485 connections are made to TB13 on the CPU-640 as shown. 24 VDC power-limited non-resettable power for the ACM-8R is available from TB7 on the CPU-640. Do not use the two pins on TB7 marked “resettable”. TB7 - DC Power 24 VDC power-limited, –...

  • Page 48: G.4: Connecting The Acm-8R To The Nfs-640

    NFS2-640/NFS-320, AFP-300/400/NFS-640 Connecting the ACM-8R to the NFS-640 ACM-8R — P/N 15342:G1 11/14/19...

  • Page 49: Manufacturer Warranties And Limitation Of Liability

    Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan.
  • Page 50 NOTIFIER 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 www.notifier.com...
