300 W. Pontiac Way Clovis, CA 93612 Toll free: 1-800-445-3767 Web: www.belltech.com
Thank you for being selective enough to choose our high quality BELLTECH PRODUCT. We
have spent many hours developing our line of products so that you will receive maximum
Note: Confirm that all of the hardware listed in the parts list is in the kit. Do not begin installation if
any part is missing. Read the instructions thoroughly before beginning this installation.
Warning: DO NOT work under a vehicle supported by only a jack. Place support stands securely un-
der the vehicle in the manufacturer's specified locations unless otherwise instructed.
Warning: DO NOT drive vehicle until all work has been completed and checked. Torque all hardware
to specified values.
Reminder: Proper use of safety equipment and eye/face/hand protection is absolutely necessary when
using these tools to perform procedures!
Note: It is very helpful to have an assistant available during installation.
STOP! We strive for an exceptional experience for all of our valued customers. If, for any reason, you
need assistance with your Belltech products, please do not return the products to the store or website
you purchased from. Please call our dedicated experts at (1-800-445-3767) from 7am to 5pm PST.
RECOMMENDED TOOLS:
Properly rated floor jack and support stands
•
Wheel chocks
•
Torque wrench up to 200 ft/lbs
•
Metric & Standard socket wrench set
•
Metric & Standard wrench set
•
Tape measure
•
Dead blow hammer
•
Marking pen
•
26020-888 3/15/2021 JP REVA-01
A Division of KW AUTOMOTIVE North America, Inc.
19+ RAM 1500 2WD/4WD
**Excludes classic models**
performance with minimum difficulty during installation.
Exceptional Customer Experience Guarantee:
INSTALLATION INSTRUCTIONS
26020
0"-3" LEVELING STRUT
DIFFICULTY:
INSTALLATION TIME: 1-2hrs per strut + Alignment
1
Advertisement
Related Manuals for Belltech 26020
Summary of Contents for Belltech 26020
- Page 1 STOP! We strive for an exceptional experience for all of our valued customers. If, for any reason, you need assistance with your Belltech products, please do not return the products to the store or website you purchased from. Please call our dedicated experts at (1-800-445-3767) from 7am to 5pm PST.
-
Page 2: Kit Contents
KIT CONTENTS PART #: DESCRIPTION: QTY: 26020-100 LIFTING STRUT 25003-016 16mm SPACER 25003-008 8mm SPACER 4926-001 BUMP STOP 65210031 VENT DISC 4935-001 15mm PACKER 26015-002 SPRING PERCH M12X 1.25 26020-888 3/15/2021 JP REVA-01 A Division of KW AUTOMOTIVE North America, Inc. -
Page 3: Kit Installation
Then remove the entire spring/strut assem- bly from its perch and out of the vehicle. NOTE: BE CAREFUL NOT TO DAMAGE OR OVER EXTEND THE BRAKE HOSES WHEN REMOVING THE STRUT ASSEMBLY. 26020-888 3/15/2021 JP REVA-01 A Division of KW AUTOMOTIVE North America, Inc. - Page 4 STRUT DISASSEMBLY: !CAUTION! The coil spring is held in place under extreme load. BELLTECH recommends the use of a heavy duty spring compressor suitable for truck springs to perform this step. If un- sure, take this to a professional installer. Use caution during the following steps to avoid per- sonal injury and/or damage to vehicle.
-
Page 5: Finalizing The Installation
Please place packer on top of the vent disk, channel side down as shown in Photo 7. d. Insert the BELLTECH strut into the OEM spring and install the BELL- TECH bump stop onto the strut Complete the assembly using the OEM lower coil spring isolator, top mount and supplied nut.
