----1075 North Ave. Sanger, CA 93657-3539
Congratulations! You were selective enough to choose a BELLTECH PRODUCT. We have spent
many hours developing our line of products so that you will receive maximum
performance with minimum difficulty during installation.
Note:
Confirm that all of the hardware listed in the parts list is in the kit. Do not begin installation if
any part is missing. Read the instructions thoroughly before beginning this installation.
Warning:
DO NOT work under a vehicle supported by only a jack. Place support stands securely under
the vehicle in the manufacturer's specified locations unless otherwise instructed.
Warning:
DO NOT drive vehicle until all work has been completed and checked. Torque all hardware to
values specified.
Reminder:
Proper use of safety equipment and eye/face/hand protection is absolutely necessary when
using these tools to perform procedures!
NOTE: This is a complex installation that requires trimming of the rear chassis rails and cross members. It
should not be attempted by someone without the proper tools and some experience in installations of this
type. This installation may also require exhaust system modification to re-route the tailpipe aft of the muffler.
We recommend that the installation be performed by a qualified mechanic or repair facility.
RECOMMENDED TOOLS:
Properly rated floor jack, support stands, and wheel chocks
Combination wrench set
Torque wrench: 0-75 lb ft. range
Ratcheting socket wrench and socket sets
Safety Glasses
KIT INSTALLATION
1. Open the hardware kit and remove all of the contents. Refer to the part list (Page 5) to verify that all
parts are present.
2. Park the vehicle on a smooth, level concrete or seasoned asphalt surface and activate the parking
brake. Block the FRONT wheels of the vehicle with appropriate wheel chocks; making sure the
vehicle's transmission is in 1
3. Raise the rear of the vehicle off the ground using a floor jack rated for this load. Position a set of jack
stands rated for this load under the frame rails just forward of the rear leaf spring forward hangers.
Lower the vehicle down onto the jack stands and verify the vehicle stability on the jack stands with the
floor jack located under the center of the rear axle housing.
4. Remove, and set aside, the rear wheels and tires.
6640-888 9/05 ©
A Division of KW AUTOMOTIVE North America, Inc.
toll free: 800-445-3767
6640
FLIP KIT
CHEVY / GMC 2 DR. TAHOE / YUKON
st
gear (manual) or "Park" (automatic).
1

INSTALLATION INSTRUCTIONS

web:
www.belltechcorp.com----

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6640 and is the answer not in the manual?

Questions and answers

Summary of Contents for Belltech 6640

  • Page 1: Installation Instructions

    FLIP KIT CHEVY / GMC 2 DR. TAHOE / YUKON Congratulations! You were selective enough to choose a BELLTECH PRODUCT. We have spent many hours developing our line of products so that you will receive maximum performance with minimum difficulty during installation.
  • Page 2 (PHOTO 21) CAUTION: Be aware of the fuel, brake and electrical components inside the frame rail when drilling through the frame, so as not to cause damage to these components. CAUTION: Always wear eye protection when using power tools. 6640-888 9/05 © A Division of KW AUTOMOTIVE North America, Inc.
  • Page 3 100-120 Ft.-lbs. After the bolts that secure the frame reinforcement to the side of the chassis are torqued, drill through the forward and aft holes in the bottom of the frame reinforcement and install the 6640-888 9/05 © A Division of KW AUTOMOTIVE North America, Inc.
  • Page 4 34. Placement of the exhaust system tailpipe should be analyzed at this point to determine if it extends below a line sighted between the bottom of the frame reinforcement mounted bump stops. The 6640-888 9/05 © A Division of KW AUTOMOTIVE North America, Inc.
  • Page 5 92 Ft.-lbs. and the rear leaf spring eye and shackle eyebolt to 81 Ft.-lbs. 37. Installation is complete. Check all of the hardware and re-torque at intervals for the first 10, 100, 1000 miles. PART LIST FOR 6640 FLIP KIT PART No. DESCRIPTION QTY.
  • Page 6 111125 14mm x 2.0 x 115mm Grade 8 Bolts 111135 14mm x 2.0 Grade C Nut 6640-188 Template 110409 HHCS ½” –20 x 1 ½” 6640-888 9/05 © A Division of KW AUTOMOTIVE North America, Inc.
  • Page 7 6640-888 9/05 © A Division of KW AUTOMOTIVE North America, Inc.
  • Page 8 6640-888 9/05 © A Division of KW AUTOMOTIVE North America, Inc.
  • Page 9 6640-888 9/05 © A Division of KW AUTOMOTIVE North America, Inc.
  • Page 10 6640-888 9/05 © A Division of KW AUTOMOTIVE North America, Inc.
