- Page 1 Installation GUIDE PART NUMBER: 15001 FRONT COILOVER KIT FORD F-150 2WD / 4WD | 2015-2020 -1” TO -3.5” HEIGHT ADJUSTABLE LOWERING 300 W. PONTIAC WAY. CLOVIS, CA 93612 PHONE: 800-445-3767 | EMAIL: INFO@BELLTECH.COM...
-
Page 2: Safety Information
Proper use of safety equipment and eye/face/hand protection is absolutely necessary when performing any of the following instructions. We strive for an exceptional experience for all our valued customers. If for any reason you need assistance with your Belltech products, please do not return the product to the store you purchased from, but rather call our dedicated customer service experts, from 7am to 5pm PST. -
Page 3: Installation Time
Technician note: Before making any adjustments to your new Belltech coilover, please be sure to loosen the set screw on the lower spring perch. Failure to do so will damage the threads. After the adjustments are made, you may then tighten the set screw to keep the settings in place. - Page 4 Never work under a vehicle supported only by a jack. It is necessary to place support stands securely under the vehicle in the manufacturer’s specified locations unless otherwise instructed. 15001-888 11/30/2022 AG REV A-02 A Division of KW AUTOMOTIVE North America, Inc.
- Page 5 10. Remove the upper nuts from the sway bar end links with a 8mm and 19mm wrench to detach the sway bar. 11. Remove the two 18mm nuts securing the lower strut mount to the control arm. 15001-888 11/30/2022 AG REV A-02...
- Page 6 16. To ease the installation of the new coilover, mark the position of the top mount in relationship to the upper spring isolator and strut body, then remove the strut from the chassis. 15001-888 11/30/2022 AG REV A-02 A Division of KW AUTOMOTIVE North America, Inc.
- Page 7 It is recommended to preset a higher “A” measurement and adjust down, clockwise, to the desired vehicle height once the coilover is installed. Belltech does not recommend lowering beyond what is advertised in the table above as the performance of the shock may be greatly decreased.
- Page 8 Belltech Coilover installation 22. Install the strut assembly into the chassis strut tower and secure using the three OE nuts. Torque to 52 ft lbs. 23. Attach the lower strut mount to the lower control arm using the supplied flanged nuts and bolts. Torque to 66 ft lbs.
- Page 9 Attach the lower control arms with the original hardware and torque to 258 ft lbs. Torque the control arms with the suspension loaded or with the weight of the vehicle resting on the wheels and tires, otherwise incorrect clamp load and bushing damage may occur. 15001-888 11/30/2022 AG REV A-02 A Division of KW AUTOMOTIVE North America, Inc.
-
Page 10: Finalizing The Installation
Belltech related merchandise for you and your vehicle belltechsuspension on our website www.belltech.com Belltech Suspension @belltechsuspension If you have any questions, concerns, or warranty related issues regarding your Belltech product, please call or email our experienced customer service specialists. Belltech Customer Support: Phone: 1-800-445-3767 Email: info@belltech.com... -
Page 11: Kit Contents
KIT CONTENTS 15001 25007-777 Hardware Kit Part number Description Part number Description 15001-100 BELLTECH COILOVER 112307 M14 FLANGED BOLT 68510039 SPANNER WRENCH 112308 M14 FLANGED NYLOC NUT 25007-777 HARDWARE KIT 15001-100 Part number Description 15001235 THREADED DAMPER NYLOC NUT M14X 1.50...
