- Page 1 Operating Instructions Memocheck Sim CYP03D Testing tool for analysis measuring points MEMO SENS BA481C/07/EN/13.11 71096536 valid from: Software version 0.03.13...
-
Page 3: Table Of Contents
Cleaning ......27 Battery replacement ....27 Calibration and requalification ..27 Endress+Hauser... -
Page 4: Safety Instructions
Safety instructions Designated use Memocheck Sim CYP03D is a testing tool for analysis measuring points. It enables the simulation of freely definable measured values and of errors in all sensors using Memosens technology. If the device is used for any purpose other than that described, this poses a threat to the safety of people and the entire measuring system and is thus not permitted. -
Page 5: Operational Safety
• Local standards and regulations Please note the technical data on the nameplate! Return Contact your regional Endress+Hauser sales or service representative to receive detailed shipping conditions. Contact details can be found at www.endress.com by selecting your region. Enclose the duly completed "Declaration of Contamination" (copy the second-last page of the Operating Instructions) with the packaging and shipping documents. -
Page 6: Identification
To establish the version of your device, enter the order code from the nameplate into the search field at the following address: www.products.endress.com/orderident Scope of delivery The delivery comprises: • Memocheck Sim CYP03D • Cable as per order • Operating Instructions Certificates and approvals Declaration of Conformity The product meets the requirements of harmonized European standards. -
Page 7: Device Description
Sensor simulation in a complete measuring system consists of: • Memocheck Sim CYP03D • Transmitter with Memosens technology • Memosens data cable CYK10 a0014717 Fig. 1: Measuring system with Memocheck Sim CYP03D Transmitter with Memosens technology, e.g. Liquiline CM442 Memosens data cable CYK10 Memocheck Sim CYP03D Endress+Hauser... -
Page 8: Operation
• Configuration of parameters and numerical values • Navigation through menu In simulation mode, the MINUS and PLUS keys have the following functions: • "Run through" of sim. main values, with each values being changed by the amount of the delta value Endress+Hauser... - Page 9 MINUS key and ENTER key Pressing the MINUS and ENTER keys simultaneously allows you to carry out a reset. PLUS key and ENTER key Pressing the PLUS and ENTER keys simultaneously allows you to reset the device to the factory settings. Endress+Hauser...
-
Page 10: Entering Numerical Values
To accept the changed value, highlight the check mark and press Switching on and off To switch on the device, press for at least 3 seconds. This loads the last setup that was saved. To switch off the device, press for at least 3 seconds. Endress+Hauser... -
Page 11: Menu Structure
Contrast Setup Simulation Parameter Memosens Fixed cable Sim. main value Test values Save setup Load setup Advanced Date Time Switch off auto. Advanced functions Calibration value Error simulation Ramp Diagnostics Diagnostic list Order code Serial number Software Switch off Endress+Hauser... -
Page 12: Quick Start
You can now simulate the selected parameter using the factory settings. Once you connect the Memocheck Sim CYP03D to a Memosens transmitter, the Memosens icon appears in the status line of the simulator . It indicates that the simulator is communicating with the transmitter. -
Page 13: Configuration: Setup
Set the number of minutes after which the device is 5 to 100 min automatically switched off. If the simulator is connected to a transmitter, this function is deactivated. In this case, the simulator does not switch off automatically. Endress+Hauser... -
Page 14: Selecting Parameters
In the "Setup/Save setup" menu, you can save up to 10 setups under the relevant parameter name. If you wish to use a saved setup, select it under the "Setup/Load setup" menu. Endress+Hauser... -
Page 15: Configuring Sim. Main Value And Test Values
• pH glass/pH glass SIL/pH ISFET: - pH value - Temperature - Raw value - Raw value temperature - SCS resistance (not for pH ISFET) • ORP: - ORP potential - ORP [%] - Temperature - Raw value - Raw value temperature Endress+Hauser... - Page 16 - Temperature - Raw value temperature - Slope • Turbidity: - Temperature - TU value [FNU] - TU value [g/l] - Raw value temperature • Nitrate: - NO content - NO N content - Temperature - Raw value temperature Endress+Hauser...
-
Page 17: Configuration: Advanced Functions
Calibration value • If you change a calibration value, there will be a brief interruption to communication between the Memocheck Sim CYP03D and the transmitter to allow the transmitter to accept the calibration settings. • An unfavorable configuration may result in measured values outside the specified measuring range. -
Page 18: Advanced Functions: Ph Glass/Ph Glass Sil
-750.0 to 750.0 mV -750.0 to 750.0 mV Raw value temperature -40.0 °C 150.0 °C -40.0 to 150.0 °C -40.0 to 150.0 °C SCS resistance 0.001 MOhm 1.0 TOhm 0.001 MOhm to 1.0 TOhm 0.001 MOhm to 1.0 TOhm Endress+Hauser... -
Page 19: Advanced Functions: Ph Isfet
150.0 °C -40.0 to 150.0 °C -40.0 to 150.0 °C Raw value -750.0 mV 750.0 mV -750.0 to 750.0 mV -750.0 to 750.0 mV Raw value temperature -40.0 °C 150.0 °C -40.0 to 150.0 °C -40.0 to 150.0 °C Endress+Hauser... -
Page 20: Advanced Functions: Orp
150.0 °C -40.0 to 150.0 °C -40.0 to 150.0 °C Raw value -1.5 V 1.5 V -1.5 to 1.5 V -1.5 to 1.5 V Raw value temperature -40.0 °C 150.0 °C -40.0 to 150.0 °C -40.0 to 150.0 °C Endress+Hauser... -
Page 21: Advanced Functions: Conductive/Toriodal
1.0 GOhm 0.001 mOhm to 1.0 GOhm 0.001 mOhm to 1.0 GOhm Raw value temperature -40.0 °C 150.0 °C -40.0 to 150.0 °C -40.0 to 150.0 °C Phase 0.0 ° 320.0 ° 0.0 to 320.0 ° 0.0 to 320.0 ° Endress+Hauser... -
Page 22: Advanced Functions: Oxygen Amperometric/Optical
0.0 to 20.0 mg/l 0.0 to 20.0 mg/l Current 0.0 pA 640.0 nA 0.0 pA to 640.0 nA 0.0 pA to 640.0 nA saturation 0.01 % sat 220.0 % sat 0.01 to 220.0 % sat 0.01 to 220.0 % sat Endress+Hauser... - Page 23 -40.0 °C 60.0 °C -40.0 to 60.0 °C -40.0 to 60.0 °C Raw value temperature -40.0 °C 60.0 °C -40.0 to 60.0 °C -40.0 to 60.0 °C Slope 0.0 % 200.0 % 0.0 to 200.0 % 0.0 to 200.0 % Endress+Hauser...
-
Page 24: Advanced Functions: Chlorine
-2.0 to 16.0 pH -2.0 to 16.0 pH Raw value current -1.5 μA 0.0 pA -1.5 μA to 0.0 pA -1.5 μA to 0.0 pA Raw value temperature -40.0 °C 150.0 °C -40.0 to 150.0 °C -40.0 to 150.0 °C Endress+Hauser... -
Page 25: Advanced Functions: Turbidity
10000.0 FNU 0.0 to 10000.0 FNU 0.0 to 10000.0 FNU TU value [g/l] 0.001 mg/l 1000 g/l 0.001 to 1000 g/l 0.001 to 1000 g/l Raw value temperature -40.0 °C 150.0 °C -40.0 to 150.0 °C -40.0 to 150.0 °C Endress+Hauser... -
Page 26: Advanced Functions: Nitrate
Raw value temperature -40.0 °C 150.0 °C -40.0 to 150.0 °C -40.0 to 150.0 °C Diagnostics Path: Menu/Diagnostics Function Info Diagnosis list The diagnostic messages provide information to Endress+Hauser service personnel. Order code CYP03D-xxx Serial no. xxxxxxxxxxx Software x.xx.xx Hardware x.xx.xx Reset Device is restarted. -
Page 27: Maintenance
Thanks to digital technology, it is not necessary to calibrate the device. The Memocheck Sim CYP03D can, with the quality certificate, also be used as a qualification tool for your measuring point. It may be sent to Endress+Hauser for requalification, see "Returns" section. The device is tested fully, and a new quality certificate is issued. -
Page 28: Technical Data
Weight (incl. batteries): 0.3 kg (0.7 lbs) 7.2.2 Battery For the Memocheck Sim CYP03D, use only the following battery types, as only these are covered by the Ex approval: • Duracell batteries, MN1500 (AA, 1.5 V, LR6 as per IEC), x 3 •... -
Page 29: Index
Serial number ......6 pH ISFET ......19 Endress+Hauser... - Page 30 Setup ....... . . 13 Sim main value ......15 Simulation mode.
- Page 31 Declaration of Hazardous Material and De-Contamination Please reference the Return Authorization Number (RA#), obtained from Endress+Hauser, on all paperwork and RA No. mark the RA# clearly on the outside of the box. If this procedure is not followed, it may result in the refusal of the package at our facility.
- Page 32 BA481C/07/EN/13.11 FM+SGML 6.0...
