Novita A4G Quick Starter Manual

A4G
NON WI-FI VERSION
Ensure that the power plug is disconnected from the power supply at all times during installation, maintenance and transportation.
• DO NOT operate the unit without filter unit installed. Please remove the plastic packaging on the 3-In-1 filter and humidifying filter and insert them in the correct
sequence before use.
• The front panel, air outlet grille and water tank must be properly assembled for the unit to be operational.
• SETTING UP
STEP Remove all packaging materials and place the unit on a dry,
stable and level surface.
Remove the plastic packaging on the 3-In-1 filter
STEP
and place it into the unit with cool catalyst filter as
the outermost layer while 99.97% true HEPA filter
as the innermost layer. Reattach the washable
mesh filter.
STEP Grasp the water tank handle, slide outwards to
remove it.Remove the plastic packaging on the
humidifying filter and place it back into its
designated compartment.
Proceed to place back the water tank refill rubber lid, align, slot
STEP
and slide the water tank back into the unit. Ensure the water
tank is securely installed and locked in position.
• OPERATING NOTES
STEP
STANDBY MODE
Insert the power plug into the power supply and power on.
When unit is at standby mode, the
illuminates in red.
STEP
INITIALIZATION
The FIR PM2.5 Particle Sensor will take a minute for
initialization, During the initializing process, the PM2.5 display
will show "- -". Once completed, the moving average FIR PM
2.5 readings (unit: µg/m
and the air quality sensor light indicator will illuminate in
different colours, in accordance to the air quality detected.
• The FIR PM2.5 Particle Sensor detection accuracy is subjected to a
yearly depreciation rate of 10% to 20%. For optimum air quality
detection, it is recommended to perform factory calibration to the
air quality sensor once every 2 years.
4-IN-1 AIR PURIFIER
QUICK STARTER GUIDE
ON/OFF button
) will be reflected on the LCD screen
3
Grasp both recess sides of the front panel casing and pull
STEP
outwards to remove it. Proceed to remove the humidifying
filter placed underneath the front panel casing and safekeep it
for replacement in 12 months' time. Next, remove the
washable mesh filter.
Align the grooves at the bottom of the front panel casing into
STEP
the unit and close it towards the magnetic catch securely.
04
• The front panel, air outlet grille and water tank must be properly
assembled for the unit to be operational.
Open the water tank refill rubber lid, and fill the water tank with
STEP
clean tap water. It is recommended to fill the unit with 1 litre of
tap water (maximum 80% in height) for optimum unit
performance.
• It is recommended to replace with fresh tap water daily.
• DO NOT use chemical agents, other aromatic substances (unless
otherwise stated) or aggressive solvent.
Ensure there is clearance of at least 50 cm for air inlets at both
STEP
sides of the unit and clearance of at least 10 cm for the back of
the unit.
• DO NOT block the air inlets and outlets to ensure sufficient
air ventilation and maximum efficiency of the unit.
STEP
POWER ON/OFF
Touch the ON/OFF once to switch on the unit. When unit is
at on mode, the ON/OFF illuminates in green and operates
in auto mode by default and its corresponding light indicator
illuminates.
STEP
AUTO MODE
Touch the button once to activate the auto mode and its
corresponding button illuminates. At auto mode, fan speed
setting will be automatically adjusted in accordance to the air
quality detected. Both anion mode
lamp will be activated by default and its corresponding
indicator illuminates.
PM2.5 Count (µg/m³) AIR QUALITY SENSOR LIGHT COLOUR
0 to 50
51 to 80
81 to 100
101 to 120
121 to 140
141 to 160
161 to 300
300 to 500
• When user selects fan speed under auto mode, unit will deactivate
auto mode automatically.
• Both the built-in ionizer and germicidal ultraviolet lamp are
semi-permanent.
and germicidal ultraviolet
FAN SPEED SETTING
Green
Blue
Yellow
Red
