Novita ND60+ Operating Instructions And E-Warranty Application

2-in-1dehumidifier + air purifier

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

2-IN-1

DEHUMIDIFIER

+ AIR PURIFIER

ND60

THE HIGHEST CAPACITY

CONSUMER UNIT

PRODUCT FEATURES

SEMI-

AUTO

PERMANENT

HUMIDITY

BUILT-IN IONIZER

SENSOR

H13

SLEEP

HEPA

MODE

FILTRATION

AUTO-SHUT OFF

WITH FULL TANK

INDICATOR

REGULATE

HUMIDITY

LEVELS

OPERATING INSTRUCTIONS AND E-WARRANTY APPLICATION

Please read instructions before using the Dehumidiﬁer

PREFERRED

LAUNDRY

HUMIDITY

DRYING

SETTINGS

MODE

TIMER

ROTARY

COMPRESSOR

CONTINUOUS

FILTER

DRAINAGE

LIFESPAN

OPTION

INDICATOR

DEHUMIDIFY

EXCESSIVE

MOISTURE

UP TO 20 MILLION

NEGATIVE IONS / CM³

SINGAPORE'S

HIGHEST

capacity consumer

dehumidiﬁer at

DRYING

PURIFY

EFFECTIVE INDOOR

H13 HEPA & HI-PERFORMANCE

LAUNDRY DRYING

CARBONPLUS FILTER

IMPR

VED

& ENHANCED

WITH H13 HEPA &

HI-PERFORMANCE CARBONPLUS

For Optimum Smoke & Odor

Removal Efﬁciency

TEN YEARS

WARRANTY

COVERAGE

ℓ

/day

IONIZE

REFRESHING

INDOOR AIR

Table of Contents

Need help?

Do you have a question about the ND60+ and is the answer not in the manual?

Questions and answers

Summary of Contents for Novita ND60+

Page 1 IMPR & ENHANCED 2-IN-1 WITH H13 HEPA & HI-PERFORMANCE CARBONPLUS DEHUMIDIFIER For Optimum Smoke & Odor Removal Efﬁciency + AIR PURIFIER ND60 UP TO 20 MILLION UP TO 20 MILLION NEGATIVE IONS / CM³ NEGATIVE IONS / CM³ THE HIGHEST CAPACITY CONSUMER UNIT PRODUCT FEATURES SEMI-...
Page 2: Table Of Contents
LIMITED WARRANTY TERMS & CONDITIONS This product includes: • novita 2-In-1 Dehumidifier + Air Purifier ND60+ • novita 2-In-1 Dehumidifier + Air Purifier ND60+ Operating Instructions & e-Warranty Application (e-copy) • Starter Guide • 1 x 2 Metres PE Hose (16 mm inner diameter) •...
Page 3: Product Description
PRODUCT DESCRIPTION 2-In-1 Dehumidifier + Air Purifier ND60+ FRONT VIEW BACK VIEW Semi-Permanent Water Level Indicator Rear Panel Casing Built-In Ionizer Water Tank Groove Continuous Drainage Air Outlet Oscillation Flap Outlet Port 2-In-1 Air Inlet Frame Control Panel & Pre-Filter Screen Cord Holder Carrying Handle H13 HEPA &...
Page 4: Technical Specifications
TECHNICAL SPECIFICATIONS 220-240V~50Hz Voltage / Frequency 700 Watts Power Consumption (27℃/60%RH) 1010 Watts Max. Power (35°C/80%RH) Extraction Rate (30°C/80%RH) 45L/Day • H13 HEPA & Hi-Performance CarbonPlus Filter • Hi-Performance CarbonPlus Filter (alternative) 60L/Day Available Humidity Setting Auto Humidity Sensor Available Operating Temperature 5°C-35°C Compressor...
Page 5: Filtration System
FILTRATION SYSTEM STEP STEP STEP STEP STEP 2A-1 2A-2 PRE-FILTER FILTER TYPE 2A-1: FILTER TYPE 2A-2: FILTER TYPE 2B: BUILT-IN IONIZER SCREEN HEPA FILTER HI-PERFORMANCE HI-PERFORMANCE ◊ (SEMI-PERMANENT) CARBONPLUS FILTER CARBONPLUS FILTER ◊ ◊ LEGEND ALLERGENS COARSE DUST HAIR SCURF FINE DUST POLLEN PET DANDER...
Page 6: Features
FEATURES Laundry Drying Mode Besides functioning as portable dehumidifier to safeguard your valuables from moisture and mold, ND60+ also doubles up as an effective laundry drying device. DRYING - EFFECTIVE INDOOR LAUNDRY DRYING Moisture from the damp garment will be drawn into the unit and condensed into water droplets. Warm air is simultaneously produced from the air outlet to speed up the drying process.
Page 7: Humidity Setting Control
Humidity Setting Control User can set the humidity level according to individual’s desire within a range of 30% to 80% RH at an interval of 5% RH or Continuous Dehumidification Mode. Selected RH% level will be displayed on the display screen. •...
Page 8: Sleep Mode
Sleep Mode Unit is programmed with a sleep mode function whereby upon activation, all the light indicators on the control panel stops illuminating after 10 seconds and low fan speed will be activated for an undisturbed operation. To wake the unit up, simply press any button, then select your desired operating setting. Timer Function At On Mode, the unit can be programmed with a timer from 01 to 24 hours at an interval of 1 hour for an automatic shutoff.
Page 9: Defrost Mode
Defrost Mode Defrost Mode will be activated automatically with “F” shown on the display screen when room temperature drops to 4 C and below. The compressor stops operation and unit runs of high fan speed setting until the defrosting process is completed. Auto-Shut Off with Full Tank Indicator Unit shuts off automatically with full water tank indicator illuminates and unit beeps 5 times in following...
Page 10: Continuous Drainage Option
Continuous Drainage Option Side View Continuous Drainage Outlet Port Rubber Plug Obstruction-Free Drainage Pipe Stable & Level Surface Continuous drainage option allows easy removal of collected water instead of manually empty from the water tank. Using the continuous drainage option: 01.
Page 11: Using The Unit
USING THE UNIT Ensure that the power plug is disconnected from the power supply at all times during installation, maintenance and transportation. • DO NOT operate the unit without filter unit installed. • Please remove the plastic packaging on the filter unit before usage. Remove all packaging materials and...
Page 12: Operating Notes
Operating Notes 01. Dehumidifying mode/ Laundry Drying mode/ Sleep mode Dehumidifying mode By default, unit runs on manual continuous dehumidifying mode. Laundry Drying mode Press the to select the laundry drying mode and its corresponding indicator illuminates. At this mode, the unit works in continuous dehumidification (CO), high fan speed for 6 hours timer. Once the cycle is completed, unit will switch off automatically.
Page 13: Emptying The Water Tank
RH% setting when the power is restored. Emptying the Water Tank novita Dehumidifier ND60+ shut off automatically when the water tank is full and unit beeps 5 times with indicator illuminating. Follow the simple steps below to empty the water tank.
Page 14: Replacing Filter
Filter Lifespan Prompt Indicator When the Unit Filter lifespan is coming due, the Filter lifespan indicator will prompt to allow ample time to prepare for Filter replacement. INDICATOR REMAINING LIFE REMINDER ACTION Blink 3 times with 1 Beep Standby New Last 14 days sound every 60 mins.
Page 15: Cleaning & Maintenance
CLEANING & MAINTENANCE Cleaning the novita Dehumidifier + Air Purifier The 2-In-1 ND60+ It is important to conduct service maintenance of the unit at least once a week to ensure unit optimum performance and to prevent dust/dirt built up at the continuous drainage outlet port and water float sensor, which may lead to water leakage.
Page 16 Removal of the product terms of use sticker pasted on the unit will be the acceptance and agreement to the terms. • All information is accurate at the point of print. novita reserves all rights to update the information without prior notice.
Page 17: Troubleshooting
• Remove water tank and re-assemble it into the unit again. • Power plug or cord damaged. • Contact novita Customer Care Centre. Fan not working. • The desired RH% setting is achieved. • Set the desired RH% lower than the surrounding humidity level.
Page 18 • Internal drainage passage is blocked or • Contact novita Customer Care Centre. obstructed. Display screen • The ambient humidity is lower than 30% RH.
Page 19: Safety Precautions
SAFETY PRECAUTIONS DO NOT pull or tug the unit by Keep the unit away from Refrain from placing the Servicing should only be the power cord to prevent flammable liquids. dehumidifier in confined closets. conducted by professional safety hazards or damage to service technicians.
Page 20: Novita Customer Service Guarantee
Service Trekking* With everyone’s busy schedule, it’s sometimes hard to keep track of everything. Sit back, relax and leave the fussing to us. Instead of calling and checking up on the status of your product, let novita keeps you updated.
Page 21: Limited Warranty Terms & Conditions
negligence.
Page 22 T & C Updates Commission/Effective from 20 Nov 2024 • All Information is accurate at the point of print. novita reserves all rights to update the information without prior notice.
