A5.
AIR PURIFIER
• SETTING UP
01. Remove all packaging materials and place the unit on a dry, stable and level surface.
02. Grasp both recess sides of the air inlet panel and pull outwards to remove it from the unit.
03. Remove the plastic packaging on the 3-in-1 PuriPRO
carbon filter as the outermost layer while H13 HEPA filter as the innermost layer.
• Ensure the tag on the PuriPRO
• Ensure the PuriPRO
®
filter unit is properly assembled and installed in position before usage.
04. Align the air inlet panel upper middle latch to the designated catch on the unit's internal housing.
Press both the upper left and right corners followed by both the bottom left and right corners of
the air inlet panel to lock and secure it in position.
05. Ensure there is a clearance of at least 50 cm for the air inlet and clearance of at least 10 cm for the air outlet.
• DO NOT block the air inlet and air outlet to ensure sufficient air ventilation and maximum efficiency of the unit.
• OPERATING NOTES
STANDBY MODE
01.
Insert the power plug into the power supply and power on. Unit beeps once and the display screen illuminates and flashes once. At Off Mode, the
ON/OFF button illuminates in red.
POWER ON/OFF
02.
Touch the
POWER ON/OFF button to switch on the unit. Unit operates in auto mode with air quality light indicator illuminating in green by default.
• While operating the unit, in the event if there is any power trip, the unit will auto resume its operation based on the last preceding setting, when the power is restored.
PM2.5 SENSOR INITIALIZATION
03.
The FIR PM2.5 Particle Sensor will take 10 seconds for initialization. During the initializing process, the PM2.5 display will show " – " and loop in a clockwise direction
with air quality sensor light indicator illuminating in green.
UNIT DISPLAY SCREEN
Once completed, the moving average FIR PM 2.5 readings (unit: µg/m³) will be reflected on the display screen and the air quality sensor light indicator will illuminate
in different colours, in accordance to the air quality detected.
• The FIR PM2.5 Particle Sensor detection accuracy is subjected to a yearly depreciation rate of 10% to 20%. For optimum air quality detection, it is recommended
to perform factory calibration to the air quality sensor once every 2 years.
FAN SPEED
04.
Touch the
SPEED button to select auto mode, speed 1, 2, 3 or sleep mode. Its corresponding light indicator illuminates on the selected setting.
AUTO MODE
05.
Touch the
SPEED button consecutively to select auto mode. Upon activation, its corresponding light indicator A illuminates. At auto mode, the fan
speed setting will automatically adjust in accordance to the air quality detected.
Air Quality Light
Air Quality Indication
Fan Speed Setting
SLEEP MODE
06.
Touch the
SPEED button consecutively to select sleep mode. Upon activation, display screen will prompt "SLP" and its corresponding light indicator
illuminates. At sleep mode, air flow is reduced to the lowest and after 5 seconds, all light indicators will be turned off for an undisturbed rest.
To wake the unit, touch any button on the control panel. When the light indicators illuminate (3 seconds), touch
• When the unit is left idle for 3 seconds, it will auto resume sleep mode function.
• At sleep mode, when childlock function is activated, the display screen will prompt "LOC" whenever the user touches the control panel. To deactivate the childlock function,
touch and hold the
POWER ON/OFF and
CHILDLOCK
07.
Touch and hold both
POWER ON/OFF and
the control panel will be locked and display screen prompts "LOC" whenever user touches the control panel. To unlock, touch and hold both
SPEED buttons for 3 seconds.
novita.com.sg
QUICK STARTER GUIDE
Ensure that the power plug is disconnected from the power supply at all
times during installation, maintenance and transportation.
• DO NOT operate the unit without filter unit installed. Please remove the plastic
packaging on the filter unit and insert them in the correct sequence before use.
filter and place it into the unit with granular activated
®
filter is facing the filter cover.
®
Blue
Green
Excellent
Good
Speed 1
Speed 2
SPEED buttons position for 3 seconds.
SPEED buttons for 3 seconds to activate childlock function and display screen will prompt "LOC". Upon activation,
Red
Poor
Speed 3
SPEED button to exit sleep mode.
SCAN THE QR CODE
to view the user manual
for full operating instructions
04
1
"CLICK"
Catch
Latch
3
"CLICK"
POWER
POWER ON/OFF and
