Floor Standing Type
Air Conditioner
OWNER'S
MANUAL
Before using your air conditioner please read this
manual carefully and keep it for future reference.
MODEL: PT Chassis
Prior to installation, this air-conditioning unit
must be submitted for approval by the utility
service which provides electricity (EN 61000-3
Norm).
Advertisement
Related Manuals for LG PT Chassis
Summary of Contents for LG PT Chassis
- Page 1 MANUAL Before using your air conditioner please read this manual carefully and keep it for future reference. MODEL: PT Chassis Prior to installation, this air-conditioning unit must be submitted for approval by the utility service which provides electricity (EN 61000-3...
-
Page 2: Table Of Contents
Safety precautions Safety Precautions To prevent injury to the user or other people and property damage, the Warning ........2 following instructions must be followed. Caution .........4 Incorrect operation due to ignoring of instruction will cause harm or damage, the seriousness is classified by the following indications. Operating Instructions WARNING Features and Specifications..6... - Page 3 WARNING WARNING Do not connect grounding wires to a window Do not place objects around an outdoor sash or a tap. device for children to stand on it. • Otherwise, it may cause electrical shock. • Children may fall down outside. Do not open air intake hole of indoor/outdoor Do not randomly disassemble or modify the devices during operation.
-
Page 4: Caution
CAUTION • Contact the authorized Service technician for repair or maintenance of this unit. • Contact the installer for installation of this unit. • The air conditioner is not intended for use by young children or infirm persons without supervision. •... - Page 5 CAUTION CAUTION Do not install the product at a bathroom, a Avoid excessive cooling and execute location disclosed to rains or winds or a ventilation once or twice times for two hours place where water splashes. during long-term use. • There is concern of electrical shock, fire or •...
-
Page 6: Features And Specifications
Features and Specifications Features Design for cooling and 2 cooling/heating speeds heating Removable air filter Super energy efficiency Anti-Bacteria filter Micom control 3 minutes delay circuit Whisper quiet operation Wireless remote control Specifications Air Outlet Vent Air Intake Vent (Rear) Remote Signal Receptor Air Outlet... -
Page 7: Indoor Unit Controls And Indicators
Indoor Unit Controls and Indicators Display (Heat Pump Model) (Cooling Model) START/STOP BUTTON AUTO OPERATION LAMP Operation starts when this button is pressed and stops when the button is OFF TIMER OPERATION LAMP pressed again. AUTO AIR FLOW OPERATION OPERATION MODE SELECTION BUTTON LAMP Used to select the operation Mode. -
Page 8: Name And Function-Remote Control
Name and Function-Remote Control Control Signal Transmitter • Transmits the signals to the floor standing type air conditioner Operation Display of the Remote Control Indoor Fan Speed Selection Button • To select the desired fan speed in two steps [Low, High] Cooling ON Button Temperature Setting Buttons Power ON/OFF Button... -
Page 9: Remote Control Preparation
Remote Control Preparation How to mount onto a wall Use the screws to secure the holder to the wall or attach the holder side of indoor unit. To insert the remote control to the holder. Insert Pull How to insert batteries •... -
Page 10: Air Conditioner Operation
Air conditioner operation How to use the Operation Mode Button • Each time the Operation Mode Selection Button is pressed, the Operation Mode is shifted in the arrow direction. Cooling Operation Soft Dry Operation Heating Operation (Heat pump Model) Auto Operation Soft Dry Operation Cooling Operation (Cooling Model) - Page 11 Cooling Operation Mode Press the Start/Stop Button. Select Cooling Operation. Press the Operation Mode Selection Button. Press the Cooling Operation Button on the remote controller. Set the temperature lower than the room temperature. The temperature can be set within a range of 16°C~30°C by 1°C. To raise the temperature To lower the temperature Set the Fan Speed.
-
Page 12: Soft Dry Operation
Soft Dry Operation Press the Start/Stop Button. Select Soft Dry Operation. Press the Operation Mode Selection Button. Press the Soft Dry Operation Button on the remote controller. Set the temperature lower than the room temperature. The temperature can be set within a range of 16°C~30°C by 1°C. To raise the temperature To lower the temperature During softy Dry Operation... - Page 13 Heating Operation Mode(Heat Pump Model) Press the Start/Stop Button. Select heating Operation. Press the Operation Mode Selection Button. Press the heating Operation Button on the remote controller. Set the temperature upper than the room temperature. The temperature can be set within a range of 16°C~30°C by 1°C. To raise the temperature To lower the temperature Set the Fan Speed.
- Page 14 Auto Operation Mode(Cooling Model Only) Press the Start/Stop Button. Select Auto Operation. Press the Operation Mode Selection Button. Press Auto Operation Button. Set the temperature upper or lower than the standard temperature. The temperature can be set within a range of by 1 level.
-
Page 15: Fan Operation Mode
Fan Operation Mode Press Fan Operation Button. Press the Start/Stop Button. Set the Fan Speed. Each time the Button is pressed, the Fan Speed mode is shifted. Airflow Direction Procedure Press the Start/Stop Button. Press the Auto Swing Button and then louvers will swing left and right. - Page 16 OFF Timer Setting Procedure(OFF TIMER Setting, or CANCEL) Press the Start/Stop Button. Select Function. Press the Timer Button. • If you press the button, the selected off timer is displayed as follows; • If you select ‘ ’, the Off Timer function will be cancelled. When you finish the Off Timer setting, the Timer indicator lights off.
- Page 17 Child Lock Operation Procedure Press the fan speed button and high temperature setting buttons simultaneously for 3 seconds. The unit will respond with beep. After 3 second, After 3 seconds, it will shift it will shift During Child Lock Operation Whenever you press any Button on Display Panel, it will immediately display “...
-
Page 18: Care And Maintenance
Care and Maintenance CAUTION: Before performing any maintenance, turn off the main power to the system. During the season Cleaning of the air filters. Recommended about once every two weeks Remove the Air Filter. Clean. Take hold of the tab and pull slightly •... -
Page 19: When The Air Conditioner Is Not Going To Be Used For A Long Time
When the air conditioner is not going to be used for a long time. At the start of the season At the end of the season Operate the air conditioner at the Clean the air filters, re-insert, then following settings for 2 to 3 hours. operate the air conditioner. -
Page 20: Before You Call For Service
Before you call for service... Troubleshooting Tips! Save time and money! Check the following points before requesting repairs or service..If the fault persists, please contact your dealer or service center. Case Explanation See page Does not operate. • Have you made a mistake in timer operation? •... -
Page 21: Service Centers
Details of LG serial No. 9 10 Code Detail Code of Model Meaning Year The last digit of year (Digit) ex) 1997 7, 2000 Month 01~12 Month (Digit) ex) March 03, August Nation Where manufactured (Alphabet) ex) K Korea, C... - Page 22 NOTE...
- Page 23 P/No.: 3828A30069M Printed in Korea...
