Sharp MX-M654N Installation Manual
Sharp MX-M654N Installation Manual

Sharp MX-M654N Installation Manual

Digital multifunctional system
Hide thumbs Also See for MX-M654N:

Advertisement

Quick Links

: '15/Feb
2
[1] MX-M654N/M754N (MAIN UNIT) . . . . . . . . . . . . . . 1-1
[2] Dehumidifying heater kit . . . . . . . . . . . . . . . . . . . . . 2-1
[3] MX-LC15 (LARGE CAPACITY TRAY). . . . . . . . . . . 3-1
[4] MX-LC16 (LARGE CAPACITY TRAY). . . . . . . . . . . 4-1
[6] MX-TR16 (EXIT TRAY UNIT) . . . . . . . . . . . . . . . . . 6-1
[7] MX-TU15 (EXIT TRAY CABINET). . . . . . . . . . . . . . 7-1
[8] MX-RB23 (PAPER PASS UNIT) . . . . . . . . . . . . . . . 8-1
[9] MX-FN19 (FINISHER). . . . . . . . . . . . . . . . . . . . . . . 9-1
[11] MX-PN12A/B/C/D (PUNCH MODULE) . . . . . . . . . 11-1
[13] MX-CF11 (INSERTER) . . . . . . . . . . . . . . . . . . . . . 13-1
[14] MX-RB13 (RELAY UNIT) . . . . . . . . . . . . . . . . . . . 14-1
[15] MX-FD10 (FOLDING UNIT) . . . . . . . . . . . . . . . . . 15-1
(FINISHER/SADDLE STICH FINISHER) . . . . . . . 16-1
[17] MX-PN13A/B/C/D (PUNCH MODULE) . . . . . . . . . 17-1
[18] MX-TM10 (TRIMMING MODULE). . . . . . . . . . . . . 18-1
[19] MX-RB24 (PAPER PASS UNIT),
2
MX-FN17 (INNER FINISHER). . . . . . . . . . . . . . . . 19-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with
specified ones for maintaining the safety and performance of the set.
INSTALLATION MANUAL
DIGITAL
MULTIFUNCTIONAL SYSTEM
MX-M654N
MODEL
CONTENTS
[20] MX-PUX1 (XPS EXPANSION KIT). . . . . . . . . . . . . 20-1
[21] MX-PF10 (BARCODE FONT KIT) . . . . . . . . . . . . . 21-1
[23] AR-SU1 (STAMP UNIT) . . . . . . . . . . . . . . . . . . . . . 23-1
[25] MX-EB12 N (MIRRORING KIT) . . . . . . . . . . . . . . . 25-1
[27] IC card reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-1
[28] MX-KB13 (KEYBOARD). . . . . . . . . . . . . . . . . . . . . 28-1
SHARP CORPORATION
CODE: 00ZMXM754/I6E
(APPLICATION INTEGRATION MODULE) . . . . . . 29-1
(APPLICATION COMMUNICATION MODULE) . . . 30-1
(WEB BROWSING EXPANSION KIT) . . . . . . . . . . 32-1
setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33-1
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MX-M654N and is the answer not in the manual?

Questions and answers

todd matherne
March 27, 2025

what kind of power outlet do i need? 120v or 220v?

1 comments:
Mr. Anderson
March 27, 2025

The Sharp MX-M654N requires a 220V power outlet, as indicated by the reference to the "AC power line diagram (200V series)" in the context.

This answer is automatically generated

Summary of Contents for Sharp MX-M654N

  • Page 1: Table Of Contents

    Transit, Installation (using) environment, Note Configuration [1] MX-M654N/M754N (MAIN UNIT) ....1-1 [20] MX-PUX1 (XPS EXPANSION KIT)... . . 20-1 [2] Dehumidifying heater kit .
  • Page 2 [18] MX-TM10 (TRIMMING MODULE) MX-M654N/M754N (MAIN UNIT) 1. Unpacking ........1-1 1.
  • Page 3 CONTENTS [32] MX-AM10 (WEB BROWSING EXPANSION KIT) 1. Unpacking ....... . . 32-1 2.
  • Page 4: Transit, Installation (Using) Environment, Note

    MX-M754N Transit, Installation (using) environment, Note Service Manual 1. Installing (use) conditions (3) Power frequency, waveform The frequency must be within the range of the specified frequency Before installing the machine, check that the following installing ±2%,If power waveform is deformed, a trouble may occur. (use) conditions are satisfied.
  • Page 5: Direct Sunlight

    F. Note for handling PWB and electronic parts Humidity RH When handling the PWB and the electronic parts, be sure to observe the following precautions in order to prevent against dam- age by static electricity. * When in transit or storing, put the parts in an anti-static bag or an anti-static case and do not touch them with bare hands.
  • Page 6: Transit And Delivery

    G. Note for proper drum, developing, fusing and transfer unit handling When handling the OPC drum, developing and transfer units, observe the following items. Drum unit * To prevent damage to the OPC drum, avoid working on the drum unit in high intensity light areas. * When the OPC drum is removed from the machine, cover it with light blocking material.
  • Page 7: Configuration

    Service Manual CONFIGURATION 1. System diagram MX-FN19 MX-PN12 A/B/C/D MX-TR16 MX-FN20 MX-TU15 MX-RB13 MX-LT10 MX-PN13 MX-FN21 MX-RB23 A/B/C/D MX-CF11 MX-LC15 MX-RB15 MX-M654N MX-M754N MX-FD10 MX-TM10 MX-LC16 MX-FN22 MX-PUX1 MX-PF10 MX-FX11 MX-FR47U MX-FR47 AR-SU1 MX-FWX1 MX-USX1 MX-USX5 MX-US10 MX-US50 MX-USA0 MX-EC50...
  • Page 8: Option List

    MX-AMX2 APPLICATION COMMUNICATION MODULE Standard for North America. MX-AMX3 EXTERNAL ACCOUNT MODULE MX-UN01A Sharp OSA Network Scanner Tool 1 License Kit MX-UN05A Sharp OSA Network Scanner Tool 5 License Kit MX-UN10A Sharp OSA Network Scanner Tool 10 License Kit MX-UN50A...
  • Page 9: Mx-M654N/M754N (Main Unit)

    Attach the Power supply careful label to the back of cabinet C. Included parts check Check to confirm that all the parts are provided. Name Quantity Height adjuster plate NOTE: choose a linguistic label according to the area. MX-M754N MX-M654N/M754N (MAIN UNIT) 1 – 1...
  • Page 10 Power supply careful label EU-F Hungarian/Greek Power supply careful label EU-G Turkish/Slovak Power supply careful label EU-H Latvian/Romanian Power supply careful label EU-I Slovene/Croatian Power supply careful label EU-J Estonian/Lithuanian Power supply careful label EU-K Bulgarian MX-M754N MX-M654N/M754N (MAIN UNIT) 1 – 2...
  • Page 11 Loosen the screw and remove the cover. D. Fusing heat roller pressure Pull the knob on the right door to pull out the right door. Loosen the screw and pull out the developing unit. MX-M754N MX-M654N/M754N (MAIN UNIT) 1 – 3...
  • Page 12 Open the right cover. Install the cover and fix it with screws. Check to confirm that toner collection container is securely installed. Insert developing unit to the main unit and fix it with screw. MX-M754N MX-M654N/M754N (MAIN UNIT) 1 – 4...
  • Page 13: Toner Cartridge Installation

    Push down the paper feed base plate gently, hold the hooks completion of the setting operation. and remove A4 size regulation plate. H. Toner cartridge installation Open the front cover. Install the toner cartridge then close the front cover. MX-M754N MX-M654N/M754N (MAIN UNIT) 1 – 5...
  • Page 14 Remove the screw, and remove the mylar sheet. Change the installing direction and install with screws. (2 positions) Push down the paper feed base plate of the tray 2 gently, hold the hooks and remove A4 size regulation plate. Remove the sheet. MX-M754N MX-M654N/M754N (MAIN UNIT) 1 – 6...
  • Page 15 A and B are slidable. Slide each guide plate while squeezing its lock lever. MX-M754N MX-M654N/M754N (MAIN UNIT) 1 – 7...
  • Page 16: Specifications Setup

    Press [EXECUTE] button. The high density process control is performed, and the copy gray patch image (adjustment pattern) is printed out. (A4/11" x 8.5" or A3/11" x 17" paper is automatically selected.) High density density MX-M754N MX-M654N/M754N (MAIN UNIT) 1 – 8...
  • Page 17 Troubleshoot the cause, repair or perform necessary works, and repeat the adjustment from the beginning. MX-M754N MX-M654N/M754N (MAIN UNIT) 1 – 9...
  • Page 18: Dehumidifying Heater Kit

    : ‘14/Dec : ‘16/Apr [2] Dehumidifying heater kit MX-M754N Service Manual Parts list Kit name Kit part code Parts name Part code Q'ty Heater electric DKIT-0444FCZZ (100V series) Dehumidifier heater switch QSW-C9294QCZZ component kit Label for heater switch TLABZ5256FCZZ DKIT-0445FCZZ (200V series) Supporter LSUPP0140FCPZ WH PWB...
  • Page 19 Kit name Kit part code Parts name Part code Q'ty LCC (A3) heater kit DKIT-0452FCZZ (100V series) Heater harness (100V series) DHAI-5506FCPZ Heater harness (200V series) DHAI-5507FCPZ DKIT-0452FC11 (200V series) Snap band LBNDJ0043FCP1 AC cord fixer LFIX-0016FCZZ Heater cover PCOVP1942FCZZ Heater sheet PSHEZ5482FCZZ Connector cover A...
  • Page 20 : ‘14/Dec Installation Remove the screw, and remove the left cabinet lower. NOTE: Before installation, be sure to turn both the operation and main power switches off and disconnect the power plug from the power outlet. Make double sure that the data lamp on the operation panel does not light up or blink when per- forming installation.
  • Page 21 (2) Attach the WH PWB Fix the snap band to the frame. Insert the supporter to the frame of the power unit, and attach the WH PWB on it. NOTE: Be careful not to break the PWB when mounting the PWB to the supporters.
  • Page 22 C. Installation of the scanner heater kit Attach the clamp to the scanner frame. (1) Assembling of the scanner heater unit NOTE: When installing, be careful to prevent damage of the wire. Secure the marking position on the harness of the scanner heater to the heater fixing plate with the banding band.
  • Page 23 D. Installation of the tandem heater kit Tighten the loose scanner heater harness by pulling it in the arrow direction and secure it with the snap band then cut its tip (1) Assembling of the tandem heater unit to approx. 5 mm or less. Affix the heater harness sheet onto the heater mount plate.
  • Page 24 : ‘16/Apr E. Installation of the cassette heater kit (R) Attach the step screw (M3) and edge holder to the frame. Put the tandem heater unit on the step screw (M3) and fix it (1) Assembling of the cassette heater with the tight screw (M4 x 6 S-tight).
  • Page 25 Pass the heater harness through the hole on the rear frame, Affix the heater harness onto the heater cover. and fix by the snap band to the frame. Attach the heater mount plate to the heater cover, and fix by the screw (M3 x 8 S-tight).
  • Page 26 Remove the harness front the wire saddle. H. Installation of the LCC (A4) heater kit Connect the connector of heater harness and WH harness. (1) Paper feed unit removal Pull out the paper feed tray. Open the cover. Remove the cover and the screws. Open the screw.
  • Page 27 (2) Heater attachment Disconnect the connector. Attach the heater and fix it by the screw. Attach the connector to the frame, and fix the snap band. EX200 Remove the paper feed unit. Attach the protect sheet. 75 5mm 0 2mm Remove the screw and the heater cover.
  • Page 28 Connect the connector of the heater harness unit. Attach the Attach the paper feed unit and fix it with the screw. earth wire, and fix by the screw. NOTE: Attach the earth wire at an angle of 45 degrees. EX200 Connect the connector.
  • Page 29: Connector Connection

    (5) Connector connection Remove the upper cover. Remove the screw, and remove the connector cover. Disconnect the connector. Connect the connector and tighten the screw. Remove the screw and the paper feed unit. I. Installation of the LCC (A3) heater kit (1) Paper feed unit removal Pull out the paper feed tray.
  • Page 30 Attach the protect sheet. (5) Heater cover and heater sheet attachment Attach the heater connector cover with the screws (M4 x 8). 80mm 80mm (4) Heater harness unit attachment Attach the heater cover. Attach the snap band of the heater harness unit and fix it with the screw.
  • Page 31 (7) Paper feed unit attachment (8) Connector connection Attach the paper feed unit and fix it with the screw. Remove the screw and the connector cover. Connect the connector and tighten the screw. Connect the connector. J. Operation check after installation Turn on the dehumidifier heater switch.
  • Page 32: Mx-Lc15 (Large Capacity Tray)

    [3] MX-LC15 (LARGE CAPACITY TRAY) MX-M754N Service Manual Unpacking Remove the right door cover from the machine.. A. Packed items check Remove the fixing screws (2 pcs.) of the machine and remove the cover. Names of bundles Quantity Mounting plate upper Connecting unit Fixing screw A (Hex washer S-tight M4x18) Fixing screw B (4x8 cup)
  • Page 33: Height Adjustment

    Attach cover back to the main unit. If the height adjustment is not required, insert the large capac- ity tray unit further more. If the height adjustment is required, perform the adjustment procedure from 4). While lifting the section marked with ○ insert the connection unit into the large capacity tray unit and fix the fixing screw B (Packed item No.4) at the mark A on the connection unit.
  • Page 34: Paper Size Switch

    Tighten the loosened screw. Loosen the stopper fixing screw (1 pc.) on the lower right side of the paper feed tray to disable the stopper function. Pull out the paper feed tray again until it stops. D. Connector connection Remove the connector cover. If the dehumidifier kit is not installed, there is no need to remove the connector cover.
  • Page 35 Push the paper feed tray slightly, and return the disabled stop- b. Auxiliary guide size switch per to the original position, and fix with the fixing screw (1pc.). When changing the size of the side plate R, check to confirm the mark positions of "...
  • Page 36 Pull out the paper feed tray again until it stops. Insert the removed rear edge shaft into the mounting hole in the paper feed base as shown in the figure below. Fix the upper section with the fixing screw which was removed previ- ously.
  • Page 37: Size Setting

    G. Size setting (2) Mechanical adjustment Since the off-center adjustment is performed when shipping, there Execute SIM 26-2 "Size setting" with the key operations of the main is basically no need to perform this adjustment. If the center is unit. shifted, however, the simulation is normally used.
  • Page 38 Slightly push the tray, restore the stopper to the original posi- tion, and fix the fixing screw. Check to insure that the stopper pawl is engaged with the stop- per reception of the large capacity tray. Slowly insert the tray to the original position. Then make a copy to check to insure that there is no more shift.
  • Page 39: Mx-Lc16 (Large Capacity Tray)

    MX-M754N [4] MX-LC16 (LARGE CAPACITY TRAY) Service Manual Unpacking B. Attach the mounting plate upper and the lower front/rear connecting plate A. Packed items check Attach the mounting plates upper (Packed item No.1) with the fixing screw A (Packed item No.3) to the installation part of right side of the main unit.
  • Page 40 Insert the temporarily fixed screw A into the key hole in the Loosen the hex washer based screws on the both ends of the connecting unit and temporarily fix the connecting unit. caster movable plate on the front and the rear sides. Fix the other fixing screw A and tighten the temporarily fixed Turn the adjustment screw behind the plate to adjust the screw A securely.
  • Page 41 If the height adjustment is not required, insert the large capac- D. Connector connection ity tray unit further more. Remove the screw from the upper connector cover and If the height adjustment is required, perform the adjustment remove the cover to install the large capacity tray unit. procedure from 3).
  • Page 42 <2> F. Turn on the power of the main unit Move the side plate to the desired paper size position. Connect the power plug of the machine to the power outlet,. Open the front cover and turn ON the main power switch. <3>...
  • Page 43 Check that the adjustment pattern image is printed in the cor- rect position.Measure the dimensions of the void areas on the front- and rear-frame sides of the adjustment pattern image, and make sure that the following conditions are met: A-B = 0 3.0mm Push the large capacity tray into the closed (locked) position.
  • Page 44 Push the large capacity tray into the closed (locked) position. b. Diagonal feed adjustment Press the lock button on the front cabinet and lower the paper feed base tray to the paper supply position. Pull out the tray. Then make a copy again to insure that there is no shift. Repeat this procedure as required.
  • Page 45: Mx-Lt10 (Long Paper Feeding Tray)

    : ‘15/July Service Manual MX-M754N [5] MX-LT10 (LONG PAPER FEEDING TRAY) 1. Unpacking Hook the Long paper feeding tray to the guide of the machine. A. Packed items check Name Quantity Long paper feeding tray Insert the guide of the machine. 2.
  • Page 46: Mx-Tr16 (Exit Tray Unit)

    : ‘14/Dec : ‘15/July Service Manual MX-M754N [6] MX-TR16 (EXIT TRAY UNIT) Unpacking Remove the screws. Remove the right delivery unit. A. Packed items check ① ② ③ ③ ① ② Name Quantity Right delivery unit Delivery tray Delivery extension tray Full detect actuator Installation B.
  • Page 47: Mx-Tu15 (Exit Tray Cabinet)

    : ‘14/Dec [7] MX-TU15 (EXIT TRAY CABINET) MX-M754N Service Manual 1. Unpacking 2) Open the front cover, and remove the screw and cover. A. Packed items check Open the right door, remove the screws and the cover. Name Quantity Delivery tray cabinet Screw Paper fixture Full detect actuator...
  • Page 48 : ‘14/Dec 6) Attach the sponge (Packed item No.5) to the roller. 9) Attach the delivery tray cabinet fixing plate and fix it with screw. Attach the roller shaft and the roller back to the paper guide. 10) Attach the paper exit tray, and fix it with the screw. 11) Attach the cover and close the right door.
  • Page 49 13)Attach the paper holding arm. 14) Attach the full detection actuator. Be careful of the installing direction of the full detection actua- tor. B. Turn ON the power of the main unit Connect the power plug of the machine to the power outlet, and turn ON the main power switch and the operation panel power switch.
  • Page 50: Mx-Rb23 (Paper Pass Unit)

    MX-M754N [8] MX-RB23 (PAPER PASS UNIT) Service Manual Unpacking Remove the screw and left cover. A. Packed items check Engage the projection of the main unit frame with the hole in the plate (Packed item No.2) and install it and fix it with screw (Packed item No.5) Packed part names Quantity...
  • Page 51 Remove the connection cover from the cover removed by step 10) Install cover back to the original position and close front cover 2 and attach it to the cover (Packed item No.3) Install the cover and fix with the screw A (Packed item No.5) and screw B (Packed item No.6).
  • Page 52: Mx-Fn19 (Finisher)

    [9] MX-FN19 (FINISHER (50 sheets binding)) MX-M754N Service Manual Unpacking One person tilt the finisher, another person remove the lower tray. A. Removal of the finisher NOTE: For removal of the finisher, manpower of two persons or more is required. Remove the fixing material, and remove the top case.
  • Page 53 : ‘15/Feb Installation Remove the screws and remove the fixing material for the paper exit tray. (four positions) NOTE: Check to confirm that the firmware version is later that below. If the version is older, upgrade the firmware. Firmware version : 01.08.01.00 NOTE: When the finisher is installed, first install the paper pass unit, and then install the finisher.
  • Page 54 C. Attaching the cushion D. Check of the connected position of main unit and finisher Attach the cushion C (Packed items No.13), the cushion B (Packed items No.14) and the cushion A (Packed items No.15) Insert the rail of the finisher into the slit on the rail reception to the position indicated in the figure and cut cushion A circled.
  • Page 55 E. Adjustment Remove the fixing tapes. Remove the finisher from the main unit. Remove the screws, and remove the auxiliary wheels. Remove the screw and remove the lower cover and the front lower cover. Remove the screws, and remove the rear lower cover. Open the front upper cover.
  • Page 56 11) Remove the screw, and remove the spanner installed inside 15) Install the rear lower cover with the fixing screws. the front lower door. 16) Install the auxiliary wheels with the fixing screws. 12) Turn the bolt for which the adjustment is necessary, and adjust to become it within the range of specification.
  • Page 57 20) Close the front upper cover. Attach the connector cover on rear side of the finisher. 21) Attach the front lower cover with the fixing screw. G. Connection of connector to the main unit F. Connection of the finisher Connect two connectors of the finisher to the main unit, and tighten the screws.
  • Page 58: Mx-Fn20 (Saddle Stitch Finisher)

    MX-M754N [10] MX-FN20 (SADDLE STITCH FINISHER (50 sheets binding)) Service Manual Unpacking One person tilt the saddle stitch finisher, another person remove the lower tray. A. Removal of the saddle stitch finisher NOTE: For removal of the saddle stitch finisher, manpower of two persons or more is required.
  • Page 59 Remove the screws and remove the fixing material for paper Replace the stapler unit to the original position, and close the exit tray. (four positions) front door. Remove the fixing screws, and remove the right lower cover. Open the front door of the finisher, and remove the fixing tapes and protection material.
  • Page 60 : ‘15/Feb Installation C. Packed items check NOTE: Check to confirm that the firmware version is later than below. If the version is older, upgrade the firmware. Firmware version:01.08.01.00 NOTE: When the saddle finisher is installed, first install the paper pass unit, and then install the saddle finisher.
  • Page 61 C. Attaching the cushion Remove the screw, and remove the connector cover on rear side of the finisher. Attach the cushion C (Packed itemNo.13), the cushion B (Packed itemNo.14) and the cushion A (Packed itemNo.15) to the position indicated in the figure and cut cushion A circled.. Cushion A cut position Cushion A...
  • Page 62 Remove the cabinet fixing screw. Remove the fixing tapes. Loosen the caster fixing screws. Remove the screw, and remove the front lower cabinet 1. Remove the fixing screw of the front lower cabinet 2. Remove the screws, and slide to the left the front lower cabinet 2, and remove it.
  • Page 63 12) Check to insure that the upper and lower clearances between 16) Install the front lower cabinet 1 with the fixing screws. the main unit and the finisher are even. 17) Attach the cabinet fixing screw. 13) Tighten the caster fixing screws so that the indicator scale is fit.
  • Page 64 F. Connection of the saddle stitch finisher Remove the screw, and remove the connector cover on rear side of the finisher. Engage the saddle stitch finisher to the main unit. Install the Step screw B (Packed items (No.4)). Open the front door of saddle stitch finisher. Attach the connector cover on rear side of the finisher with the fixing screw.
  • Page 65 H. Staple position label attachment Attach the staple position label (Packed items) to the position indicated in the figure. For scanner (Packed items (No.9)) For DSPF (Packed items (No.10)) CAUTION Cleaning of the document scan section When streaks appear on copy or scan images, open the automatic document feed unit and clean the document scan section with the glass cleaner (accessory).
  • Page 66: Mx-Pn12A/B/C/D (Punch Module)

    [11] MX-PN12A/B/C/D (PUNCH MODULE) MX-M754N Service Manual Unpacking Installation A. Pulling out of the punch unit NOTE: Before installing the MX-PN12A/B/C/D, unpack the MX- FN19 or MX-FN20. A. Installation of punch unit MEMO: Carry out the procedure 1) only for MX-FN20. Peel off the released paper of the washer, and stick it to the fin- isher.
  • Page 67 Tighten the step screws bundled to the punch unit, fix the In the case of the finisher (MX-FN19) punch unit. Remove the screw of the finisher, and reuse it. Install it using the reuse screw, and three fixing screws bundled to punch unit.
  • Page 68 Install the connection fixture R to the main unit with the fixing G. Install to main unit screws. Engage the finisher that has installed punch unit to the main unit. Fix the main unit and the punch unit with the fixing screw D.
  • Page 69 Install the connector cover of the finisher and fix it with the fix- I. Connection of connector to the main unit ing screw. Connect two connectors of the finisher to the main unit, and tighten the screws. H. Attach the front door Open the front door of the finisher.
  • Page 70: Mx-Rb15 (Curl Correction Unit)

    MX-M754N [12] MX-RB15 (CURL CORRECTION UNIT) Service Manual D. Cushion attachment Unpacking A. Decurler unit removal NOTE: When moving the unit, use manpower of two or more per- sons. B. Fixing tape and protection material removal Cushion attachment position Remove fixing tape and fixing bracket from the decurler unit. C.
  • Page 71 B. Shunt cable connection plate installation E. Install to main unit (Back of the decurler unit) Return the stand rail to the original position. Fix the shunt cable connection plate (Packed items No.9) with Connect the unit to the machine. the screws (Packed items No.2).
  • Page 72 Use adjuster bolt (2) to adjust the height so that the center of the hole for the unit fixing screw in the R side is aligned with the center marking-off line. Use adjuster bolt (3) so that the clearance between the machine and the unit becomes uniform.
  • Page 73: Mx-Cf11 (Inserter)

    MX-M754N [13] MX-CF11 (INSERTER) Service Manual Unpacking Front Rear Quan Name tity A. Inserter unpacking RB15 RB13 FD10 Connection plate L NOTE: When moving the inserter, use manpower of three or more (Machine side) persons. Connection plate R (Machine side) Black Mylar Height adjustment saucer "L"...
  • Page 74 D. Paper guide C (bundled with the decurler unit) Attachment reference installation Attach to the notch in the rear side as the reference. Install the paper guide C (bundled with the decurler unit No.13) to the paper feed side of the inserter with the screws (bundled R side with the decurler unit No.1).
  • Page 75 Attach the connection plate F/R (Packed items No.8, 9) to the H. Fall-prevention stay storing decurler unit with the screws (Packed items No.18 Screw Loosen the screw of the fall-prevention stay, and store the 4x6L). stay. Fall-prevention stay G. Connection with the decurler unit Open the inserter front upper cover, remove the screw, and I.
  • Page 76: Cable Connection

    Remove the front inner cover. (2 screws) 10) Attach the accessory cover (Packed items No. 1) with the screw (Packed items No. 17) and the winding bushing (Packed Fix the tray unit. (2 screws (Packed items No. 16)) items No. 21). Front inner cover T ray unit Screw (M4 x 12)
  • Page 77: Mx-Rb13 (Relay Unit)

    MX-M754N [14] MX-RB13 (RELAY UNIT) Service Manual D. Cushion attachment Unpacking A. Relay unit unpacking NOTE: When moving the relay unit, use manpower of two or more persons. Cushion attachment position Reference of cushion on. (Rear screw hole tiered edge) Reference of cushion on.
  • Page 78 B. Rear upper cover installation E. Gasket installation (Only for Taiwan) Attach the rear upper cover (Packed items No.8) and fix it with Stick a gasket (Bundled with the inserter unit No.22) to the the screw (Packed items No.3). paper exit side of the inserter as the following reference. 10mm from frame line Upper line of the bracket Rear Frame...
  • Page 79 G. Connection with the inserter Open the front cover of the relay unit, remove the screws and pull the lock lever toward you. Adjust the adjuster bolt (1) so that the difference in heights in the front side the relay unit and the connection unit is within 2mm.
  • Page 80: Mx-Fd10 (Folding Unit)

    MX-M754N [15] MX-FD10 (FOLDING UNIT) Service Manual Unpacking A. Paper folding unit unpacking NOTE: When moving the paper folding unit, use manpower of four or more persons. C. Packed items check B. Fixing tape and protection material removal Remove the fixing tape. Remove the L-shape angle brackets for the folding unit.
  • Page 81 Installation B. Paper folding unit connection Connect the unit to the decurler unit. NOTE: Before installation, be sure to turn both the operation and Insert the pin in the decurler unit side into the hole in the unit. main power switches off and disconnect the power plug from the power outlet.
  • Page 82: Tilt Adjustment

    D. Tilt adjustment MEMO: When the adjuster bolt is turned counterclockwise, the height is decreased. When turned clockwise, the height is increased. MEMO: The specification of the tilt adjustment is as follows. Tilt: The difference of clearance between upper and lower part of the adjacent device is within +/-2mm.
  • Page 83: Mx-Fn21/Fn22

    Service Manual MX-M754N [16] MX-FN21/FN22 (FINISHER/SADDLE STITCH FINISHER) Unpacking Put the base of the machine on the floor. (Use enough care not to slip.) A. Removal of the finisher Tilt the machine slightly to the opposite side, and remove the packing material on the opposite side.
  • Page 84 : ‘14/Dec : ‘15/Feb C. Packed items check Name Quantity Staple unit staple case MX-FN21 Power cord Screw (RS tight, M4 x 8) Bookbinding tray Saddle stitcher unit accessory caster Screw (with spring washer) Staple position label (For scanner) Staple position label (For DSPF) Punch position label (For scanner) Punch position label (For DSPF) Saddle staple unit staple case...
  • Page 85 : ‘15/Feb Installation Insert the saddle staple unit staple case into the saddle unit until it clicks. NOTE: Check to confirm that the firmware version is later that below. If the version is older, upgrade the firmware. Firmware version:01.17.01.00 NOTE: Before installation, be sure to turn both the operation and main power switches off and disconnect the power plug from the power outlet.
  • Page 86 : ‘14/Dec : ‘15/Feb D. Shunt cable unit installation Connection unit: MX-RB13 (Relay unit) Fix the latch receivers F/R (Packed items No.1) and the posi- Fix the shunt cable unit (Packed items No.3) with the screw tioning pin (Packed items No.2) to the relay unit with the (Packed items No.8 RS tight, M4 x 8).
  • Page 87 Check to confirm that the latch is securely engaged with the Turn the fixing nut of the caster in the arrow direction with the latch holder, and fix the latch with the fixing screw. wrench to loosen it. Turn the adjustment nuts of the caster in the arrow direction with the wrench to adjust the height.
  • Page 88 J. Staple position label attachment MEMO: To adjust the tilt, use the two casters shone in the fig- ure below. Attach the staple position label (Packed items No.11, 12) to the position indicated in the figure. For scanner I. Cable connection Insert the wire saddle (Packed items No.4) into the hole in the upper rear cover to attach.
  • Page 89: Mx-Pn13A/B/C/D (Punch Module)

    MX-M754N [17] MX-PN13A/B/C/D (PUNCH MODULE) Service Manual Installation Unpacking NOTE: Installation must be executed in the sequence of the com- A. Removal of the punch unit plex machine body, the paper feed option, and the paper exit option. NOTE: Before installation, be sure to turn both the operation and main power switches off and disconnect the power plug from the power outlet.
  • Page 90: Transport Unit Removal

    Remove the rear cabinet of the finisher. Purchase assembling Attach the punch handle (Packed items No.13) and spring hook plate (Packed items No.12) to the punch open support plate (Packed items No.1) with the screw (Packed items No.10) and the step screw (Packed items No.11). Step screw Purchase installation B.
  • Page 91 In the front side of the punch unit, fit the hole in the punch unit Connect the cable from the punch unit. with the pin in the finisher side then push down the entire unit. F. Punch unit fixing pin attachment Attch the punching unit fixing pin (FN21 : Packed items No.4, FN22 : Packed items No.5) and fix it with the screw.
  • Page 92 H. Punch dust box installation I. Card installation (MX-FN21 only) Once remove the existing card fixing screw and stack the card (Packed items No.8) on the existing card then fix with the screw. J. Punch JAM clear label attachment (MX-FN22 only) MX-M754N MX-PN13A/B/C/D (PUNCH MODULE) 17 –...
  • Page 93: Mx-Tm10 (Trimming Module)

    MX-M754N [18] MX-TM10 (TRIMMING MODULE) Service Manual Unpacking A. Sponge sheet removal Remove the sponge sheet. A. Trimmer unit unpacking B. External fixture removal NOTE: When unpacking the trimmer unit, use manpower of two or Open the front door of the finisher. more persons.
  • Page 94 C. Transport unit removal Remove the discharge unit. Save the removed screws for later use. Pull out the saddle unit until it stops. Disconnect the connector at the rear of the saddle unit. D. Trimmer unit installation Insert the pin at the rear of the accuride rail (Packed items No.8) into the hole at the rear of the finisher.
  • Page 95 Hold the trimmer unit frame body (Packed items No.7) as Connect the connector for the sensor. shown in the figure below. Engage the frame of the trimmer unit frame body (Packed items No.7) with the step screw (Packed items No.9 M4x6) attached in procedure 2), Connect the connector for the motor, and fix it with the wire saddle.
  • Page 96 Connect the connector at the back of the unit. Attach the plate removed in procedure B-3). Attach the drive belt (Packed items No.4). Remove the resin E-ring, the bearing, and the resin washer. 10) Attach the upper cover (Packed items No.1). Insert the trimmer frame into the slit groove of the cover.
  • Page 97 : ‘15/Feb [19] MX-RB24 (PAPER PASS UNIT), MX-M754N MX-FN17 (INNER FINISHER) B. Packed items check (MX-RB24) 1. Unpacking A. Packed items check (MX-FN17) Packed part names Quantity IF interface transport guide upper IF right positioning plate Front rail guide IF interface transport guide lower IF Open/close cabinet IF left rear cabinet IF interface front cabinet...
  • Page 98 : ‘15/Feb Remove the right side plate. Remove the inner cover. B. No.5 Replace the IF interface transport guide lower Remove the upper unit. Replace the paperguide, and install cover back to the original position. MX-M754N MX-RB24 (PAPER PASS UNIT), MX-FN17 (INNER FINISHER) 19 – 2...
  • Page 99 : ‘15/Feb Attach the paperguide.. Attach the safety cover to the attachment, and fix it with the screw (M3 x 6 S tight, with flange). C. Installation of the IF right positioning plate Open the front cabinet (A). Remove the screws (B) and shift Attach the attachment.
  • Page 100 : ‘15/Feb Attach the path guide and fix it with the screw(M3 x 6 S tight 11) Remove the screw and left cover. with flange). Attach the front rail guide and fix it with the screw (M4 x 7 S) tight.
  • Page 101 : ‘15/Feb Fix the rail on the R side with the screw (M4 x 7 S tight). Remove the connector cover of the machine. When attaching the rail on the R side, lift it slightly so that there is no clearance between the rail on the R side and the machine frame.
  • Page 102 : ‘15/Feb G. Turn ON the power of the main unit Install cover back to the original position and close the front cover.. Connect the power plug of the machine to the power outlet, and turn ON the main power switch and the operation panel power switch.
  • Page 103: Mx-Pux1 (Xps Expansion Kit)

    MX-M754N [20] MX-PUX1 (XPS EXPANSION KIT) Service Manual Unpacking A. Packed items check Name Quantity CD-ROM Operation manual Product key sheet Installation A. Enable setting of functions Enter the product key to enable the functions. Enter the system setting mode. The machine enters the product key input mode.
  • Page 104: Mx-Pf10 (Barcode Font Kit)

    MX-M754N [21] MX-PF10 (BARCODE FONT KIT) Service Manual Unpacking A. Packed items check Name Quantity CD-ROM Product key sheet Installation A. Enable setting of functions Enter the product key to enable the functions. Enter the system setting mode. The machine enters the product key input mode. Enter the product key.
  • Page 105: Mx-Fx11 (Facsimile Expansion Kit)

    : ‘14/Dec [22] MX-FX11 (FACSIMILE EXPANSION KIT) MX-M754N Service Manual Unpacking A. Packed items check Ge rmany Aust ralia France For other destinations B. Pull out the MFP control unit Remove the screw, and remove the right rear cabinet. Name Quantity Remarks Fax unit...
  • Page 106: Connect The Interface Cable

    C. Connect the interface cable Fit the interface cable into the opening that has been cut. Attach the right rear cabinet, and fix the screw. Connect the interface cable to the MFP control PWB. NOTE: Check that the connector is not obliquely inserted. Push the interface cable into the recessed portion of the sheet metal on the MFP control unit.
  • Page 107 H. Line cable connection Connect the line cable (Packed items) on the line to the modu- lar jack indicated as “LINE.” MEMO: When connecting the line cable (to LINE or TEL), wind the line cable two turns around the ferrite core (Packed items) as shown in the figure, and connect to the modular jack which is marked with “LINE.”...
  • Page 108: Ar-Su1 (Stamp Unit)

    MX-M754N [23] AR-SU1 (STAMP UNIT) Service Manual Unpacking Attach the stamp unit (Packed items) to the stamp case which was removed from the DSPF unit with the installing screw A. Packed items check (Packed items). (Fix it together with the earth wire.) Name Quantity Stamp unit...
  • Page 109 Disengage the pawl, and open the stamp case unit. Install the stamp cartridge (Packed items). Install the OC mat to the SPF glass, and close the DSPF unit. B. Turn on the power of the main unit Connect the power plug of the machine to the power outlet, and turn ON the main power switch and the operation panel power switch.
  • Page 110: Mx-Fwx1 (Internet Fax Expansion Kit)

    MX-M754N [24] MX-FWX1 (INTERNET FAX EXPANSION KIT) Service Manual Unpacking A. Packed items check Name Quantity CD-ROM Product key sheet Installation NOTE: In order to specify the address of the Internet Fax with the PC-FAX driver, the PC-FAX driver must be updated by the Internet Fax expansion kit.
  • Page 111: Mx-Eb12 N (Mirroring Kit)

    MX-M754N [25] MX-EB12 N (MIRRORING KIT) Service Manual 2. Data backup 1. Unpacking A. Packed items check When the mirroring kit is installed to a machine which has not been used, this procedure is not required. Backup of data with a machine which has been used is made in order to provide against a failure in automatic copy of data to the HDD of the kit.
  • Page 112 Pull out and remove the control PWB unit. Attach the mirroring unit to the standard HDD, and connect the connector. Fix the mirroring unit with the screws (Packed items) and GND harness. B. Mirroring unit attachment Disconnect the connector of the standard HDD from the HDD. Connect the connector to the mirroring unit.
  • Page 113: Operation Check

    C. Reattach the control PWB and the right rear D. Turn ON the power of the main unit cabinet. Turn on the main power switch and the operation panel power switch. * If the fax box unit is installed, carry out steps 1), 2), and 3) Date copying from the standard HDD to the mirroring unit HDD additionally.
  • Page 114 B. Procedures Select the target HDD to delete the mirroring information. Connect the target HDD to delete mirroring information with the USB cable, SATA connection cable, SATA connector and the AC adaptor as follows. Click [Clear RIB in HDD] button. NOTE: When disconnect the cable from the HDD, be sure to dis- connect the USB cable from the PC in advance.
  • Page 115 C. Kinds of errors, causes and remedies Phenomenon 3 Though the target HDD is connected, it is not displayed. Phenomenon 1 An error indicating an abnormality in the Setup.ini file when booting Cause The target HDD is not registered in the Setup.ini file. the RIB Buster software.
  • Page 116: Mx-Fr47U/Fr47 (Data Security Kit)

    : ‘14/Dec : ‘16/Apr [26] MX-FR47U/FR47 (DATA SECURITY KIT) MX-M754N Service Manual Unpacking Pull out the control PWB unit. A. Packed items check Name Quantity Program RPM Product key sheet User manual (CD-ROM) Firmware program (USB memory) authentication label (MX-FR47 only) Installation - If the fax box unit is installed, carry out steps 4), 5), and 6) additionally.
  • Page 117: Firmware Update Procedures

    Set the BOOT SW on the left upper side of the MFP control Key name Functions in the CN update mode PWB to OFF. [OK] key Executes the selected function or item. [MENU] key Selects a menu. [BACK] key Selects a menu. (Serves as a cancel key in the execution check screen.) [UP] key...
  • Page 118 : ‘16/Apr Select the firmware file (SFU file) of the target. Carry out the operation check and initial settings in accordance with the instructions in the supplied CD and Installation Man- Use [UP] key and [DOWN] key to select the target file. ual.
  • Page 119: [27] Ic Card Reader

    : ‘14/Dec : ‘15/June Service Manual MX-M754N [27] IC card reader Installation Preparation NOTE: Before installation, be sure to turn both the operation and A. Supported IC card readers main power switches off and disconnect the power plug from the power outlet. Make double sure that the data lamp on the operation panel does not light up or blink when per- forming installation.
  • Page 120 : ‘14/Dec : ‘15/June Vertical direction: Fit with the notch. Holder type C Horizontal direction: Fit with the notch and the lower edge. TWN3 Cut out the boss. NOTE: The cutting position of the boss of the IC card reader holder differs depending on the kind of the IC card reader.
  • Page 121 : ‘14/Dec : ‘15/June C. Attach the upper cabinet front right Attach the upper cabinet front right and fix the screw. ① ① NOTE: Adjust the position of USB connector that roughly in the center of the holder. Bind up the cord on the inside of the holder. Holder type B Y591-EHID-201 v01 Bind up the cords at the about 80mm from the end of holder.
  • Page 122: Setting File For Hid Card Reading

    G. Making and importing of the setting file for HID B. Format of the setting file card reading The format of the setting file should be as shown below: Section name NOTE: The following procedures are executed only when a request is made by a user for customizing the data format Key name = Key value of IC card reading.
  • Page 123: Card Reading Test

    (2) Display when card reading is successfully [ Decoding\FacilityCode] completed Key name Description Start.Delimiter Delimiter (Front) Read Success. (* Specified only when the location key value is Card ID: XXXXXX "ByDelimiter".) Facility Code: XXXXXX * Only ASCII code printable characters can be used for specification.
  • Page 124: Mx-Kb13 (Keyboard)

    MX-M754N [28] MX-KB13 (KEYBOARD) Service Manual Unpacking Remove the screw and the cover. Disconnect the connector. A. Packed items check Name Quantity Keyboard unit Wire saddle Screw (M4 x 8 S-tight) Remove the screw and the cover. *1: Not use for this installation. Installation NOTE: Before installation, be sure to turn both the operation and main power switches off and disconnect the power plug...
  • Page 125 Disconnect the connector of the operation panel unit, and B. Installation of the keyboard unit remove the harness from the wire saddle. Pass the harness through the hole in the keyboard unit. Attach the keyboard unit, and fix the screw. Remove the clamp, and pull out the harness toward you.
  • Page 126 Attach the operation panel to the machine with the screw. Pass the harness through the clamp and the wire saddle, and connect the connector. NOTE: Be careful not to pinch the lead wires. Attach the operation panel cover. Pass the harness through the cabinet. Fix the harness with the clamp.
  • Page 127 12) Connect the connector, attach the cover with the screw. 13) Attach the cover with the screw. 14) Attach the cover with the screw. Close the front cover. C. Turn ON the power of the main unit Connect the power plug of the machine to the power outlet, and turn ON the main power switch and the operation panel power switch.
  • Page 128: Mx-Amx1 (Application Integration Module)

    MX-M754N [29] MX-AMX1 (APPLICATION INTEGRATION MODULE) Service Manual Unpacking A. Packed items check Name Quantity CD-ROM MX-AMX1 GETTING STARTED GUIDE Sharpdesk license kit Operation Manual Installation A. Enable setting of functions Enter the product key to enable the functions. Enter the system setting mode. The machine enters the product key input mode.
  • Page 129: Mx-Amx2 (Application Communication Module)

    MX-M754N [30] MX-AMX2 (APPLICATION COMMUNICATION MODULE) Service Manual Unpacking A. Packed items check Name Quantity CD-ROM Operation manual Installation A. Enable setting of functions Enter the product key to enable the functions. Enter the system setting mode. The machine enters the product key input mode. Enter the product key.
  • Page 130: Mx-Amx3 (External Account Module)

    MX-M754N [31] MX-AMX3 (EXTERNAL ACCOUNT MODULE) Service Manual Unpacking A. Packed items check Name Quantity CD-ROM Operation manual Installation A. Enable setting of functions Enter the product key to enable the functions. Enter the system setting mode. The machine enters the product key input mode. Enter the product key.
  • Page 131: Mx-Am10

    MX-M754N [32] MX-AM10 (WEB BROWSING EXPANSION KIT) Service Manual Unpacking A. Packed items check Name Quantity Operation manual (CD-ROM) Product key sheet Installation A. Enable setting of functions Enter the product key to enable the functions. Enter the system setting mode. The machine enters the product key input mode.
  • Page 132: Remote Operation Panel Function Password Setting Procedures

    MX-M754N [33] Remote operation panel function Enable setting Service Manual General To use the remote operation panel function, the password for the remote operation panel function must be entered on the password input menu displayed on the VNC boot screen. Note that, therefore, the password must be set in advance to use the remote operation panel function.
  • Page 133: Setting, Adjustments, Operation Check

    MX-M754N [34] Setting, Adjustments, Operation check Service Manual Firmware version check and version After installation of all the options to the machine, use SIM22-5 to check the version of each firmware. If it is not the latest version, upgrade it to the latest one. Function and operation check Check that the following operations are normal.
  • Page 134: Setup And Adjustment Data Recording

    MX-M754N [35] Setup and adjustment data recording Service Manual Print the various setup data and the adjustment data (list) with SIM22-6(Data pattern NO.1 and NO.3) and keep the data. * In case of a memory trouble, if the data are not kept, all the adjustments must be made again.
  • Page 135: Necessary Works Before Moving The Machine

    : ‘14/Dec [36] Necessary works before moving the machine MX-M754N Service Manual If the following options are installed, remove all of them from the machine. * Large capacity tray * Finisher * Paper pass unit * Saddle finisher * Curl correction unit * Inserter * Holding unit * Relay unit or Punch module...
