RILEY SMALL DINING SET
ASSEMBLY INSTRUCTIONS
IMPORTANT
FOR DOMESTIC USE ONLY
PLEASE READ BEFORE YOU CONTINUE FURTHER
THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF SERVICE
IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND PERIODIC
MAINTENANCE AND CLEANING.
ASSEMBLE ON A SOFT CLEAN SURFACE.
DO NOT USE ANY TOOLS OTHER THAN THOSE SHOWN.
ANY SPANNERS OR ALLEN KEYS REQUIRED ARE INCLUDED WITH THE FITTINGS KIT.
DO NOT FOR ANY REASON USE A POWER TOOL TO ASSEMBLE THIS PRODUCT.
ITS USE WILL INVALIDATE ANY CLAIM YOU MAY HAVE AND COULD MAKE THIS PRODUCT
UNSAFE.
DEPENDING ON THE AMOUNT OF USE THIS PRODUCT RECIEVES IT MAY BE
NECESSARY TO TIGHTEN UP THE FIXINGS FROM TIME TO TIME.
THIS IS COMPLETELY NORMAL FOR ANY FLAT PACK FURNITURE.
DO NOT OVERTIGHTEN FIXINGS.
FOR CLEANING, YOU MAY USE A DAMP CLOTH (NOT WET).
THE SURFACE OF THIS ITEM IS NOT HEAT RESISTANT. ALWAYS USE A
PLACE MAT UNDER HOT OR COLD ITEMS TO PREVENT MARKING.
