- Page 1 4 6 0 ⁄ 300 2jet 35280XX7 Z H ⁄ 用户手册 ⁄ 组装说明 4 6 0 ⁄ 300 3jet E N ⁄ Instructions for use ⁄ Assembly instructions 35282XX7 I N S T A L L A T I O N...
- Page 2 ! 安全技巧 大小 (参见第页 09) ! 装配时为避免挤压和切割受伤, 必须戴上手套. 流量示意图 (参见第页 04) ! 本产品只允许作为洗浴, 卫生和洁身之用. 备用零件 (参见第页 14) ! 冷热水管间过大的压力差必须予以平衡. XX = 颜色代码 00 = 镀铬 安装提示 ⁄ 安装前必须检查产品是否受到运输损害. 安装后将 34 = Brushed Black Chrome 不认可运输损害或表面损伤. 99 = Polished Gold-Optic 清洗 (参见第页 10) ⁄ 管道和阀门必须根据通用标准进行安装, 冲洗和 检查. 安装示意(参见第页 04) ⁄ 请遵守当地国家现行的安装规定. 淋浴器水效等级 技术参数 本公司淋浴器产品水效等级符合GB 28378-2019 《 淋 工作压强: 最大 0,6 MPa 浴器水效限定值及水效等级》 的要求,淋浴器水效等级 推荐工作压强: ...
- Page 3 ! S A F E T Y N O T E S F L O W D I A G R A M (see page 04) ! Gloves should be worn during installation to prevent S P A R E P A R T S (see page 14) crushing and cutting injuries.
- Page 4 460 ⁄ 300 2jet 35280XX7 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 Q = l/min 9 12 15 18 21 24 27 30 Q = l/sec = Rain = RainStream...
- Page 5 460 ⁄ 300 2jet 35280XX7 RainStream iBox universal 01800187 Rain DN 15 (1/2“) DN 15 (1/2“) DN 15 (1/2“) DN 20 (3/4“) > 50 L ⁄min DN 20 (3/4“) DN 20 (3/4“) Ø 70...
- Page 6 460 ⁄ 300 3jet 35282XX7 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 Q = l/min 9 12 15 18 21 24 27 30 Q = l/sec = Mono = Rain = RainStream...
- Page 7 460 ⁄ 300 3jet 35282XX7 iBox universal RainStream 01800187 Rain Mono DN 15 (1/2“) DN 15 DN 15 (1/2“) (1/2“) DN 20 (3/4“) > 50 L ⁄min DN 20 (3/4“) DN 20 (3/4“) Ø 70...
- Page 8 iBox universal 01800187 16x2 18x2 4 mm (5 Nm) 2,5 mm (2 Nm)
- Page 9 2 mm (1 Nm) 4 6 0 ⁄ 300 2 jet 35280XX7 4 6 0 ⁄ 300 3 jet 35282XX7 5 9 0 4 61 3 3 0 15 6 4 6 6...
- Page 10 ⁄ ⁄ ⁄ ⁄ ⁄ Axor ⁄ , Axor ⁄ www.hansgrohe.com.cn/service/producer-quarantee. ⁄ ⁄ QuickClean QuickClean, ⁄ ⁄ QUICK CLEAN...
- Page 11 W A R R A N T Y sponge pads or micro fi bre cloths. Axor guarantees to the consumer that this product is free of ⁄ The safety instructions of the cleaning agent manufactur- production faults. If any defect is detected within the war- ers must be strictly followed.
- Page 12 2 mm 92686000 92686000 20 mm...
- Page 13 (0,5 Nm) 2 mm (1 Nm)
- Page 14 460 ⁄ 300 2jet 35280XX7 98513000 98133000 96525000 (16x2) 98181000 (18x2) 92851000 92701XX0 (M5x8) 98214000 (12x2) 92700XX0 (M4x12) 93210000 13595000 95521000 92683000 (25 mm) (1°) 98388000 (24x2) 98163000 93207000 (15x2) 98205000 (21x2)
- Page 15 460 ⁄ 300 3jet 35282XX7 98513000 96525000 98133000 (16x2) 98181000 (18x2) 92851000 92701XX0 (M5x8) 98214000 (12x2) 92700XX0 (M4x12) 93210000 92683000 98388000 (24x2) 13595000 95521000 (25 mm) (1°) 98163000 (15x2) 93211000 98205000 (21x2) 92686000...
- Page 16 Axor ⁄ Hansgrohe SE Auestraße 5–9 77761 Schiltach Deutschland info@axor-design.com axor-design.com...
