ASSEMBLY GUIDE
WOODRIDGE™ PRO WOOD PELLET GRILL
SCAN FOR
STEP-BY-STEP
ANIMATED
INSTRUCTIONS
IMPORTANT: RETAIN FOR FUTURE REFERENCE. READ CAREFULLY.
©2024 TRAEGER PELLET GRILLS LLC.
ALL RIGHTS RESERVED.
T17562-REV A
A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN
REQUIRED CLEARANCES (AIR SPACES) TO COMBUSTIBLE
MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS
PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH
THESE INSTRUCTIONS.
TRAEGER PELLET GRILLS LLC
533 South 400 West
Salt Lake City, UT 84101
TRAEGER.COM

Advertisement

loading
Need help?

Need help?

Do you have a question about the WOODRIDGE PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Traeger WOODRIDGE PRO

Summary of Contents for Traeger WOODRIDGE PRO

  • Page 1 PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS. IMPORTANT: RETAIN FOR FUTURE REFERENCE. READ CAREFULLY. TRAEGER PELLET GRILLS LLC 533 South 400 West ©2024 TRAEGER PELLET GRILLS LLC. TRAEGER.COM Salt Lake City, UT 84101 ALL RIGHTS RESERVED. T17562-REV A...
  • Page 2 BEFORE YOU BUILD SETUP SPACE PLEASE READ THIS ASSEMBLY GUIDE AND YOUR OWNER’S MANUAL BEFORE INSTALLATION AND USE OF YOUR TRAEGER ® GRILL. FAILURE TO FOLLOW PRO TIP: Build on the bottom THE INSTRUCTIONS IN THIS ASSEMBLY tray of the shipping box to GUIDE AND YOUR OWNER’S MANUAL...
  • Page 3 HARDWARE (TOTAL QUANTITIES) 1:1 SCALE x2 extra x4 extra x1 extra 0.375 ROUND 0.375 COTTER CLEVIS PIN WASHER 0.75 in. 0.5 in. x2 extra x1 extra 120° SILICONE COTTER PIN MOUNTING BUMPER PLATE...
  • Page 4 CHAPTERS CHAPTER 1 – PAGE 5 COMPARTMENTS & LEGS CHAPTER 2 – PAGE 13 BOTTOM SHELF, WHEELS, & CASTERS CHAPTER 3 – PAGE 20 CONTROLS & SHELVING CHAPTER 4 – PAGE 34 LID & GRILL INTERNALS...
  • Page 5 CHAPTER 1 COMPARTMENTS & LEGS...
  • Page 6 CHAPTER 1 INSTALL SAFETY GRATE PRO TIP: Hand-tighten all screws first, then finish tightening with screwdriver.
  • Page 7 ASSEMBLE HOPPER 180°...
  • Page 8 ATTACH HOPPER TO BODY PRO TIP: Two people make this step easier.
  • Page 9 ATTACH HOPPER TO BODY...
  • Page 10 CONNECT AUGER BOX 12-PIN CONNECTOR CLICK! PRO TIP: Have a second person hold the auger box while you connect the cord. PRO TIP: Don't forget to remove the twist tie and tape holding down the cord.
  • Page 11 ATTACH AUGER BOX Use THIS screw now! PRO TIP: Don't pinch the wire between the auger box and the grill body!

  • Page 12: Attach Legs

    ATTACH LEGS Use THIS screw again! PRO TIP: You can gently squeeze the legs to align the screws before you finish tightening with a screwdriver. NICE WORK! CHAPTER 1 COMPLETE!
  • Page 13 CHAPTER 2 BOTTOM SHELF, WHEELS, & CASTERS...
  • Page 14 CHAPTER 2 ASSEMBLE BOTTOM SHELF Use THIS screw now! PRO TIP: Hand-tighten all screws first, then finish tightening with screwdriver.
  • Page 15 ASSEMBLE BOTTOM SHELF PRO TIP: These brackets fit snugly; loosely install all hardware on one bracket before tightening down and moving to the other bracket. PRO TIP: Make sure “Traeger” is upside down.
  • Page 16 ATTACH BOTTOM SHELF PRO TIP: No screws are needed for this step!
  • Page 17 ATTACH WHEEL HOOVES Use THIS screw again! AUGER BOX PRO TIP: Make sure alignment and positioning of hooves is as shown.
  • Page 18 ASSEMBLE WHEELS & CASTERS...
  • Page 19 FLIP GRILL OVER PRO TIP: Lock casters to prevent grill from possibly rolling. NICE WORK! CHAPTER 2 COMPLETE!
  • Page 20 CHAPTER 3 CONTROLS & SHELVING...
  • Page 21 CHAPTER 3 BUILD P.A.L. RAILS PRO TIP: Hand-tighten all screws first, then finish tightening with screwdriver.
  • Page 22 PRO TIP: This ATTACH P.A.L. TRIM step can be tricky. Scan our QR code to access video animations for assembly. Jump to Chapter 3, Step 2 for a video. PRO TIP: To prevent hardware from falling into the auger box, lay this manual on top of the grate.
  • Page 23 SECURE P.A.L. TRIM...
  • Page 24 ATTACH FOLDING SIDE SHELF...
  • Page 25 ATTACH FOLDING PRO TIP: Hand-tighten all screws SIDE SHELF first, then finish tightening with screwdriver.
  • Page 26 ASSEMBLE BACKSPLASH PRO TIP: This step requires no hardware. CLICK! CLICK!
  • Page 27 PRO TIP: Don't pinch the wire between ROUTE BACKSPLASH WIRING the backsplash and the grill body! Also, slide the wire through the openings carefully to prevent damage!
  • Page 28 ATTACH BACKSPLASH...
  • Page 29 INSTALL REAR HOOK...
  • Page 30 CONNECT CONTROLLER RTD SENSOR CONTROLLER 4-PIN 12-PIN CONNECTOR CONNECTOR CLICK! PELLET LEVEL SENSOR 6-PIN CONNECTOR PRO TIP: For easier connecting, lay the controller on its back on the edge of the hopper. PELLET LEVEL RTD SENSOR CONTROLLER SENSOR 6-PIN 4-PIN CONNECTOR 12-PIN CONNECTOR CONNECTOR PRO TIP: After connecting, tuck wires...
  • Page 31 ATTACH CONTROLLER PRO TIP: Install controller over flange in hopper.
  • Page 32 ATTACH CONTROLLER...
  • Page 33 ATTACH VENT PLATE NICE WORK! CHAPTER 3 COMPLETE!
  • Page 34 CHAPTER 4 LID & GRILL INTERNALS...
  • Page 35 CHAPTER 4 ATTACH HOPPER LID PRO TIP: Hand-tighten all screws first, then finish tightening with screwdriver.
  • Page 36 INSTALL CHUTE, SHIELD, AND BAFFLE EMBER SHIELD GREASE CHUTE HEAT BAFFLE EMBER SHIELD HEAT BAFFLE GREASE CHUTE...
  • Page 37 INSTALL DRIP TRAY...
  • Page 38 ATTACH LID HANDLE...
  • Page 39 ATTACH LID PRO TIP: Use two people to attach the lid. PRO TIP: Attach hinge pins C with lid closed, then open lid to install E and G.
  • Page 40 INSTALL GRATES...
  • Page 41 INSTALL GREASE + ASH KEG...

  • Page 42: Plug In Power Cord

    PLUG IN POWER CORD NICE WORK! CHAPTER 4 COMPLETE!
  • Page 43 STORING PARTS AND ACCESSORIES Wired Probe and Power Cord TO STORE: Grill Grates, Drip Tray, Grease Chute, and Ember Shield TO STORE DURING CLEANING: PRO TIP: Do not hang or store cooking utensils or power cord on grate hooks. Doing so could damage the utensils or power cord.
  • Page 44 5 GHz. The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Traeger Grills is under license. Other trademarks and trade names are those of their respective owners.
  • Page 45 Wi-Fi grill icon light up in the menu bar below the dot matrix, and an and is ready to pair. Open your smart device to the Traeger App and sign animation of a Wi-Fi signal with a question mark will be displayed.

  • Page 46: Seasoning Your Grill

    Burning wood pellets produces carbon monoxide which may lead to illness, serious injury, and/or death. Follow these guidelines to prevent this colorless, odorless gas from poisoning you, your family, your pets, or others: Only use your Traeger Grill outside in a well-ventilated area. This grill is intended •...
  • Page 47 Press the main power switch, located on the back of the auger box, to auger. Fill the hopper with pellets at least to the safety grate and close the lid. ON (I). Press the selection dial to wake up the controller. “TRAEGER” will scroll across the screen, indicating the grill is on.
  • Page 48 SEASONING YOUR GRILL CONTINUED 15 min Once the grill has reached 350°F, let it run for 15 minutes. While the After 15 minutes at 350°F, increase the temperature to 500°F. grill is seasoning, you may see dark or excessive smoke and ash; this is normal and will be less on future startups.
