Walk Behind Leaf Vacuum and Chipper
Operator's Manual
Warning: Please read and thoroughly understand all instructions before operating. Failure to follow
safety rules and other basic safety precautions may result in serious personal injury. Keep these
instructions in a safe and easily accessible place so that they can be referred to when needed. Retain
these instructions to assist in future servicing.
superhandyus.com
© SuperHandy All Rights Reserved | Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GUO128 and is the answer not in the manual?

Questions and answers

Summary of Contents for Super Handy GUO128

  • Page 1 Walk Behind Leaf Vacuum and Chipper Operator’s Manual Warning: Please read and thoroughly understand all instructions before operating. Failure to follow safety rules and other basic safety precautions may result in serious personal injury. Keep these instructions in a safe and easily accessible place so that they can be referred to when needed. Retain these instructions to assist in future servicing.
  • Page 2: Table Of Contents

    INDEX 1. WARNING ------------------------------------------------------------------------------------------------------------------------------------ 1 2. TECHNICAL SPECIFICATIONS --------------------------------------------------------------------------------------------------------- 2 3. MAIN COMPONENTS --------------------------------------------------------------------------------------------------------------------- 2 4. PART LIST -------------------------------------------------------------------------------------------------------------------------------- 3-4 5. ASSEMBLY ------------------------------------------------------------------------------------------------------------------------------ 5-9 6. OPERATION --------------------------------------------------------------------------------------------------------------------------- 10-13 7. MAINTENANCE AND STORAGE -------------------------------------------------------------------------------------------------- 13-14 8. WARRANTY ------------------------------------------------------------------------------------------------------------------------------- 14 9. TROUBLE SHOOTING ------------------------------------------------------------------------------------------------------------------- 14 10.
  • Page 3: Technical Specifications

    2. TECHNICAL SPECIFICATIONS SKU# GUO128 Impeller Diameter 14” (355 mm) Vacuum Snout Size 23.6"x4.7" (600x120mm) Collection Bag 6 cu.ft (175 L) Leaf Reduction 10:1 Chipping Capacity Max. 2" (50 mm) Chipping Knives 2pcs Reduction Rate 15:1 Wheel Size Front wheel 10", Back wheel 8"...
  • Page 4: Part List

    4. PART LIST 1. Engine Assembly Kit 2. Wheels Fixing Plate 3. Wheel Axle 4. Front Wheels x2 5. Wheel Bracket Kit 6. Swivel Wheels x2 7.Feed-in Chute Kit 8. Lower Handle-bar 9. Left Connecting Bar 10. Right Connecting Bar 11.
  • Page 5 16. Handle Bar 17. Hose 18. Clamp Base 1. Screw x2pcs 8. M8 Nut x36pcs 2. M8x20 Bolt x4pcs 9. M8 Star-shape Nut x4pcs 3. M8x25 Bolt 4xpcs 4. M8x40 Bolt x10pcs 10. D-pin x1pc 5. M8x45 Bolt x4pcs 11. φ20 Flat Washer x3pcs 6.
  • Page 6: Assembly

    5. ASSEMBLY Fig. 01 1. Assemble the Swivel Wheels (Fig.01) Engine Assembly Kit a) Use 4 M8x50 bolts and 4 M8 nuts to install the wheel bracket kit to the engine assembly kit. b) Use 2 M8x50 bolts and 2 M8 nuts to install the 2 swivel wheels to the wheel bracket kit.
  • Page 7 3. Assemble the Feed-in Chute Kit (Fig.03) a) Loosen and remove the 1 M8x25 bolt and 1 M8 nut from the housing as shown. Fig. 03 M8 Nut M8x25 Bolt b) Install the feed-in chute kit to the housing, fixed by the 1 M8x25 bolt and 1 M8 nut that were just removed, and another two (Fig.04) M8 nuts.
  • Page 8 4. Assemble the Handle-bar (Fig.05) a) Install the lower handle-bar to the base of the unit, fixing by 4 M8x40 bolts, 4 M8 nuts. b) Install the left connecting bar and right connecting bar to the lower handle-bar, fixing by 4 M8x45 bolts and 4 M8 nuts. c) Insert the upper handle-bar to the left and right connecting bars, fixing by 4 M8x40 bolts and 4 M8 nuts.
  • Page 9 6. Assemble the Collection Bag (Fig.07) a) Place the collection port of the collection bag over the discharge port, fixing by the belt. b) Install the collection bag onto the handle-bar using the 4 Star-shape bolts and 4 Star-shape nuts. Fig.
  • Page 10 8. Assemble the Hose Kit (Fig.09) a) Connect the metal vacuum port to the hose, fixing by 1 hose clamp. Tighten the clamp by turning the screw of it. b) Install the handle-bar to the metal vacuum port, fixing by 2 M8x40 bolts, 2 M8 nuts. Fig.
  • Page 11: Operation

    6. OPERATION OPERATING SAFETY IN GENERAL 1. Be very careful when loading or unloading the machine. 2. Please operate the machine carefully on the road or sidewalk. 3. Do not run the engine in an enclosed area where dangerous carbon monoxide fumes can collect. 4.
  • Page 12: Starting / Stopping The Engine

    Handle fuel with care; it is highly flammable. 1. Use an approved fuel container. 2. Never add fuel to a running engine or hot engine. 3. Fill fuel tank outdoors with extreme care. Never fill fuel tank indoors. 4. Before restarting the engine, please clean up spilled fuel before restarting. Gasoline Fires and Handling Fuel Safely Use extra care in handling gasoline and other fuels.
  • Page 13 Leaf vacuuming&Leaf Shredding Function Notice: • When using the leaf vacuuming function, make sure to tightly cover the rubber cover, otherwise it will affect the efficiency of leaf vacuuming. • The leaves will be automatically shredded and collected into the collection bag after vacuuming. Please remember to clean the collection bag prompt- One is trolley working type with suction and another is hose vacuum.
  • Page 14: Maintenance And Storage

    We suggest the user to clean the blockage in time, when the machine is not working smoothly, please check whether there is any blockage need to be cleaned, follow up the steps below: Remove blockage After the operation of the machine or when it is necessary to remove the blockage: 1.
  • Page 15: Warranty

    Inspect Cone, Hopper, & Guards 1. Service Interval: Every spring and fall. 2. Check that the chipper cone, shredder hopper, and discharge guards are in place, undamaged, and secure. Replace any damaged or missing parts. Clean Debris from Engine & Chipper 1.
  • Page 16: Exploded And Parts List

    10. EXPLODED AND PARTS LIST Part No. Description Q’ty Part No. Description Q’ty M8x45 Star-shape Bolt Front Wheels UpperHandle-bar Wheels Fixing Plate M8x40 Bolt Wheel Axle Right Connecting Bar Ø20 Flat Washer Discharging Chute Cotter Pin Clamp Base M8x20 Bolt D-pin Swivel Wheels Screw...
  • Page 20 Thank you for your most recent purchase. Great Circle USA Follow us on social media @SuperHandy Support Line: 1-866-493-0524 help@greatcircleus.com www.superhandyus.com Size: 210x285mm 157克双铜 REV 06/20/24...
