Technical Support and E-Warranty Certificate
www.vevor.com/support
STAIR CLIMBING CHAIR
MODEL: YHR-LD02
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YHR-LD02 and is the answer not in the manual?

Questions and answers

Related Manuals for VEVOR YHR-LD02

Summary of Contents for VEVOR YHR-LD02

  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support STAIR CLIMBING CHAIR MODEL: YHR-LD02 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
  • Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Before Initial Operation ● Read the user manual and note all warnings and safety instructions. ● Note technical data as lifting capacity cannot be exceeded. ● Check all electronic functions, safety brakes, and the position of the climbing track. While Operating the Unit ●...
  • Page 4 MODEL AND PARAMETERS Model YHR-LD02 Max. Load 450lbs Rubber-track Belts' Angle 20° Input AC 100-240V 50/60Hz Motor DC 24V / 120W；3-different Speed Adjustable Lithium Battery; DC 24V / 13Ah Battery Charger DC29.4V / 2A Telescopic Gripping Frame H108cm, H126cm, H145cm and H163cm...
  • Page 5 COMPONENTS Name Handle and Control Panel Rear Carry Handle Track Belt Rear Wheels(5in) Wheel Carrier Safety Belt Locking Catch Front Wheels(2in) - 4 -...

  • Page 6: Initial Operation

    INITIAL OPERATION NOTE: Before the initial operation, please ensure the STAIR LIFT will be operated in an environment higher than 0°C. Turning the Unit On: The power switch is located on the battery, press red button to turn on the power supply. Checking the Battery Charge: Press the round button on the battery charge indicator panel.

  • Page 7: Operation

    OPERATION 1. Never leave a wheelchair user unattended in the unit and always use the supplied safety belts. 2. The wheelchair stair lift should only be operated by trained personnel. 3. The unit must be operated with two hands at all times. NOTE: The battery should be fully charged prior to using the unit for the first time.
  • Page 8 Adjust each locking catch to the appropriate size for the wheelchair with a hexagon screw to adjust the catch support up or down, a cap screw for sliding the locking catch out or in as required. Pull the locking ring upwards outside the lock catch to adjust the lock catch.
  • Page 9 Manoeuvre the wheelchair onto the unit as shown. The main wheels of the wheelchair should be firmly seated in the loading trays. The locking catches should secure the back of the wheelchair. The headrest should be in a comfortable position for the wheelchair user.
  • Page 10 2. Always ensure that all parts of the unit are securely locked into place, especially the stair climbing tracks, before climbing stairs. 3. Practice operating without a load and at a LOW speed initially. Position the unit at the base of the stairs.
  • Page 11 Tilt the unit backward until the climbing track is in contact with the stairs. Press the UP button on the control unit to begin moving. 1. When you have reached the top of the stairs, manoeuvre the unit completely onto the landing and return the unit to an upright position. 2.
  • Page 12 1. Never touch any part of the climbing tracks when the unit is powered. 2. Always ensure that all parts of the unit are securely locked into place, especially the stair climbing tracks, before climbing stairs. Position the unit at the top of the stairs.

  • Page 13: Folding The Unit

    1. If possible, have a second person positioned on the stairs to steady the unit as you manoeuvre it into position. 2. When you have reached the bottom of the stairs return the unit to an upright position. 3. Press the red POWER button to turn off the climbing tracks. 4.
  • Page 14 Do not use wet hands when operating the equipment. 1. Charge the unit after each use. The MINIMUM Percentage of Charge is 25%. 2. Protect the charger and the charging wires from oil, grease, detergent, thinner or any potentially damaging liquids. 3.

  • Page 15: Troubleshooting

    TROUBLESHOOTING Faults Detection and Solutions Ensure the main power switch on the loading pallet is in the ON The unit won’t start or can't go position. The indicator light should up or down stairs. glow red. Check the battery charge. If it shows low power (<25%), charge the unit.
  • Page 16 Technical Support and E-Warranty Certificate www.vevor.com/support...
