- Page 1 INSTALLATION AND USER MANUAL THE EVOLVE SUSPENDED FIRE Bioethanol www.aurorasuspendedfires.com 65 B Piper Dr, Ballina NSW 2478 Australia...
-
Page 2: Table Of Contents
We would like to thank you for your purchase of an Aurora Suspended Fire. The care and craftsmanship we put into each fire will give you trouble free heating for many years to come. CONTENTS 1. PLANNING INTRODUCTION CLEARANCE TO COMBUSTIBLES 2. -
Page 3: Planning
PLANNING... -
Page 4: Introduction
5. Install the eco-smart drip tray and burner Mixing of appliance or flue-system components from different sources or modifying the dimensional specification of components may result in hazardous conditions. Where such action is considered, Aurora fires should be consulted in the first instance. -
Page 5: Clearance To Combustibles
AURORA SUSPENDED FIRES CLEARANCE TO COMBUSTIBLES A combustible surface is anything that can burn (i.e. plaster, wall paper, wood, fabrics etc.) These surfaces are not limited to those that are visible, but also include materials that are behind non-combustible material. Timber frames behind gyprock are considered combustible. -
Page 6: Dimensions & Specifications
DIMENSIONS & SPECIFICATIONS... - Page 7 DIMENSIONS & SPECIFICATIONS INSTALLATION AND USER MANUAL THE EVOLVE 550mm 325mm 630mm 300mm FEATURES WEIGHT & DIMENSIONS · Material: 3mm Steel Firebox width 300mm · Finish: high temperature Firebox height 630mm coating system Firebox weight 20kgs · Heat Output 1.7kW...
- Page 8 AURORA SUSPENDED FIRES CEILING BRACKET FLUE FIREBOX...
-
Page 9: Installation
INSTALLATION... -
Page 10: Suspension Bracket
INSTALLATION SUSPENSION BRACKET FLAT CEILING INSTALLATION: The bracket must be structurally secured within the roof, as shown on the diagram. The large square body of the ceiling bracket must protude down through the fi nished ceiling level by a minimum of 120mm. You must leave a 25mm clearance gap between the bracket and the ceiling. - Page 11 AURORA SUSPENDED FIRES » PITCHED CEILING INSTALLATION Custom Made For pitched ceilings we will custom fabricate your bracket to the required angle. When installing the bracket, it is very important that the bracket is sitting plumb. The installer may need to chock up one side of the bracket, with non combustible material i.e.
-
Page 12: Lower Flue
INSTALLATION INSTALLATION AND USER MANUAL LOWER FLUE LOWER FLUE LENGTHS We supply the lower flue in the standard sizes listed below. The extra length will be pushed up into the ceiling bracket, enabling you to set the correct distance of the firebox to the floor. - Page 13 AURORA SUSPENDED FIRES INSTALLING THE INTERNAL LOWER FLUE The lower active flue is delivered with additional length to allow for small changes to set the correct firebox height. 1. First position the lower flue inside the suspension bracket 1010mm from the floor.
-
Page 14: Firebox
INSTALLATION INSTALLATION AND USER MANUAL FIREBOX ENGAGING THE FIREBOX 1. Ensure the lower flue is the correct height from the floor 2. Use a jacking trolley to lift the firebox evenly onto the fixing shaft 3. Fit the blanking plate to cover the opening in the flue... -
Page 15: Engaging The Firebox
AURORA SUSPENDED FIRES ENGAGING THE FIREBOX Assemble the shaft & bearing system in the IMPORTANT following order: Ensure the threaded shaft does not knock 1. Push thrust bearing over shaft against the firebox 2. Engage the firebox. when engaging. This can 3. -
Page 16: Bioethanol Fireplace
INSTALLATION INSTALLATION AND USER MANUAL BIOETHANOL FIREPLACE The Evolve fireplace is fitted with an EcoSmart AB3 burner which uses bioethanol fuel. As bioethanol gives off nothing but water vapour there is no need for an external flue. The lower active flue will be... -
Page 17: For Installers
INSTALLATION INSTALLATION AND USER MANUAL FOR INSTALLERS CLEANING UP If the fire paint has accumulated dust, fingerprints or other residue during installation Wipe the firebox and lower flue down with a little water and a scratch free glass polishing cloth. Use a light spray of WINDEX if required. DO NOT RUB THE PAINT. -
Page 18: Installation Checklist
1mm to 2mm. IMPORTANT This must be ticked and signed by the person who installs your fire and returned to aurora suspended fires following installation for any warranty claims to be honoured. NAME SIGNATURE... - Page 19 Aurora 65B Piper Dr, Ballina NSW 2478 Australia www.aurorasuspendedfi res.com...
