- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support PIPE SHELVES MODEL:WPSR-XM011 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
-
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS WARNING: Read and understand this entire manual before operating or servicing this product. Failure to follow these warnings and instructions can cause personal injury or damage to valuable property. • Avoid children using the product. And this product is not a toy. Do not allow children to play. -
Page 4: Specification
CAUTION: • When installing the pipe shelves, pay attention to keeping the board in a horizontal state, so as to have a better experience of placing items • This product is intended for indoor installation use only. SPECIFICATION Note: The number unit in the figure is mm. Part List Mark Name... - Page 5 Board Board (*There are holes in the middle on both sides) Board Board Board Install accessories Mark Name Specifications Picture Double-headed screw Connecting rod Mandrel nut Screw M5*40mm Plastic expansion D=8mm tube Hook Screw M4*10mm - 4 -...
- Page 6 PIPE SHELVES ASSEMBLE STEP1.As shown below, combine B, G and C, and then insert the board D. STEP2.Screw the double-headed screw P into the ends of both rods.Then, press Connecting rod Q into the board STEP3.Press Mandrel nut R into the board, 2 groups in total. - 5 -...
- Page 7 STEP4.Insert the board I. *Note that the Angle of the Mandrel nut R should be adjusted during the process, and the Connecting rod Q should be tightened clockwise after being confirmed. STEP5.Press Connecting rod Q into the board E and then Insert the board STEP6.Screw in rod F.
- Page 8 STEP7.Repeat Steps 2 、4 and 5. STEP8.Screw in Upper bracket A. STEP9.If you think it is necessary, you can attach the rod G to the board and tighten it with screw V. - 7 -...
- Page 9 ATTACH PIPE SHELVES TO THE WALL Note:At least one assistant is recommended. STEP1:Locate the pipe shelves to the wall and determine the height you want to install them at. Use a level to make sure the boards are level, then mark the location holes on the mounting bracket.
- Page 10 STEP4:For each mounting hole, secure pipe shelves with tapping screws. - 9 -...
- Page 11 Manufacturer: Shanghaimuxinmuyeyouxiangongsi Address: Shuangchenglu 803nong11hao1602A-1609shi, baoshanqu, shanghai 200000 CN. Imported to AUS: SIHAO PTY LTD. 1 ROKEVA STREETEASTWOOD NSW 2122 Australia Imported to USA: Sanven Technology Ltd. Suite 250, 9166 Anaheim Place, Rancho Cucamonga, CA 91730 YH CONSULTING LIMITED. C/O YH Consulting Limited Office 147, Centurion House, London Road, Staines-upon-Thames, Surrey, TW18 4AX E-CrossStu GmbH...
- Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...
