PRODUCT SPECIFICATIONS
Maximum Temperature
Maximum Pressure
Air Inlet/outlet
Filter Element
Product Dimension
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble,
operate or maintain this product. If you have any questions, please call our
Customer Service Department at 1-888-KOBALT, 8:00 a.m. – 8:00 p.m., EST,
Monday – Friday.
Improper installation, operation or maintenance of this product could result in
serious injury and property damage. Read and understand all warnings and
operation instructions before using this equipment. Do not use this product in
unsafe work conditions. It is always recommended to keep a fire extinguisher
and first and kit near work areas.
FAILURE TO OBSERVE AND FOLLOW SAFETY INSTRUCTIONS COULD
RESULT IN INJURY OR DEATH.
AB17979
3/8 IN. AIR FILTER
125 °F (51 °C)
200 PSI
3/8 in. NPT
5 um
3.15 in. x 2.52 in. x 6.14 in. (L x W x H)
WARNING
1
ITEM #221014
MODEL #SGY-AIR9JH
Advertisement
Table of Contents
Related Manuals for LF KOBALT SGY-AIR9JH
Summary of Contents for LF KOBALT SGY-AIR9JH
- Page 1 ITEM #221014 3/8 IN. AIR FILTER MODEL #SGY-AIR9JH KOBALT and logo design are trademarks or registered trademarks of LF, LLC. All rights reserved. Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT, 8:00 a.m.-8:00 p.m., EST, Monday-Friday.
