V-TAC VT-11024-4G Instruction Manual

Ptz solar camera
Hide thumbs Also See for VT-11024-4G:

Advertisement

Table of Contents

TECHNICAL DATA
MODEL
SKU
SOLAR PANEL
WATTS
DIMENSION
OPERATION TEMPERATURE
LENS
DETECTION ANGLE
DETECTION DISTANCE
BATTERY TYPE
SENSOR TYPE
WORKS WITH
INTRODUCTION
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
instructions carefully before starting the installing and keep this manual handy for future reference. If you
have any another query, please contact our dealer or local vendor from whom you have purchased the
product. They are trained and ready to serve you at the best.
This marking indicates that this
product should not be disposed
of with other household wastes.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INSTRUCTION MANUAL
PTZ SOLAR CAMERA
VT-11024-4G
11616, 11615
8W
4
170x210x165mm
-30°C to +60°C
3.6mm
95°
0-12 Meters
18650 2600mAh Battery
PIR
works with
Google Assistant
WEEE Number: 80133970
Caution, risk of electric shock.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VT-11024-4G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for V-TAC VT-11024-4G

Summary of Contents for V-TAC VT-11024-4G

  • Page 1 Google Assistant INTRODUCTION Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installing and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.

  • Page 2: Safety Warning

    SAFETY WARNING 1) Do not allow the batteries or battery compartment to get wet prior to or during installation while your wireless camera is weatherproof and safe to use outside. 2) Do not exert external force or throw on the ptz camera. 3) PTZ camera should be stored in cool/dry place.

  • Page 3: Packaging List

    PACKAGING LIST 1. Solar Panel (1pc) 2. PTZ Camera (1pc) 3. Screw kit (1pc) • Hexagon Spanner (1pc) • Screw Driver (1pc) • Screws (8pcs) • Tapping Screw (4pcs) • USB Charging Screw (1pc) 4. User Manual (1pc) 5. Positon paper (1pc) PRODUCT DIAGRAM Solar panel Battery compartments...

  • Page 4: Installation

    PROCESS 1. Solar panel: connect panel to camera, fix a suitable angle with screws 2. SD card installation: open thesilicon flap and insert the SD card, then make sure to close the slicon flap to avoid rain leakage 3. insert TF card, then tightening the screws.. Power cable connect the cables between the panel and camera, then tightening the waterproof cap.

  • Page 5: Auto-Pairing

    AUTO-PAIRING 1. Enable Bluetooth and Home Wifi for the device to access your wifi connection for pairing. It will automatically find the nearest device. 2. Click “Scan” icon in the top right corner. MANUAL PAIRING 1. Select theSmart Camera (Wi-Fi) option from the devices list.
  • Page 6 Step 7: Once you have successfully completed step 6, will show the QR code. Show this QR Code to the camera face with the distance of 15-20cm away. Camera will automatically detect the QR code and start to pair. Step 8: A er successfully pairing the ptz camera with the app, you can start controlling multiple features of the ptz camera through your mobile –...
  • Page 7 Step 12: Once your device is successfully added, rename the device to your preference.
  • Page 8 GOOGLE ASSISTANT SETTINGS Step 1 • Install the Google Assistant app via the App Store (iOS) or the Play Store (Android) and register. If you already have an existing account with Google Assistant, please proceed to logging in. • Create a New Home/Choose from the existing home if any. •...
  • Page 9 Smart Life • Step 5: Sign In with your Smart Life Login credentials to Link the Smart Life device. • Step 6: Tap on Authorize in order to proceed to linking the device. Step 7 a. Account will now be linked, please stay on the page you will be redirected in few seconds to select the device to add to your home.
  • Page 10 Step 8: Select the Home where you would like to add the Smart Life under. (Or) you can create a New home in order to add the Smart Life to it. Step 9: You have succesfully added Smart Life device to your Google Assistant App. Step 10 a.
  • Page 11 Google Commands Now, you can control your smart device using voice commands on Google Assistant. Below are a few com- mands you can use: Ok, Google, turn on/o bedroom light, Ok, Google, turn on/o Hall light. THINGS TO REMEMBER BEFORE STARTING INSTALLATION 1.
  • Page 12 Step 5: Enable the Skill Step 6: Enter your Smart Life login ID and password and tap on “Link Now” Step 7: Once you tap on Link Now, you will be redirected to a new page requesting for authorization(Ref Im- age below).
  • Page 13 3. Smart Device - Lamp 4. Stable Wifi network IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU...
