Sharp AR-5726 Service Manual

Sharp AR-5726 Service Manual

Digital multifunctional system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
[1] PRODUCT OUTLINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
[2] SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
[3] CONSUMABLE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
[4] EXTERNAL VIEW AND INTERNAL STRUCTURE . . . . . . . . . . . . . 4-1
[5] ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
[6] SIMULATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
[7] SELF DIAG AND TROUBLE CODE . . . . . . . . . . . . . . . . . . . . . . . . 7-1
[8] MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
[9] FIRMWARE UPDATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
[10] ELECTRICAL SECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with
specified ones for maintaining the safety and performance of the set.
SERVICE MANUAL
DIGITAL
MULTIFUNCTIONAL
SYSTEM
AR-5726/5731
MODEL
CONTENTS
CODE: 00ZAR5731/S1E
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR-5726 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sharp AR-5726

Summary of Contents for Sharp AR-5726

  • Page 1: Table Of Contents

    CODE: 00ZAR5731/S1E DIGITAL MULTIFUNCTIONAL SYSTEM AR-5726/5731 MODEL CONTENTS NOTE FOR SERVICING [1] PRODUCT OUTLINE ........1-1 [2] SPECIFICATIONS .
  • Page 2 CONTENTS NOTE FOR SERVICING [5] ADJUSTMENTS 1. Warning for servicing ....... . i 1.

  • Page 3: Note For Servicing

    • Lightning conductor 8) The machine has got sharp edges inside. Be careful not to dam- age fingers when servicing. • A water pipe or a water faucet, which is not recognized as a grounding object by the authorities.

  • Page 4: Product Outline

    [MX-TE10] Machine stand Machine stand Paper feed unit Paper feed unit (Large) (Small) (500 Sheets) (500x2 Sheets) [MX-DS11] [MX-DS12] [MX-DE10] [MX-DE11] FAX expantion kit Expantion memory board FAX memory (8MB) [AR-SM5](256MB) [AR-FX7] [AR-SM6](512MB) [AR-MM9] AR-5726/5731 PRODUCT OUTLINE 1 - 1...

  • Page 5: Specifications

    LCD drive display area 192 x 72mm (600dpi: 10110dot x 6496dot) LCD backlight Fluorescent lamp backlight system Void area image loss Front/Rear: Less than 4mm LCD contrast adjustment Right/Left total: Less than 6mm at actual (100%) size AR-5726/5731 SPECIFICATIONS 2 - 1...

  • Page 6: Document Table

    11 x 17, 8.5 x 14, 8.5 x 13 (216 x A4, A4R, A5 330), 8.5 x 11, 8.5 x 11R, A3, B4, A4, A4R, A5 Multi copy S-S, S-D, D-D, D-S Mixed paper feed Enable (Same width only) AR-5726/5731 SPECIFICATIONS 2 - 2...

  • Page 7: Paper Feed Section

    8.5 x 11 shipping AB series Paper remaining detection No (paper presence only) ∗ 1: Supported envelope kinds: Commercial10 (4 - 1/8” x 9 - 1/2”), International DL (110mm x 220mm), International C5 (162mm x 229mm) AR-5726/5731 SPECIFICATIONS 2 - 3...

  • Page 8: Environmental Conditions

    Multi shot (2 in 1/4 in 1) (Centering available) Card shot (Centering available) Pamphlet mode (Centering available) Duplex copy direction switching Large volume document mode Black/white reverse (except for UK) Stream feeding mode (ON/OFF switch by the system setting) AR-5726/5731 SPECIFICATIONS 2 - 4...

  • Page 9: Consumable Parts

    Life setting by A4 (8.5"×11") 6% document (black) (Toner; Net 700g) Default: Toner save mode Developer (black) Developer ×1 26cpm: 75K MX-312FV (Developer; Net 300g) 31cpm: 100K Drum Drum ×1 26cpm: 75K MX-312FR 31cpm: 100K AR-5726/5731 CONSUMABLE PARTS 3 - 1...

  • Page 10: Maintenance Parts List

    300K, and it can be used up to 3 times. (Supplied as a drum frame unit.) Staple cartridge Staple cartridge ×3 5000 staples ×3 MX-SCX1 ∗ The other maintenance parts than the above are supplied as service parts. AR-5726/5731 CONSUMABLE PARTS 3 - 2...

  • Page 11: Developer/Drum Life End Definition

    Storage period Toner/Developer: 24 months from the Indicates the production day. manufactured month (Production lot) Hyphen under unsealed state Number Drum: 36 months from the manufactured Indicates the production lot. month under unsealed state AR-5726/5731 CONSUMABLE PARTS 3 - 3...

  • Page 12: External View And Internal Structure

    Regular paper and special paper (such as transparency film) can be fed from the bypass tray. Bypass tray extension Pull out the bypass tray extension before placing paper in the bypass tray. AR-5726/5731 EXTERNAL VIEW AND INTERNAL STRUCTURE 4 - 1...

  • Page 13: Internal Structure

    Do not touch the fusing unit when removing misfed paper. Doing so may cause a burn or injury. Fusing unit paper guide Open to remove misfed paper. AR-5726/5731 EXTERNAL VIEW AND INTERNAL STRUCTURE 4 - 2...

  • Page 14: Operation Panel

    This key blinks when auto power shut mode has activated. Press the key to return to normal operation. [INTERRUPT] key ( Use to perform an interrupt copy job. AR-5726/5731 EXTERNAL VIEW AND INTERNAL STRUCTURE 4 - 3...
  • Page 15 Document length detection SW (Long) Photo transmission Detects the document length on the tray. OPCLS Book sensor Photo transmission Detects the SPF float. Paper exit sensor Photo transmission Detects presence of documents. Document width sensor Volume Detects the document width on the tray. AR-5726/5731 EXTERNAL VIEW AND INTERNAL STRUCTURE 4 - 4...
  • Page 16 Manual feed length MPLD2 Manual feed paper length detection sensor 2 detection Manual feed paper MPED Manual feed paper empty empty sensor detection 2nd tray paper pass PFD2 2nd tray paper pass sensor AR-5726/5731 EXTERNAL VIEW AND INTERNAL STRUCTURE 4 - 5...

  • Page 17: Drive Motor

    Solenoid for the paper feed Toner motor Toner supply solenoid from the tray Paper feed solenoid CPFC1 Solenoid for the paper feed from the tray Separation pawl PSPS Separation pawl operation solenoid solenoid AR-5726/5731 EXTERNAL VIEW AND INTERNAL STRUCTURE 4 - 6...
  • Page 18 Cools the inside of the unit. Fusing paper exit fan VFM2 Cools the inside of the unit. (31 sheet model) Fusing paper exit fan VFM2 Cools the inside of the unit. Ozon filter Ozon filter AR-5726/5731 EXTERNAL VIEW AND INTERNAL STRUCTURE 4 - 7...
  • Page 19 Transports the picked up paper to RESIST section. 2nd tray pick-up roller Picks up paper from the tray. 2nd tray paper feed roller Transports the picked up paper to RESIST section. AR-5726/5731 EXTERNAL VIEW AND INTERNAL STRUCTURE 4 - 8...

  • Page 20: Adjustments

    ∗ When inserting a thickness gauge, be careful not to scratch the developing doctor and the MG roller. <Adjustment specification> Developing doctor gap +0.1mm F/C/R: 1.5 -0.15mm AR-5726/5731 ADJUSTMENTS 5 - 1...
  • Page 21 TEXT (122) (122mm/s) Enter the adjustment value with the 10-key. TEXT/PHOTO Character/Photo 5) Press the [START] key. (122) (122mm/s) Copying is started. PHOTO (122) Photo (122mm/s) TONER SAVE Toner save (122) (122mm/s) Min. unit: –10V increment AR-5726/5731 ADJUSTMENTS 5 - 2...
  • Page 22 5) Enter the set value and press the start key. The correction value is stored and a copy is made. <Adjustment specification> Adjustment Spec Setting Set value mode value range Rear edge 1 step: 0.127mm 4mm or 1 – 99 50-1-6 void shift less AR-5726/5731 ADJUSTMENTS 5 - 3...
  • Page 23 Image loss amount adjustment (Lead edge image loss set value) (OC) <Adjustment specification> Adjustment Spec Setting Set value mode value range Left edge void 50-1 1 step: 0.127mm 0.5 – 4mm 1 – 99 shift AR-5726/5731 ADJUSTMENTS 5 - 4...
  • Page 24 • When a copy as shown is made. Paper exit direction Original Copy 4) Loosen the set screw of the scanner drive pulley which is not in contact with No. 2/3 mirror base unit positioning plate. AR-5726/5731 ADJUSTMENTS 5 - 5...
  • Page 25 Paper exit Rear side direction When La = Lb and Lc = Ld, no need to perform the procedures 4) Front side and 5). 5) Tighten the fixing screw of the mirror base drive pulley. AR-5726/5731 ADJUSTMENTS 5 - 6...
  • Page 26 The current front surface sub scanning direction magnification ratio Enter the set value and press the start key. correction value is displayed in two digits on the display section. The correction value is stored and a copy is made. AR-5726/5731 ADJUSTMENTS 5 - 7...
  • Page 27 3) Slide the lens unit toward the rear side and attach it, then execute SIM. ∗ When the lens unit is moved, execute the OC main scanning magni- fication ratio auto adjustment, SIM 48-1-1. ∗ This adjustment is basically O.K. with SIM 63-7. AR-5726/5731 ADJUSTMENTS 5 - 8...
  • Page 28 If too dark, 1 – 99 – "3" is copied. decrease the (TONER SAVE) quantity displayed TEXT "3" is copied. on the copy (TONER SAVE) quantity display. TEXT PHOTO "3" is copied. (TONER SAVE) AR-5726/5731 ADJUSTMENTS 5 - 9...

  • Page 29: Simulation

    50-12, 51-2, the bold-faced items in the above list.) * If the entry value is outside the adjustable range, an error buzzer sounds and the adjustment value is not renewed. Page shift is not made, either. AR-5726/5731 SIMULATION 6 - 1...
  • Page 30 (Other modes) The display is made according to the selected mode and the item. Do you want to change the content ? Enter the new setting and adjustment values. AR-5726/5731 SIMULATION 6 - 2...

  • Page 31: Simulation Code List

    (Since this cannot be detected by hardware Used to check the operation of the toner motor and detection, it is set in this simulation.) its control circuit. AR-5726/5731 SIMULATION 6 - 3...
  • Page 32 Used to adjust the print image position (top margin) sensor. on print paper in the copy mode. (RSPF) Used to adjust the detection level of OC 20 FAX lead edge adjustment (read) degrees. FAX lead edge adjustment (print) AR-5726/5731 SIMULATION 6 - 4...
  • Page 33 Used to register the dial numbers. Used to perform the dial test. (10 PPS send test) Used to perform the dial test. (20 PPS send test) Used to perform the dial test. (DTFM signal send test) AR-5726/5731 SIMULATION 6 - 5...

  • Page 34: Details Of Simulation

    Set magnification ratio (Default 100%) Document size Varies depending on the destination. Duplex Selectable only when RSPF is installed. Set number of times 1 to 999 (0: Continuous operation) Note: Executable only when the RSPF is installed. AR-5726/5731 SIMULATION 6 - 6...
  • Page 35 Paper alignment motor R FPAM-F Paper alignment motor F FPDM Paper delivery motor Paddle solenoid FPTM Paper transport motor FDRLM Delivery roller lift motor FPGS Paper gate solenoid FARLS Alignment roller lift solenoid Staple light AR-5726/5731 SIMULATION 6 - 7...
  • Page 36 4th tray pick-up solenoid CPFS4 4th tray paper feed clutch Operation/procedure When the [START] key is pressed, the copy lamp is lighted for 10sec. Note: Execution is possible only when the option tray is installed. AR-5726/5731 SIMULATION 6 - 8...
  • Page 37 This setting is valid when SIM 7-1 (Intermittent setting) is enabled. VFM2 Fusing exit paper fan operates Setting range 1-255 Fusing fan, power cooling fan, and Default VFM&DCFM&DCFM2 power cooling fan 2 are operated at the &VFM2 same time. AR-5726/5731 SIMULATION 6 - 9...
  • Page 38 The minimum increment is 10V. The result of (Set value) -200/ 10 is stored in the EEPROM. When reading a value from the EEPROM, the value of (EEP value *10+200) is used as the set value. AR-5726/5731 SIMULATION 6 - 10...
  • Page 39 Min. unit: 10V increment Item Content Duplex motor/Duplex 2 motor forward rotation DMF145 (145mm/s) Duplex motor/Duplex 2 motor forward rotation DMF122 (122mm/s) Duplex motor/Duplex 2 motor reverse rotation DMR145 (145mm/s) Duplex motor/Duplex 2 motor reverse rotation DMR122 (122mm/s) AR-5726/5731 SIMULATION 6 - 11...
  • Page 40 Operation/procedure replaced part's counter only. 1. Press the [START] key. 2. When “1: YES” is selected, troubles other than U2 and PF are can- celed. (When “2: NO” is selected, the simulation is canceled.) AR-5726/5731 SIMULATION 6 - 12...

  • Page 41: Paper Jam

    (The old ones are deleted sequentially.) The trouble section may be determined by the data. FINISHER FINISHER If it is not installed, “- - - - - - - - - -” is displayed. AR-5726/5731 SIMULATION 6 - 13...
  • Page 42 FAX MEM NONE/Memory capacity (MB) Note: When the simulation is canceled, the display returns to the origi- HAND SET NONE/[11: Handset] nal state but the machine is not reset. USB HOST NONE/USB HOST AR-5726/5731 SIMULATION 6 - 14...
  • Page 43 SPF P-IN JAM_REV (Paper after JAM counter/JAM history reverse jam sensor reversing) SPF JAM RSPF JAM counter/RSPF JAM history RSPF short size SPF P-IN Passed (OFF at TROUBLE Trouble counter/Trouble history ORG_SHORT error sensor JAM) AR-5726/5731 SIMULATION 6 - 15...
  • Page 44 2. Press the [START] key. The confirmation menu is shown. 3. Select “1: YES.” 1: YES (Cleared) 2: NO (Not cleared) (Default) Item Content PRINTER Printer counter IMC counter DUPLEX DUPLEX counter OTHERS The other counters AR-5726/5731 SIMULATION 6 - 16...
  • Page 45 This setup detects Letter as A4 in the inch series and A4 as Letter in the AB series. 2:A4<->LT 0: Detection disable (Default) 1: Detection valid 8.5” x 13” detection valid/invalid setup Set value Setup Remarks Detection invalid Default Detection valid AR-5726/5731 SIMULATION 6 - 17...
  • Page 46 Section Auditor INEG EX inch series 0-14 Item Specifications ABEG EX AB series INEF EX inch series (FC) ABEF EX AB series (FC) CHINESE China TAIWAN Taiwan AB SEEG2 SEEG2 TAIWAN2 Taiwan China AR-5726/5731 SIMULATION 6 - 18...
  • Page 47 Input the set value with the 10-key and press the [START] key. This setup varies in connection with SIM 26-6 (Destination setup). Item Content Default Item Remarks STOP Stop JAPANESE NON STOP Non stop ENG.US ENG.UK FRENCH GERMAN ITALY DUTCH SWEDISH SPANISH AR-5726/5731 SIMULATION 6 - 19...
  • Page 48 Sets enable/disable of the gamma life correction function. Item Set value Default AE (Japan) AE (Ex Japan) Text Text/Photo Photo (Error diffusion) 0: Disable Photo (Dither) 1: Enable T/S AE (Japan) T/S AE (Ex Japan) T/S Text T/S Text/Photo AR-5726/5731 SIMULATION 6 - 20...
  • Page 49 3) Set to A5R/INVOICE R and fit the guide, then press the [START] key. 4) Narrow the guide at minimum, press the [START] key. 5) Set the paper detection width (+), and press the [START] key. AR-5726/5731 SIMULATION 6 - 21...
  • Page 50 For AB series, 1 to 5 is displayed, for inch series, 1 to 4. (145) (145mm/s) During execution of the simulation, “EXECUTING” is displayed. Ready Ready 150 - Temp Main temperature Main (122) (122mm/s) Ready Ready 150 - Temp Sub temperature Sub (122) (122mm/s) AR-5726/5731 SIMULATION 6 - 22...
  • Page 51 Setting POST Thick paper Main 150 - Function Used to set the DV count correction. CARD (122mm/s) (Purpose) (122mm/s) Image process CARDBOA Thick paper Sub Section 150 - (Photoconductor/Developing/Transfer/Cleaning) RD Sub (122mm/s) Item Operation (122) AR-5726/5731 SIMULATION 6 - 23...
  • Page 52 = 128+(60-50)+(45-50) = 133.) Setting Item Default range 0 - 93000 (31-sheet model) 1-99 93001 - 186000 (31-sheet model) 1-99 186001 - 279000 (31-sheet model) 1-99 279001 - 372000 (31-sheet model) 1-99 372001 - 465000 (31-sheet model) 1-99 AR-5726/5731 SIMULATION 6 - 24...
  • Page 53 19 +V1 THIN S (145) 5-30 122mm/s label paper > LTR 53 +V1 LABEL (122) 5-30 145mm/s thin paper t LTR 20 +V2 THIN S (145) 5-30 122mm/s label paper > LTR 54 +V2 LABEL (122) 5-30 AR-5726/5731 SIMULATION 6 - 25...
  • Page 54 Note: When this simulation is canceled, the display returns to the initial 3. Select the paper feed tray and the print density. menu but the machine is not reset. Use the 10-key to set the exposure level. 4. Press the [START] key. Copying is started. AR-5726/5731 SIMULATION 6 - 26...
  • Page 55 Content Setting range Default 1 COPY START Copy start – – 2 EXP.LEVEL Exposure level selection 3 AE Normal text AE 0-99 4 MANUAL Normal text MANUAL Note: Executable only when the FAX is installed. AR-5726/5731 SIMULATION 6 - 27...
  • Page 56 AE (PHOTO OFF) Super Fine AE 0-99 menu but the machine is not reset. MANUAL Super Fine MANUAL (PHOTO ON) (Half tone) MANUAL Super Fine MANUAL (PHOTO OFF) Note:Executable only when the FAX is installed. AR-5726/5731 SIMULATION 6 - 28...

  • Page 57: Photo Mode

    Note: When this simulation is canceled, the display is shifted to the ini- are changed, this setup is also changed to the default value accord- tial menu, but the machine is not reset. ingly. Item Setting range Default 0-31 AE(TS) AR-5726/5731 SIMULATION 6 - 29...

  • Page 58: Paper Empty

    (Horizontal, vertical to paper DOOR OPEN passing) Print magnification ratio Error display Vertical adjustment on the back surface PAPER EMPTY 1-255 (DUPLEX) (Vertical, parallel to paper passing) Note: Executable only when the FAX is installed. AR-5726/5731 SIMULATION 6 - 30...
  • Page 59 Rear edge void adjustment 3 END EDGE 1-99 DEN-B Rear edge void adjustment 1-99 (RSPF) Surface image loss quantity Rear edge void adjustment 4 LOSS(SIDE1) DEN-B-DUP 1-99 (Duplex) 5 LOSS(SIDE2) Back image loss quantity set AR-5726/5731 SIMULATION 6 - 31...
  • Page 60 1st tray 1. Select an item to be adjusted. TRAY2 2nd tray 1-99 TRAY3 3rd tray 2. Enter the set value of the lead edge adjustment with the 10 key. TRAY4 4th tray DUPLEX Back print AR-5726/5731 SIMULATION 6 - 32...
  • Page 61 The item and the currently set value are highlighted. 2. Press the [START] key. The display is shifted to the copy menu. 3. Select the paper feed tray and the print density. Enter the adjustment value with the 10-key. AR-5726/5731 SIMULATION 6 - 33...
  • Page 62 EEPROM. If an error occurs, “ERR” is dis- played and the value is not saved in the EEPROM. If the adjustment is not performed because of abnormality, “---” is dis- played. During execution of the adjustment, the operation cannot be inter- rupted. AR-5726/5731 SIMULATION 6 - 34...
  • Page 63 Lattice print (1cm, 1dot width LATTICE WLT, A3 print (A3 main scan, PRINT WLT sub scan)) is performed. * Duplex print can be made. * If the IMC board is not installed, the key inputs cannot be made. AR-5726/5731 SIMULATION 6 - 35...
  • Page 64 SUM check only 28 CNG1100 Flash ROM Tone signal Memory area 29 0.3 V21 The memory size follows the 30 ANSam Option memory automatically detected value. Pseudo-ringer sound 31 RINGER PAGE ([ON HOOK] key ON) MODEM AR-5726/5731 SIMULATION 6 - 36...
  • Page 65 * lIf there is any print data, the power must be turned off after clearing. 27 CED2100 Note: Executable only when the FAX is installed. 28 CNG1100 Tone signal 29 0.3 V21 30 ANSam Pseudo-ringer sound 31 RINGER ([ON HOOK] key ON) AR-5726/5731 SIMULATION 6 - 37...
  • Page 66 Enter the number with the 10-key, [*] key, and [#] key. Press the [CLEAR] key to return to the initial state. Press the [START] key to register the entered number. Note: Executable only when the FAX is installed. AR-5726/5731 SIMULATION 6 - 38...

  • Page 67: System Error

    AR-FX5. storage data are cleared. (When “2: NO” is selected, the simulation is Note: Executable only when the FAX is installed. canceled.) Note: Executable only when the FAX is installed. AR-5726/5731 SIMULATION 6 - 39...
  • Page 68 Note: Executable only when the FAX is installed. MED: (SMA value +1) - (LAR value – 1) SMA: 1 - (MED. Value + 1) 2. Sound volume pattern Note: Executable only when the FAX is installed. AR-5726/5731 SIMULATION 6 - 40...
  • Page 69 Note: Executable only when the FAX is installed. 66-52 Purpose Operation test/check (Japan only) Section Item Operation Function Pseudo-ringer check (Purpose) Operation/procedure Press [START] key. The call sound of the machine and the pseudo-ring are generated. AR-5726/5731 SIMULATION 6 - 41...

  • Page 70: Self Diag And Trouble Code

    Operation control PWB communication Combination error between the MCU and trouble (Time-out) the FAX firmware. Operation panel destination error FAX control PWB destination error Printer PWB communication trouble Printer PWB trouble AR-5726/5731 SELF DIAG AND TROUBLE CODE 7 - 1...
  • Page 71 IMC PWB ROM defect, data failure. Check Check the connectors of the IMC PWB and MCU PWB. remedy Check the grounding of the copier. Check the ROM of the IMC PWB. AR-5726/5731 SELF DIAG AND TROUBLE CODE 7 - 2...
  • Page 72 Check flat cable installation to the CCD Cause Motor lock. unit. remedy Check CCD unit. Motor rpm abnormality. Overcurrent to the motor. Finisher control PWB trouble. Check Use SIM 3-3 to check the staple motor operation. remedy AR-5726/5731 SELF DIAG AND TROUBLE CODE 7 - 3...
  • Page 73 Replace the developing unit. Content FAX control PWB trouble Use SIM 25-1 to perform DV stirring. remedy Details FAX control PWB abnormality Cause FAX control PWB defect Check Replate the FAX control PWB remedy AR-5726/5731 SELF DIAG AND TROUBLE CODE 7 - 4...
  • Page 74 Printer PWB ROM defect/Data failure. Check Check the connectors and the harness of the printer PWB and MCU PWB. remedy Check the grounding of the copier. Check ROM on printer PWB. AR-5726/5731 SELF DIAG AND TROUBLE CODE 7 - 5...
  • Page 75 MCU PWB. Fusing unit not installed. Clear the display of self-diagnostics with Check Check the harness and the connector of SIM 14. the thermistor and the MCU. remedy AR-5726/5731 SELF DIAG AND TROUBLE CODE 7 - 6...
  • Page 76 MCU PWB. Clear the display of self-diagnostics with SIM 14. Check that there is no foreign material in the contact section between the thermistor and the heat roller. AR-5726/5731 SELF DIAG AND TROUBLE CODE 7 - 7...
  • Page 77 Clear the trouble with SIM 14. MCU PWB failure. Check Check the main motor operation with SIM 25-1. remedy Check connection of the main motor harness and connector. Replace the main motor. Replace the MCU PWB. AR-5726/5731 SELF DIAG AND TROUBLE CODE 7 - 8...
  • Page 78 Check connection of the fan motor SIM operation error. harness and connector. Check Check for matching of the machine and Replace the fan motor. model information setting in SIM26-57. Replace the MCU PWB. remedy AR-5726/5731 SELF DIAG AND TROUBLE CODE 7 - 9...
  • Page 79 Check the grounding of the copier. remedy Content PF trouble Details The copy inhibit command from RIC is received. Cause Judged by the host. Check Inform to the host. remedy AR-5726/5731 SELF DIAG AND TROUBLE CODE 7 - 10...

  • Page 80: Maintenance

    – – – – ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ Others Paper feed rollers ✩ ✩ ✩ ✩ ✩ ✩ ✩ ✩ Gears ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ Ozone filter AR-5726/5731 MAINTENANCE 8 - 1...
  • Page 81 – – – – ❍ ❍ ❍ ❍ ❍ ❍ ❍ ❍ Others Paper feed rollers ✩ ✩ ✩ ✩ ✩ ✩ ✩ ✩ Gears ▲ ▲ ▲ ▲ ▲ ▲ ▲ ▲ Ozone filter AR-5726/5731 MAINTENANCE 8 - 2...

  • Page 82: Details Of Maintenance

    (2) Transport/exit roller H. Laser unit (1) LSU I. Power unit (1) Power source J. PWB (1) Option CN PWB (2) IMC PWB (3) MCU PWB (4) Motherboard PWB (5) Second interface PWB K. Ozone filter AR-5726/5731 MAINTENANCE 8 - 3...

  • Page 83: Drum Section

    Note: When installing the process unit in the main unit after replacing the drum, process unit may not be able to install by reason of the drum drive coupling position. In this case, rotate the drum about 45 degrees and install again. AR-5726/5731 MAINTENANCE 8 - 4...
  • Page 84 Disassembly* Hold the tip of the separation pawl and remove it. Assembly* Press the center of the separation pawl and install it. (2) Toner filter unit With the guide AS (cover) removed, replace it. When replacing, clean the guide AS. AR-5726/5731 MAINTENANCE 8 - 5...

  • Page 85: Toner Sensor

    • Clean the sensor only after removing used DV when replacing DV. Molt C. Fusing section Molt edge edge reference reference Projection edge Projection edge reference reference (4) DV blade [DV blade attachment reference] [Cross-section] Bump reference Rib reference AR-5726/5731 MAINTENANCE 8 - 6...
  • Page 86 (1) Thermostat (4) Fusing separation pawl (lower) Note: When securing the lamp harness and the thermostat, the tightening torque of the screw (4 positions) is 6-9 kgs. (5) Lower heat roller (2) Thermistor (3) Paper guide AR-5726/5731 MAINTENANCE 8 - 7...
  • Page 87 (6) Heater lamp (9) Upper heat roller (7) Upper cleaning pad (10) Thermistor cleaning pad (8) Fusing separation pawl (upper) AR-5726/5731 MAINTENANCE 8 - 8...
  • Page 88 D. Optical section (1) CCD unit a. Lamp (2) Lamp unit b. PWB AR-5726/5731 MAINTENANCE 8 - 9...
  • Page 89 (1) Paper feed solenoid (2) Tray sensor PWB (3) Manual P-in sensor/Manual empty sensor d. Mirror motor (4) Multi manual paper feed a. Paper feed roller/pickup roller E. Paper feed section Paper feed roller Pickup roller Separation sheet AR-5726/5731 MAINTENANCE 8 - 10...
  • Page 90 ∗ Slightly apply grease GP501MR (UKOG-0012QSZZ) around the axis. One rice grain for each. Installation*Install so that the cam transmit arm (1) comes under the d. Clutch/solenoid roller arm (2). (Clutch) b. Reverse sensor (Solenoid) AR-5726/5731 MAINTENANCE 8 - 11...
  • Page 91 (Clutch) (5) Upper 500 sheets tray paper feed a. Paper feed roller/pickup roller Note: With the toner cartridge installed, do not tilt or shake the devel- oper cartridge. AR-5726/5731 MAINTENANCE 8 - 12...
  • Page 92 Separation sheet ∗ When replacing, be careful not Slightly apply grease GE676 to adhere conduction grease (UKOG-0013QSZZ) to the (black) to the drive section. drum boss. AR-5726/5731 MAINTENANCE 8 - 13...
  • Page 93 Grease should not come out when assembling. (6) Lower 500 sheets tray paper feed a. Paper feed roller/pickup roller ∗ Slightly apply grease GP501MR (UKOG-0012QSZZ) around the axis. One rice grain for each. Grease should not come out when assembling. AR-5726/5731 MAINTENANCE 8 - 14...
  • Page 94 Transport clutch g. Solenoid h. Sensor PWB e. Paper feed clutch F. Side door unit (1) Transport roller unit f. Transport clutch ∗ Check that two springs are securely inserted into the transfer roller unit bosses. AR-5726/5731 MAINTENANCE 8 - 15...
  • Page 95 (2) Transport roller (4) DUP motor G. 1st paper exit unit (1) Cooling fan (3) DUP transport roller AR-5726/5731 MAINTENANCE 8 - 16...
  • Page 96 (2) Transport/exit roller (Except North America) AR-5726/5731 MAINTENANCE 8 - 17...

  • Page 97: Laser Unit

    2) Remove the left cabinet and exit tray. 3) Disconnect the LSU connector, and remove the securing screws to remove the LSU. Note: Check to confirm that the solenoid shaft is in the gate bracket, and fix with the screw. AR-5726/5731 MAINTENANCE 8 - 18...
  • Page 98 I. Power unit (1) Power source J. PWB (1) Option CN PWB AR-5726/5731 MAINTENANCE 8 - 19...
  • Page 99 (2) IMC PWB (4) Motherboard PWB (3) MCU PWB AR-5726/5731 MAINTENANCE 8 - 20...

  • Page 100: Ozone Filter

    (5) Second interface PWB K. Ozone filter AR-5726/5731 MAINTENANCE 8 - 21...
  • Page 101 (3) Toner motor (4) PS transport clutch L. Drive section (1) DUP reverse motor (2) Main drive motor AR-5726/5731 MAINTENANCE 8 - 22...
  • Page 102 (5) Paper feed clutch (7) Lift up motor (6) Drive unit M. Transport section (1) Transport roller Drive unit (Grease application part) AR-5726/5731 MAINTENANCE 8 - 23...
  • Page 103 (2) OPU PWB (3) Key PWB N. Operation section (1) Operation section AR-5726/5731 MAINTENANCE 8 - 24...
  • Page 104 (4) LCD unit P. RSPF (1) Document tray section a. Document tray unit O. Switch (1) Power switch AR-5726/5731 MAINTENANCE 8 - 25...
  • Page 105 Document length sensor (2) Paper feed unit section a. Paper feed clutch b. Pickup roller c. Document width resistor PWB AR-5726/5731 MAINTENANCE 8 - 26...
  • Page 106 Paper feed roller d. Paper feed unit e. Separation sheet AR-5726/5731 MAINTENANCE 8 - 27...

  • Page 107: Transport Section

    Sensor b. PS clutch c. Pressure release solenoid (3) Transport section a. Transport unit d. RSPF motor AR-5726/5731 MAINTENANCE 8 - 28...
  • Page 108 Roller <Note for disassembling the motor> The motor is positioned by the jig. Use the mark when assembling it to the original position. e. Transport roller g. Sensor AR-5726/5731 MAINTENANCE 8 - 29...
  • Page 109 Roller (4) Base section a. Interface PWB b. Solenoid i. Roller c. Book sensor AR-5726/5731 MAINTENANCE 8 - 30...

  • Page 110: Other Related Items

    FAX counter clear SIM 24-10 Scanner mode counter clear SIM 24-15 ∗ 31 sheet model: When maintenance message is displayed, replace consumption part reaching the number of sheets of maintenance, then clear the replaced part's counter only. AR-5726/5731 MAINTENANCE 8 - 31...

  • Page 111: Firmware Update

    ∗ Make sure to start up maintenance program before turn on the • Maintenance software: maintenance.exe machine. • Andromeda module file: ProcModelR.mdl • Maintenance tool driver: SFZEJENU.inf Ready to start download process when these trees appear. AR-5726/5731 FIRMWARE UPDATE 9 - 1...
  • Page 112 1)-5) again. And then, Expand "Special", and double-click on "Con- firm Error Status". If any of the message besides "No error has been occurred" appears, it means that download is incomplete, so please try again. AR-5726/5731 FIRMWARE UPDATE 9 - 2...

  • Page 113: Others (Troubleshooting)

    Restart maintenance program after confirming the selected download file is not abnormal and not using other application. An error. [0xXXXXXXXX] The error occurred except the above errors. [TROUBLESHOOTING] Restart maintenance program after confirming communication device of PC(either COM or parallel) is under right condition. AR-5726/5731 FIRMWARE UPDATE 9 - 3...

  • Page 114: Electrical Section

    CN29 CN12 CN31 CN501 CN30 CN502 CN18 CN27 CN23 (AB / INCH ) CN28 CN25 CN19 CN26 Paper Full Sensor 2nd POUT COVER SENSOR Pout 2 Ssensor CN14 Pout Gate CN22 Solenoid CN32 CN38 AR-5726/5731 ELECTRICAL SECTION 10 - 1...

  • Page 115: Actual Wiring Chart

    /INCHJP DGND LED0# DSIN2A 292250-5 DGND DSCLK# LED0# DSIN2B DGND OC COVER SENSOR DSCLK# OC COVER DGND LED0# PULL UP OCCOVER 292250-3 DGND 5V(PULL UP) MHP SENSOR 5V(PULL UP) PULL UP DGND DGND S3B-PH-K-S AR-5726/5731 ELECTRICAL SECTION 10 - 2...
  • Page 116 B. MCU - Optical base plate 2, OP I/F PWB, 1st paper exit unit, 2nd paper exit unit MCU PWB CCD PWB OP I/F PWB RSPF FINISHER RIC / DOWNLOAD/ PCI AR-5726/5731 ELECTRICAL SECTION 10 - 3...
  • Page 117 C. Manual feed, 1st tray unit section [1st TRAY UNIT] MCU PWB AR-5726/5731 ELECTRICAL SECTION 10 - 4...
  • Page 118 <PAPER EMPTY SENSOR> <PAPER UPPER LIMIT SENSOR> SMR-02V-N SMP-02V-NC /PCS2 <PAPER FEED SL> CN7(B3B-PH-K-E) Blue 292250-2 CSS2 CSS2 <TRAY SENSOR SW> DGND DGND CN1(B3B-PH-K-R) Red B 3B-PH-K-S LUM2D LUM2D [LIFT UP MOTOR UNIT] PGND PGND AR-5726/5731 ELECTRICAL SECTION 10 - 5...
  • Page 119 E. Fusing unit, Power supply unit section HV PWB HARNESS GUIDE MCU PWB DGND RTH2 DGND RTH1 PDPX DGND 5V(PullUp) AR-5726/5731 ELECTRICAL SECTION 10 - 6...
  • Page 120 F. DV & LSU unit section MCU PWB AR-5726/5731 ELECTRICAL SECTION 10 - 7...
  • Page 121 GDATA3 GDATA3 GDATA3 GDATA5 GDATA5 GDATA5 GDATA7 GDATA7 GDATA7 GDATA9 GDATA9 GDATA9 GDATA11 GDATA11 GDATA11 GDATA13 GDATA13 GDATA13 GDATA15 GDATA15 GDATA15 /PCLREQ1P /FAXREQ1P /FAXREQ1P CN9(B3B-PH-K-S) /PCLCS1P /FAXCS1P /FAXCS1P /PCLREQ0P /FAXREQ0P /FAXREQ0P /PCLCS0P /FAXCS0P /FAXCS0P AR-5726/5731 ELECTRICAL SECTION 10 - 8...

  • Page 122: Signal List

    LUD4 Lift-up motor upper limit Detects the upper limit of Detected Option tray detection (Tray 4) the lift-up motor. detected LUM1H Lift-up motor Drives the lift plate of the CN15 paper tray. AR-5726/5731 ELECTRICAL SECTION 10 - 9...
  • Page 123 Cools the fusing unit. CN504 POUTFANRDY Paper exit cooling fan lock Detects lock of the paper Rotation Lock CN504 detection exit cooling fan. PPD2 Paper pass sensor (Tray 2) Detects paper pass. Standard tray I/F AR-5726/5731 ELECTRICAL SECTION 10 - 10...
  • Page 124 TRCL2 Vertical transport clutch Controls ON/OFF of the Standard vertical transport roller. tray I/F TRCL3 Vertical transport clutch Controls ON/OFF of the Option tray vertical transport clutch. Paper empty sensor Detects paper empty. interface AR-5726/5731 ELECTRICAL SECTION 10 - 11...

  • Page 126: Parts Guide

    PARTS GUIDE CODE:00ZMXM310P002 デジタル複合機 Digital Multifunction System MX-M260/N/FG/FP MX-M310/N/FG/FP Revised Edition AR-5726/5731 (Except North America, MX-VR10 Japan,Argentina) MX-RP10 (North America, Japan, Argentina is standard) MX-TR11 MODEL (Japan is standard) このパーツガイドに掲載されている表示価格ランクは消費税抜きです。 CONTENTS 外装部 1(Exteriors 1) 2nd 外装 (2nd exteriors) 外装部 2(Exteriors 2) 2nd 550 ｶｾｯﾄﾕﾆｯﾄ...
  • Page 127 < 修正パーツガイド活用時の注意 > ・部品の互換性は下表の通り、No1 ～ 6 で表現しております。 < 互換性 > 新・旧の互換性有り。 新の代わりに旧は使用可。 旧の代わりに新は使用不可。 新の代わりに旧は使用不可。 旧の代わりに新は使用可。 新・旧の互換性無。 旧 (a,b,c…) どうし一対、又は 新 (a,b,c…) どうし一対で、 　 互換性有。 その他 ・部品の追加・変更・廃止・員数の増減等の変更は下表のマークで表現しております。 < 変更区分 > 新規追加 変　　更 廃　　止 員数増・その他 員数減 パーツ修正 ・変更時期のランニングチェンジは、R/C として記載しています。 < 変更時期 > ランニングチェンジ...

  • Page 128: 外装部 1(Exteriors 1)

    Update : 2009/11/16 補修部品のランク付 市場における補修部品の在庫管理が、適正に運営出来る手助けとなることを、目的とします。 Aランク : メンテナンスパーツ、メンテナンスパーツには入っていないがメンテナンスパーツに近い消耗パーツ。 Bランク : 性能・機能パーツ（センサー、クラッチ等の電気パーツ） 、消耗パーツ。 Eランク : 基板含むユニットパーツ。 Dランク : 整備パーツ（外装、パッキング、同梱パーツ） 。 Cランク : 上記ランク以外のパーツ（基板の子部品を除いたもの） 。 DEFINITION Rank A : Maintenance parts, and consumable parts which are not included in but closely related to maintenance parts Rank B : Performance/function parts (sensors, clutches, and other electrical parts), consumable parts Rank E : Unit parts including PWB Rank D : Preparation parts (External fitting, packing, parts packed together)
  • Page 129 Update : 2009/11/16 外装部 1(Exteriors 1) Original cover only SPF only PRP03901 – 2 –...

  • Page 130: 外装部 2(Exteriors 2)

    LBNDZ0007QSZZ ﾊﾞﾝﾄﾞ A2R GCAB-0141QSZZ 前ｷｬﾋﾞ Front cabinet Energy star label [MX-M260(Except Argentina) TLABZ5148FCZZ /M260FG/M260FP/M310(Except Argentina) /M310FG/M310FP,AR-5726/5731(East Europe)] ｴﾅｼﾞｰｽﾀｰﾗﾍﾞﾙ LX-BZ0082QSPZ ﾋﾞｽ Screw(3×8) TCAUA1069FCZZ (Except Japan) ｻｰﾋﾞｽ注意ﾗﾍﾞﾙ Service caution label TLABZ0793QSZZ (Except North America,Japan) ｸﾗｽ 1 ﾗﾍﾞﾙ NEW Class 1 label NEW TLABG5005FCZZ (Japan) ｸﾗｽ...
  • Page 131 Update : 2009/11/16 外装部 2(Exteriors 2) PRP03902 – 4 –...

  • Page 132: 操作部 (Operation Panel Unit)

    Update : 2009/11/16 操作部 (Operation panel unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time PSHEZ0646QSPZ 基板保護ｼｰﾄ PWB protect sheet XEBS730P08000 ﾋﾞｽ Screw(3×8) DHAI-0503QSPZ KEY 基板ﾊｰﾈｽ KEY PWB harness OPU PWB (North America,Philippines,Thailand, CPWBX0211QSF2 Indonesia,India,Special country,Malaysia, Singapore,Argentina) OPU 基板...
  • Page 133 Update : 2009/11/16 操作部 (Operation panel unit) PRP03903 – 6 –...

  • Page 134: ﾌﾚｰﾑ部 (Frame Section)

    Update : 2009/10/16 ﾌﾚｰﾑ部 (Frame section) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time LPLTM0163QSZZ 左補強板下 Left reinforce plate lower XHBS730P08000 ﾋﾞｽ Screw(3×8) LPLTM0232QSZ2 ﾌﾚｰﾑ補強板 R Frame reinforce plate R CFRM-0043QS03 ｺｰﾅｰﾌﾚｰﾑ RL Corner frame RL XEBS740P10000 ﾋﾞｽ...
  • Page 135 Update : 2009/10/16 ﾌﾚｰﾑ部 (Frame section) PRP03904 – 8 –...

  • Page 136: ﾗﾝﾌﾟﾕﾆｯﾄ (Lamp Unit)

    Update : 2009/11/16 ﾗﾝﾌﾟﾕﾆｯﾄ (Lamp unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time PREFL0004QSZZ ﾘﾌﾚｸﾀｰ Reflector RLMPU0012QSZZ ﾗﾝﾌﾟ Lamp LHLDZ0047QSZ3 ﾍﾞｰｽ Base MSLI-0138FCZZ ｽﾍﾞﾘ材 Slider PCUSU0203FCZZ 防振ｸｯｼｮﾝ Protection cushion MSPRP0145QSZZ ﾐﾗｰｽﾌﾟﾘﾝｸﾞ Mirror spring PMIR-0009QSZZ 1st ﾐﾗｰ...
  • Page 137 Update : 2009/11/16 ﾗﾝﾌﾟﾕﾆｯﾄ (Lamp unit) PRP03905 – 10 –...

  • Page 138: 光学ﾌﾚｰﾑ 1(Optical Frame 1)

    Update : 2009/11/16 光学ﾌﾚｰﾑ 1(Optical frame 1) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time PWIR-0006QSPZ MB ﾜｲﾔｰ F MB wire F CDAIU0012QS15 光学台板 Optical base plate NPLYZ0016QSZZ 定ﾌﾟｰﾘｰ Pulley NPLYZ0006QSZ1 L ﾌﾟｰﾘｰ L pulley XRESP40-05000 E ﾘﾝｸﾞ...
  • Page 139 Update : 2009/11/16 光学ﾌﾚｰﾑ 1(Optical frame 1) PRP03906 – 12 –...

  • Page 140: 光学ﾌﾚｰﾑ 2(Optical Frame 2)

    Update : 2009/11/16 光学ﾌﾚｰﾑ 2(Optical frame 2) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time PCOVP0075QSZZ ﾊｰﾈｽｶﾊﾞｰ Harness cover XNES730-24000 ﾅｯﾄ Nut(M3) VHPGP2D03//-18 (Inch Series) ﾌｫﾄｾﾝｻｰ Photo sensor(GP2D03) VHPGP2D07//-18 (AB Series) ﾌｫﾄｾﾝｻｰ Photo sensor(GP2D07) DHAI-0347QSPZ (Inch Series) 光学ｾﾝｻｰﾊｰﾈｽ...
  • Page 141 Update : 2009/11/16 光学ﾌﾚｰﾑ 2(Optical frame 2) Series Inch Series Inch Series Series PRP03907 – 14 –...

  • Page 142: 中間ﾌﾚｰﾑ部 (Middle Frame Section)

    Earth spring XEPS723P12000 ﾋﾞｽ Screw(3×12) PSHEZ0394QSZ1 ｿﾚﾉｲﾄﾞ消音材 Solenoid sound proof sheet QSW-B0017QSZZ ﾄﾚｲ検知ｽｲｯﾁ Tray detect switch Drive unit CPLTM0160RS59 [MX-M260/M260N/M260FG/M260FP,AR-5726] 駆動ﾕﾆｯﾄ Drive unit CPLTM0160RS60 [MX-M310/M310N/M310FG/M310FP,AR-5731] 駆動ﾕﾆｯﾄ PSPAZ0041QSZZ ｿﾚﾉｲﾄﾞｽﾍﾟｰｻｰ Solenoid spacer Fusing cushion A PMLT-0120QSZ1 [MX-M310/M310N/M310FG/M310FP,AR-5731] 定着ﾓﾙﾄ A PMLT-0116QSZZ ﾌｧﾝｶﾊﾞｰﾓﾙﾄ L...
  • Page 143 Update : 2009/11/16 中間ﾌﾚｰﾑ部 (Middle frame section) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time ﾌﾟﾛｾｽ吸気ﾀﾞｸﾄ Process air intake duct cover PCOVP0143QSZZ ｶﾊﾞｰ PDUC-0010QSZZ ﾌﾟﾛｾｽ吸気ﾀﾞｸﾄ Process air intake duct AN2R PS fan harness AN2R PS DHAI-0609QSPZ ﾌｧﾝﾊｰﾈｽ...

  • Page 144: 550 ｶｾｯﾄﾕﾆｯﾄ (550 Cassette Unit)

    Update : 2009/10/16 550 ｶｾｯﾄﾕﾆｯﾄ (550 cassette unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time LPLTP0159QSZZ ｶｾｯﾄ後端板 Cassette rear edge plate LHLDW1226FCZZ ﾀｰﾝﾌｧｽﾅｰ Turn fastener LPLTM0179QSZ1 回転板 Rotation plate PSHEZ0274QSZZ 回転板ｼｰﾄ Rotation plate sheet GCASP0006QSZZ 550 ｶｾｯﾄ...
  • Page 145 Update : 2009/10/16 550 ｶｾｯﾄﾕﾆｯﾄ (550 cassette unit) PRP03909 – 18 –...

  • Page 146: F 給紙部 (Paper Feed Section)

    Update : 2009/10/16 給紙部 (Paper feed section) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time XEBS730P10000 ﾋﾞｽ Screw(3×10) CPWBF0081QSE2 ｶｾｯﾄｾﾝｻｰ基板 Cassette sensor PWB MLEVP0064QSZZ 紙検知ｱｸﾁｭｴｰﾀｰ Paper detect actuator 上限検知 Upper limit detect actuator MLEVP0063QSZ1 ｱｸﾁｭｴｰﾀｰ...
  • Page 147 Update : 2009/10/16 給紙部 (Paper feed section) PRP03910 – 20 –...

  • Page 148: G 搬送部 (Paper Transfer Section)

    Update : 2009/11/16 搬送部 (Paper transfer section) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time XEBS740P12000 ﾋﾞｽ Screw(4×12) PCOVP0053QSZ6 中間ﾌﾚｰﾑｶﾊﾞｰ Middle frame cover PS ｱｰｽ PS earth spring LP MSPRD0194QSZ1 ｽﾌﾟﾘﾝｸﾞ LP MSPRC0291QSZZ PS 加圧ｽﾌﾟﾘﾝｸﾞ...
  • Page 149 Update : 2009/11/16 搬送部 (Paper transfer section) 48 53 PRP03911 – 22 –...

  • Page 150: H ｻｲﾄﾞﾄﾞｱﾕﾆｯﾄ (Side Door Unit)

    Update : 2009/11/16 ｻｲﾄﾞﾄﾞｱﾕﾆｯﾄ (Side door unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time MLEVP0058QSTZ ﾛｯｸﾚﾊﾞｰ Lock lever GDOR-0002QSTD [Missing parts code] 右ﾄﾞｱ 1st lot Right door XRESP40-06000 E ﾘﾝｸﾞ E type ring(E4) LBSHZ0303FCZZ M ﾌﾞｯｼﾝｸﾞ...
  • Page 151 Update : 2009/11/16 ｻｲﾄﾞﾄﾞｱﾕﾆｯﾄ (Side door unit) 49 59 PRP03912 – 24 –...
  • Page 152 Update : 2009/10/16 ﾏﾙﾁ手差しﾄﾚｲﾕﾆｯﾄ (Multi manual paper feed tray unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time PGIDM0075QSTZ [Missing parts code] MB ｻｲﾄﾞｶﾞｲﾄﾞ F 1st lot MB side guide F PGIDM0076QSTZ [Missing parts code] MB ｻｲﾄﾞｶﾞｲﾄﾞ R 1st lot MB side guide R XEBS730P08000...
  • Page 153 Update : 2009/10/16 ﾏﾙﾁ手差しﾄﾚｲﾕﾆｯﾄ (Multi manual paper feed tray unit) PRP03913 – 26 –...
  • Page 154 Update : 2009/10/16 ﾏﾙﾁ手差し給紙ﾕﾆｯﾄ (Multi manual paper feed unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time PCOVP0107QSTF ﾏﾙﾁﾌﾚｰﾑｶﾊﾞｰ N1 Multi frame cover N1 XEBS730P10000 ﾋﾞｽ Screw(3×10) PSHEZ0099QSZZ 防振ｼｰﾄ S Protect sheet S NROLR0922FCZ2 手差しﾛｰﾗｰ...
  • Page 155 Update : 2009/10/16 ﾏﾙﾁ手差し給紙ﾕﾆｯﾄ (Multi manual paper feed unit) 14 6 PRP03914 – 28 –...
  • Page 156 Update : 2009/11/16 DV ﾕﾆｯﾄ (DV unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time LHLDZ0142QSZZ ﾌｨﾙﾀｰﾎﾙﾀﾞｰ Filter holder PFILD0313FCZZ TN ﾌｨﾙﾀｰ TN filter XEBS730P08000 ﾋﾞｽ Screw(3×8) PGIDM0158QSZZ ｶｰﾄﾘｯｼﾞｶﾞｲﾄﾞ上 Cartridge guide top PSEL-0162QSZZ DV ﾌﾞﾚｰﾄﾞ...
  • Page 157 Update : 2009/11/16 DV ﾕﾆｯﾄ (DV unit) PRP03915 – 30 –...
  • Page 158 Update : 2009/11/16 ﾌﾟﾛｾｽﾕﾆｯﾄ (Process unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time XEBS730P08000 ﾋﾞｽ Screw(3×8) PCAPH0022QSZZ ﾄﾅｰﾊﾟｲﾌﾟｷｬｯﾌﾟ Toner pipe cap NSRW-0002QSZZ 搬送ﾊﾟｲﾌﾟｽｸﾘｭｰ Transport pipe screw LPLTM0241QSZZ ﾌﾟﾛｾｽ補強板 Process reinforce plate MLEVP0065QSZZ 剥離爪ﾚﾊﾞｰ...
  • Page 159 Update : 2009/11/16 ﾌﾟﾛｾｽﾕﾆｯﾄ (Process unit) PRP03916 – 32 –...
  • Page 160 Update : 2009/10/16 定着ﾕﾆｯﾄ 1(Fusing unit 1) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time MARMP0048QSZ2 [Missing parts code] 圧解支点ｱｰﾑ 1st lot Pressure release fulcrum arm MLEVP0100QSZZ 圧解ﾚﾊﾞｰ F TL Pressure release lever F TL MLEVP0101QSZZ 圧解ﾚﾊﾞｰ...
  • Page 161 Update : 2009/10/16 定着ﾕﾆｯﾄ 1(Fusing unit 1) PRP03917 – 34 –...
  • Page 162 Update : 2009/11/16 定着ﾕﾆｯﾄ 2(Fusing unit 2) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time NBRGY0022QSZZ FU 加圧軸受 Fusing pressure bearing NROLR0156QSZZ 圧着ﾛｰﾗｰ Fusing roller 定着加圧 Fusing pressure spring(TL) MSPRC0324QSZZ ｽﾌﾟﾘﾝｸﾞ LPLTM0341QSZ1 定着ｱｰｽ板 Fusing earth plate(DR) [Missing parts code] ﾊｲﾚｼﾞｱｰｽ板...
  • Page 163 Update : 2009/11/16 定着ﾕﾆｯﾄ 2(Fusing unit 2) PRP03918 – 36 –...
  • Page 164 NGERH0090QSZ1 定着駆動ｷﾞﾔ Fusing drive gear(19T) NGERH0084QSZZ ｷﾞﾔ Gear(94/21T) XRESP70-08000 E ﾘﾝｸﾞ E type ring(E7) NGERH0192QSZZ ｷﾞﾔ Gear(46/19T) Gear(39/21T) [MX-M260/M260N/M260FP/M260FG, NGERH0086QSZZ AR-5726] ｷﾞﾔ Gear(39/19T) [MX-M310/M310N/M310FP/M310FG, NGERH0190QSZZ AR-5731] ｷﾞﾔ Gear(30/21T) [MX-M260/M260N/M260FP/M260FG, NGERH0087QSZZ AR-5726] ｷﾞﾔ Gear(30/21T) [MX-M310/M310N/M310FP/M310FG, NGERH0189QSZZ AR-5731] ｷﾞﾔ NGERH0010QSZZ ｷﾞﾔ Gear(28T) NGERH0092QSZZ ｷﾞﾔ...
  • Page 165 Update : 2009/11/16 駆動ﾕﾆｯﾄ (Drive unit) PRP03919 – 38 –...
  • Page 166 Update : 2009/10/16 第一排紙ﾕﾆｯﾄ 1(1st delivery paper unit 1) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time NSFTZ0042QSZ1 排紙従動ﾛｰﾗｰ軸 Delivery sub roller shaft NROLP0049QSZZ 排紙従動ﾛｰﾗｰ Delivery sub roller 排紙従動ﾛｰﾗｰ Delivery sub roller(Large) NROLP0111QSZZ ( 大...
  • Page 167 Update : 2009/10/16 第一排紙ﾕﾆｯﾄ 1(1st delivery paper unit 1) 8 16 PRP03920 – 40 –...
  • Page 168 Update : 2009/11/16 第一排紙ﾕﾆｯﾄ 2(1st delivery paper unit 2) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time XHBS730P08000 (Except North America) ﾋﾞｽ Screw(3×8) RMOTS0071QSPZ (Except North America) ｼﾌﾀｰﾓｰﾀｰ Shifter motor CPLTM0184QS03 (Except North America) ｼﾌﾀｰ駆動板 Shifter drive plate XEBS730P08000 ﾋﾞｽ...
  • Page 169 Update : 2009/11/16 第一排紙ﾕﾆｯﾄ 2(1st delivery paper unit 2) PRP03921 – 42 –...
  • Page 170 PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time IMC PWB [MX-M260/M260N/M260FP/M260FG, CPWBX0136QS3L AR-5726] IMC 基板 IMC PWB [MX-M310/M310N/M310FP/M310FG, CPWBX0136QS3M AR-5731] IMC 基板 XBBS730P08000 ﾋﾞｽ Screw(3×8) PSPAB0039QSZZ ｽﾍﾟｰｻｰ Spacer CPWBF0235QSE1 ｵﾌﾟｼｮﾝ中継基板 Option interface PWB XBBS830P08000 ﾋﾞｽ...
  • Page 171 [MX-M260N/M310N Philippines] PCL VHI29L32077QS BOTDIMMJ PCL BOTDIMMJ VHI29L32079QS [MX-M260N/M310N Except Philippines] BOTDIMMJ PCL BOTDIMMJ [MX-M260FP/M310FP] PCL VHI29L64012QS BOTDIMMJ LBNDJ0013FCZ1 ﾊﾞﾝﾄﾞ Band PSPAN0025QSZZ ｽﾍﾟｰｻｰ Spacer LX-BZ0024QSZZ ﾋﾞｽ Screw 基板部 (PWB section) MX-M260N MX-M310N MX-M260/M310 MX-M260FP MX-M260FG/M310FG MX-M310FP AR-5726/5731 PRP03922 – 44 –...
  • Page 172 Update : 2009/11/16 後ﾌﾚｰﾑ部 (Rear frame section) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time XBPSN40P06K00 ﾋﾞｽ Screw(4×6K) AN2R HL interface harness [Missing parts code] AN2R HL DHAI-0596QSPZ 1st lot 中継ﾊｰﾈｽ TLABZ4868FCZ1 (200V Series) ｱｰｽﾗﾍﾞﾙ Earth label XHBS730P06000 ﾋﾞｽ...
  • Page 173 Update : 2009/11/16 後ﾌﾚｰﾑ部 (Rear frame section) North America only 200V SERIES 100V PRP03923 SERIES – 46 –...
  • Page 174 Update : 2009/11/16 2nd 搬送部 (2nd paper transfer section) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time MSPRC0378QSZ1 ﾛｯｸｽﾌﾟﾘﾝｸﾞ Lock spring MLOKZ0001QSZZ ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞﾛｯｸ Paper guide lock XEPS730P08X00 ﾋﾞｽ Screw(3×8X) 搬送 Transport paper guide PGIDM0068QSZ1 ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ...
  • Page 175 Update : 2009/11/16 2nd 搬送部 (2nd paper transfer section) PRP03927 – 54 –...

  • Page 176: U 2Nd 550 ｶｾｯﾄﾕﾆｯﾄ (2Nd 550 Cassette Unit)

    Update : 2009/10/16 2nd 550 ｶｾｯﾄﾕﾆｯﾄ (2nd 550 cassette unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time LPLTP0159QSZZ ｶｾｯﾄ後端板 Cassette rear edge plate LHLDW1226FCZZ ﾀｰﾝﾌｧｽﾅｰ Turn fastener LPLTM0179QSZ1 回転板 Rotation plate PSHEZ0274QSZZ 回転板ｼｰﾄ...
  • Page 177 Update : 2009/10/16 2nd 550 ｶｾｯﾄﾕﾆｯﾄ (2nd 550 cassette unit) PRP03925 – 50 –...
  • Page 178 Update : 2009/10/16 2nd 給紙部 (2nd paper feed section) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time PCOVP0070QSZZ ｾﾝｻｰｶﾊﾞｰ Sensor cover 2nd ｶｾｯﾄｾﾝｻｰ 2nd cassette sensor PWB CPWBF0095QSE3 基板 上限検知 Upper limit detect actuator MLEVP0063QSZ1 ｱｸﾁｭｴｰﾀｰ...
  • Page 179 Update : 2009/10/16 2nd 給紙部 (2nd paper feed section) 28 2 PRP03926 – 52 –...

  • Page 180: W 2Nd 搬送部 (2Nd Paper Transfer Section)

    Update : 2009/11/16 2nd 搬送部 (2nd paper transfer section) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time MSPRC0378QSZ1 ﾛｯｸｽﾌﾟﾘﾝｸﾞ Lock spring MLOKZ0001QSZZ ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞﾛｯｸ Paper guide lock XEPS730P08X00 ﾋﾞｽ Screw(3×8X) 搬送 Transport paper guide PGIDM0068QSZ1 ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ...
  • Page 181 Update : 2009/11/16 2nd 搬送部 (2nd paper transfer section) PRP03927 – 54 –...

  • Page 182: 2Nd 駆動部 (2Nd Drive Section)

    Update : 2009/10/16 2nd 駆動部 (2nd drive section) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time PCOVP0084QSZZ 2nd 底ｶﾊﾞｰ 2nd bottom cover 2nd ｶｾｯﾄ中継 2nd cassette interface PWB CPWBF0228QSE1 基板 XEBS730P08000 ﾋﾞｽ Screw(3×8) DHAI-0597QSP1 [Missing parts code] 2nd 多段ﾊｰﾈｽ...

  • Page 183: Y ﾘﾌﾄｱｯﾌﾟﾕﾆｯﾄ (Lift Up Unit)

    Update : 2009/10/16 ﾘﾌﾄｱｯﾌﾟﾕﾆｯﾄ (Lift up unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time ﾘﾌﾄｱｯﾌﾟﾓｰﾀｰ Lift up motor unit CMOTV0778FCE3 ﾕﾆｯﾄ NGERH0158QSZ1 ｷﾞﾔ Gear(29T/11T) LDAIU0024QSZ2 ﾘﾌﾄｱｯﾌﾟﾍﾞｰｽ Lift up base NGERH0102QSZZ ｷﾞﾔ Gear(53T/14T) NSFTZ0045QSZZ ｼｬﾌﾄ...

  • Page 184: Zmx-Rp10 外装部 1(Mx-Rp10 Rspf Exteriors 1)

    Update : 2009/11/16 MX-RP10 外装部 1(MX-RP10 Exteriors 1) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time GCAB-0075QST1 後ｷｬﾋﾞ Rear cabinet XEBS740P12000 ﾋﾞｽ Screw(4×12) XHBS730P08000 ﾋﾞｽ Screw(3×8) LSTPP0016QSZZ ｽﾄｯﾊﾟｰ Stopper PCLC-0023QSZZ SPF 給紙ｸﾗｯﾁ SPF paper feed clutch NPLYZ0033QSZZ ｶｯﾌﾟﾘﾝｸﾞﾌﾟｰﾘｰ...
  • Page 185 Update : 2009/11/16 MX-RP10 外装部 1(MX-RP10 Exteriors 1) PRP03930 – 58 –...
  • Page 186 Update : 2009/11/16 MX-RP10 外装部 2(MX-RP10 Exteriors 2) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time CPWBF0139QSE1 SPF 中継基板 SPF interface PWB XHBS730P08000 ﾋﾞｽ Screw(3×8) DHAI-0448QSZZ SPF 中継ﾊｰﾈｽ SPF interface harness LPLTM0111QSZZ 補強板ｱｰｽ板 Reinforce plate earth plate RPLU-0011QSZ2 [Missing parts code] ｹﾞｰﾄｿﾚﾉｲﾄﾞ...
  • Page 187 Update : 2009/11/16 MX-RP10 外装部 2(MX-RP10 Exteriors 2) PRP03931 – 60 –...

  • Page 188: Mx-Rp10 給紙部

    Update : 2009/11/16 MX-RP10 給紙部 (MX-RP10 Paper feeding section) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time GCAB-0076QST1 開閉ｷｬﾋﾞ Open/close cabinet NGERH0166QSZZ 給紙軸ｷﾞﾔ Paper feed shaft gear(20T) PCLC-0316FCP1 ﾄﾙｸﾘﾐｯﾀｰ Torque limiter MLNKP0001QSZZ 呼込みﾘﾝｸ TLPD Pick up link TLPD 呼込みｱｰﾑ...
  • Page 189 Update : 2009/11/16 MX-RP10 給紙部 (MX-RP10 Paper feeding section) PRP03932 – 62 –...

  • Page 190: Mx-Rp10 搬送部

    Update : 2009/11/16 MX-RP10 搬送部 1(MX-RP10 Transport section 1) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time PGIDM0107QSZ1 給紙ｶﾞｲﾄﾞ Paper feed guide PSHEZ0452QSZZ 前捌きｼｰﾄ Front separator sheet PSHEZ0423QSZZ 捌きｼｰﾄ Separator sheet LPLTP0328QSZZ SPF 捌き板 SPF separator plate MSPRC0321QSZ1 圧力ｽﾌﾟﾘﾝｸﾞ...
  • Page 191 Update : 2009/11/16 MX-RP10 搬送部 1(MX-RP10 Transport section 1) PRP03933 – 64 –...
  • Page 192 Update : 2009/11/16 MX-RP10 搬送部 2(MX-RP10 Transport section 2) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time RMOTS0043QSPZ SPF ﾓｰﾀｰ TLPD SPF motor TLPD DHAI-0467QSZZ RSPF ﾊｰﾈｽ RSPF harness PTPE-0018QSZZ ﾓｰﾀｰｱｰｽﾃｰﾌﾟ Motor earth tape XEBS730P08000 ﾋﾞｽ...
  • Page 193 Update : 2009/11/16 MX-RP10 搬送部 2(MX-RP10 Transport section 2) PRP03934 – 66 –...
  • Page 194 Update : 2009/10/16 MX-TR11 第二排紙ﾕﾆｯﾄ (MX-TR11 2nd delivery paper unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time XHBS740P10000 ﾋﾞｽ Screw(4×10) DID ﾚｰﾙ DID rail sub plate CPLTM0216QS01 補助ﾌﾟﾚｰﾄ DID ﾚｰﾙ DID rail sub plate CPLTM0216QS02 09/08 Mid 補助ﾌﾟﾚｰﾄ...
  • Page 195 Update : 2009/10/16 MX-TR11 ｼﾞｮﾌﾞｾﾊﾟﾚｰﾀｰﾕﾆｯﾄ (MX-TR11 Job-separater unit) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time LSOU-0034QST3 [Missing parts code] 2nd 排紙ﾄﾚｲ 1st lot 2nd delivery tray GCOV-0042QST1 ﾚｰﾙﾀﾞﾐｰｶﾊﾞｰ Rail dummy cover MLEVP0066QSZZ ｱｸﾁｭｴｰﾀｰ...
  • Page 196 (Germany,Switzerland,Europe,East Europe) 設置報告書 TCADS1693FCZZ (Japan) 設置報告書 Installation report card TCADZ0098QSZZ (U.kingdom) 保証ｶｰﾄﾞ SUK Warranty card SUK Maintenance card EX CCADZ1518FC01 [MX-M260/M260N/M310/M310N,AR-5726/5731] ﾒﾝﾃﾅﾝｽｶｰﾄﾞ EX Maintenance card J CCADZ1561FC01 [MX-M260FG/M260FP/M310FG/M310FP] ﾒﾝﾃﾅﾝｽｶｰﾄﾞ J TGANE1001QCZB (Australia,New Zealand) SCA 保証書 SCA warranty QCNWG0013QSZZ (Japan) ﾗｲﾝｹｰﾌﾞﾙ...
  • Page 197 Update : 2009/11/16 梱包及び付属品 (Packing material & accessories) Japan Except Japan MX-M260(North America) MX-M260(Except North America) MX-M310(North America) MX-M310(Except North America) MX-M260FG,MX-M310FG MX-M260N,MX-M310N MX-M260FP,MX-M310FP AR-5726,AR-5731 PRP03937 – 70 –...
  • Page 198 Update : 2009/10/16 MX-VR10 梱包及び付属品 (MX-VR10 Packing material & accessories) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time GCOV-0075QSZ1 OC ｶﾊﾞｰ OC cover GCOV-0247FCZZ OC ｽﾄｯｶｰ OC stocker PCUSS0032QSZZ OC ﾏｯﾄ OC mat MHNG-0025QSTZ OC ﾋﾝｼﾞ...
  • Page 199 Update : 2009/10/16 MX-RP10 梱包及び付属品 (MX-RP10 Packing material & accessories) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time SPAKA0088QSZZ 保護ｼｰﾄ Protect packing sheet CFIX-0012RS54 SPF ｶﾞﾗｽﾕﾆｯﾄ SPF glass fixing plate unit SSAKZ0004QSZZ ﾎﾟﾘ袋 Vinyl bag(80×450) SSAKH3012KCZZ ﾎﾟﾘ袋...
  • Page 200 Update : 2009/10/16 MX-TR11 梱包及び付属品 (MX-TR11 Packing material & accessories) PRICE RANK NEW Inter- PART Effective PARTS CODE DESCRIPTION TR No. change MARK RANK time XEBS740P10000 ﾋﾞｽ Screw(4×10) XHBS740P10000 ﾋﾞｽ Screw(4×10) SSAKA0006UCZZ ﾎﾟﾘ袋 Vinyl bag(50×60) LHLDZ0149QSZZ 第 2 排紙ﾎﾙﾀﾞｰ 2nd delivery holder SSAK-4271CCZZ ﾎﾟﾘ袋...
  • Page 201 © COPYRIGHT 2009 BY SHARP CORPORATION All rights reserved. Printed in Japan. No part of this publication may be reproduced, stored in a retrieval system, or transmitted. In any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

This manual is also suitable for:

Ar-5731

Table of Contents
