- Page 1 INSTALLATION GUIDE S57XXT 15 T RANS PO RT SEAT 2015 - 2020 CHE V ROLE T TA H OE S T R O N G R E L I A B L E S E C U R E pro-gard.com RELEASED 11.2020 800.480.6680...
-
Page 2: Barrier Installation
THESE COMPONENTS ARE REQUIRED TO INSTALL THE PRO-GARD TRANSPORT SEAT 4BWK57TAH WING HARDWARE KIT 4SHK5715 4B57XXT15 4BK5715 3S5715 4S57T15 BARRIER BARRIER KIT SEAT HARDWARE SEAT SEAT KIT 4BHK5715 I. Refer to the diagram above to verify all parts were received. BARRIER HARDWARE II. -
Page 3: Seat Installation
V. Seat Installation A. Install seat support bracket 3S5715-01 onto the barrier using the 3X03 bolts and 3X16 nuts already installed on the barrier. Tighten all fasteners. (Fig. 1) B. Hold the 3P5732 seat support bracket upright near the center of the vehicle with the angled leg facing towards the front of the vehicle. -
Page 4: Installation Complete
C. Insert the (4) 4S5070P1 spacers over the (4) OEM studs. The studs are located just behind the driver and passenger seat. D. Place the Pro-Gard Transport Seat into the vehicle. Align the (4) OEM studs with the (4) holes located in the seat. - Page 5 pro-gard.com 800.480.6680...
