Summary of Contents for amzchef SK-67HLB4T1
- Page 3 1. Make sure the size of the electric ceramic cooktop (DxWxH): (561~563)*(498~500)mm/(22.09~22.17)*(19.61~19.69)inch 2.28inch...
-
Page 4: Table Of Contents
CONTENT Safety Warnings � Product Overview � Product Information � Using your Ceramic Hob � Using the timer function � Using Large Heating Area-Ceramic Hob �� Care and Cleaning �� Hints and Tips �� Installation �� Warranty �� Made in China Manufacturer: Zhongshan SUKIO Electric Appliance., Ltd. -
Page 5: Safety Warnings
Safety Warnings... -
Page 9: Product Overview
6. Control panel Control panel 1.Selection Control 2.Triple/Oval adjustment Control 3.Safety Lock 4.+/- (up&down） Control 5.Timer 6.ON/OFF button Product Parameter Model SK-67HLB4T1 Cooking Zones 4 Zones Supply Voltage AC 220-240V~ 50-60Hz Installed Electric Power 6700W Product Size L×W×H 770*520*58mm 30.31*20.47*2.28inch Building-in Dimensions A×B... -
Page 10: Product Information
Product Information The ceramic hob can meet different kinds of cuisine demands because of resistance wire heating, senior control and multi-power selection, really the optimal choice for modern families. The ceramic hob centers on cus- tomers and adpots personalized design. The hob has safe and reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life. -
Page 11: Using Your Ceramic Hob
Using your Ceramic Hob... - Page 12 The corresponding power indicator will start flashing "5". 4.When you switch on the hob and select the cooking zone, the default gear is 5, you need to select 1-4 levels please press the "-" button, if you need to select 6-9 levels, please press the "+" button. When you want finished cooking 1.When you want to stop a cooking zone individually: press the button of the cooking zone corresponding to the one you want to stop cooking and...
-
Page 13: Using The Timer Function
Using the timer function Select the desired cooking zone with the corresponding selection control. Then press the Timer key. The timer display will show 30 min.As long as the tens digit is flashing, You can adjust it by touching the "+", "-". After the set time has expired, the corresponding cooking zone is auto- matically switched off. - Page 14 Setting: Setting: 5 min. 15 min. Remaining Remaining time: time: 0 min. 10 min. To lock the control panel Touch and hold the keylock butoon 3 seconds.
-
Page 15: Using Large Heating Area-Ceramic Hob
cooktop. Using Large Heating Area-Ceramic Hob The cearmic hob have one or several extended cooking zones(Oval/Triple zone),these extended zones can provide larger cooking area and additional heat to fit for different size of cooking pan. To use Extended zone when hob is working,followes below: 1. - Page 16 Activating the oval/triple extended zone function Oval zone 1.Select the oval area and set a power level 2.Now press the corresponding cooking zone selection button again while the heating level indicator is flashing. Subsequently press the button, the hob will display and the extend- ed area function is switched on.
-
Page 17: Residual Heat Warning
Residual Heat Warning When the cooker has been operating for some time,there will be some residual heat.The letter "H" appears to warn you to keep away from it. Take care when frying as the oil and fat heat up very quickly, At extremely high temperature oil and fat will ignite spontaneously and this presents a serious fire risk. -
Page 18: Care And Cleaning
Care and Cleaning... -
Page 19: Hints And Tips
Hints and Tips... -
Page 21: Installation
Installation 1. Make sure the size of the electric ceramic cooktop (DxWxH): (561~563)*(498~500)mm/(22.09~22.17)*(19.61~19.69)inch 2.28inch... - Page 24 75℃/167℉...
