- Page 1 USER MANUAL 30 Inch Built-in Electric Cooktop Brand: amzchef Model: SK-67HLA30K2 220-240V~ 50-60Hz 6700W...
- Page 2 Welcome to the Amzchef Family! Cheers to you for owning a new Amzchef product! We are devoted to making high-quality kitchen, home, and personal care products for all our customers. As a respected manufacturer, all our products adhere to rigorous standard, safety, and functionality.
-
Page 3: Installation Instruction
Table of contents Installation Instruction Cleaning & Care Safety Precautions Troubleshooting Hints & Tips Error Codes Getting to Know Your Appliance Technical Specification Setting the Hob Installation Instruction After unpacking the appliance, ensure there is no visible damage. If it has been damaged during transit, DO NOT USE, contact where you buy immediately. - Page 4 Connecting the hob to the mains Make sure that the data on the rating plate (V) matches your supply voltage. To connect the hob to the mains power supply, do not use adapters, reducers, or branching devices as they can cause overheating and fire. If the cable is damaged or needs to be replaced, this must be done by a qualified electrician with the correct tools.
-
Page 5: Safety Precautions
Ventilation Make sure the hob is well-ventilated and the air inlet and outlet are not blocked: Item Data (”) Data (mm) 29.92” 760 mm min. 1.97” min. 50 mm min. 0.79” min. 20 mm Air intake min. 0.39” min. 10 mm (Air exhaust) Note: The safety distance between the hob and the cupboard above the hob should be at least 760 mm / 29.92 inch. - Page 6 This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or instructed by a person responsible for their safety how to use the appliance safely and have understood the associated hazards.
-
Page 7: Hints And Tips
Overview The following table provides an overview of the most frequent kinds of damage: Damage Cause Action Stains Food Spills Remove spills immediately with a glass scraper. Unsuitable cleaning agents Only use cleaning agents that are suitable for ceramic. Scratches Salt, sugar and sand Do not use the hob as a work surface or storage space. -
Page 8: Getting To Know Your Appliance
Getting to Know Your Appliance Overview Control panel Knob control for zone Knob control for zone Knob control for zone Knob control for zone Hotplate indicator The hotplates Hotplate Indicator Rotate the knob to set a heat setting for the hotplate. When the hotplate is connected, the related hotplate indicator lights up. -
Page 9: Setting The Hob
Setting the Hob This part provides instructions on how to set the hotplates. Stand-by Starting to cook Mode 1. Rotate the knob to the desired heat setting. The hotplate indicator will light up to show that it is on and heating will start right away. Heat setting 1 = lowest setting Dual Zone Single Zone... -
Page 10: Cleaning And Care
Cleaning & Care The information in this section provides help on how best to care for your hob. Note: Before cleaning, be sure the controls are turned OFF and the hob is cool. Daily use To remove fingerprints and food stains, apply a vitro-ceramic glass cleaner, ensuring thoroughly rinse and wipe dry. -
Page 11: Error Codes
The ceramic hob makes a low This is caused by the This is normal, but the noise should humming noise technology of ceramic quieten down or disappear when you when used in a high cooking. decrease the heat setting. heat setting. A cooling fan built into your ceramic hob has come on to prevent the... -
Page 12: Technical Specification
Technical Specification Model SK-67HLA30K2 Cooking Zones 4 Zones Supply Voltage 220-240V~ 50-60Hz Installed Electric Power 6700W Product Size L×W×H 770mm×520mm×75mm 30.31”×20.47“×2.95” Building-in Dimensions L×W (723~725)×(483~485) mm (28.46~28.54)×(19.02~19.09) inch Weight and Dimensions may vary due to improvement. We may change specifications and designs without prior notice.
