- Page 1 1200W 1200W 1000W 2000W 3000W 1800W 1800W USER MANUAL 30 Inch Built-in Electric Cooktop Brand: amzchef Model: SK-90HLA30T4 220-240V~ 50-60Hz 9000W...
- Page 2 Welcome to the Amzchef Family! Cheers to you for owning a new Amzchef product! We are devoted to making high-quality kitchen, home, and personal care products for all our customers. As a respected manufacturer, all our products adhere to rigorous standard, safety, and functionality.
-
Page 3: Table Of Contents
Table of contents Installation Instruction Child Lock Safety Precautions Cleaning & Care Hints & Tips Troubleshooting Getting to Know Your Appliance Error Codes Setting the Hob Technical Specification Installation Instruction After unpacking the appliance, ensure there is no visible damage. If it has been damaged during transit, DO NOT USE, contact where you buy immediately. - Page 4 Connecting the hob to the mains Make sure that the data on the rating plate (V) matches your supply voltage. To connect the hob to the mains power supply, do not use adapters, reducers, or branching devices as they can cause overheating and fire. If the cable is damaged or needs to be replaced, this must be done by a qualified electrician with the correct tools.
-
Page 5: Safety Precautions
Ventilation Make sure the hob is well-ventilated and the air inlet and outlet are not blocked: Item Data (”) Data (mm) 29.92” 760 mm min. 1.97” min. 50 mm min. 0.79” min. 20 mm Air intake min. 0.39” min. 10 mm (Air exhaust) Note: The safety distance between the hob and the cupboard above the hob should be at least 760 mm / 29.92 inch. - Page 6 This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or instructed by a person responsible for their safety how to use the appliance safely and have understood the associated hazards.
-
Page 7: Hints & Tips
Overview The following table provides an overview of the most frequent kinds of damage: Damage Cause Action Stains Food Spills Remove spills immediately with a glass scraper. Unsuitable cleaning agents Only use cleaning agents that are suitable for ceramic. Scratches Salt, sugar and sand Do not use the hob as a work surface or storage space. -
Page 8: Getting To Know Your Appliance
Getting to Know Your Appliance Overview 1200W 1200W 1000/2000/3000W 1000W 2000W 3000W 1800W 1800W Control panel Power button Touch control for zone Touch control for zone Touch control for zone Touch control for zone Touch control for zone Dual/Triple zone selection Child lock The hotplates Hotplate... -
Page 9: Setting The Hob
Notes: - When you touch a button, an audible signal sounds and the respective function is activated. - Always keep the controls dry. Moisture reduces their effectiveness. - Do not pull pans close to the displays and sensors. The electronics could overheat. -
Page 10: Child Lock
Reheating Rapid simmering Cooking rice Pancakes Sautéing Cooking pasta Stir-frying Searing Bringing soup to the boil, boil water Stop cooking To turn off the hotplate, touch the related ON/OFF button. Once turned off, the residual heat indicator appears. To switch off the appliance, press the POWER button. Child Lock You can lock the control panel to prevent unintended use (e.g., by children accidentally switching on the cooking zones). -
Page 11: Troubleshooting
Damage from Sugary Spills and Melted Plastic Special care should be taken when removing hot substances to avoid permanent damage to the glass surface. Sugary spillovers (such as jellies, fudge, candy, and syrups) or melted plastics can cause pitting of the surface of your hob (not covered by the warranty) unless the spill is removed while still hot. -
Page 12: Error Codes
The above is the judgment and inspection of common failures. Please do not attempt to disassemble the unit yourself to prevent any potential dangers or damage to the hob. Technical Specification Model SK-90HLA30T4 Cooking Zones 5 Zones Weight and Dimensions may Supply Voltage 220-240V~ 50-60Hz vary due to improvement.
