- Page 1 INSTALLATION MANUAL 2266741 Wolfen Lead Free Trigger Spray 2266742 Wolfen Lead Free Pre Rinse Sink Mixer Tap with Pot Filler - Compact 2266743 Wolfen Lead Free Pre Rinse Sink Mixer Tap with Pot Filler Installation Details | Warranty...
- Page 2 CONTENTS Intro Technical Information Unit Components Installation Instructions Warranty...
- Page 3 Ergonomic design combined with precision engineering ensures that every Wolfen product is easy-to-use and made to last. Here are just some of the many innovative features that make Wolfen mixers the smart solution. Scope of Use :...
-
Page 4: Technical Information
Max Continuous 80°C 80°C 80°C Working Temperature Max Static Pressure 500kPa 500kPa 500kPa Height 954mm 615mm Clearance (Pot Filler) 205mm 205mm Reach (Trigger Spray) 250mm 250mm Recommended 350kPa 350kPa 350kPa Working Pressure WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer... - Page 5 Wolfen Lead Free Pre Rinse Sink Mixer Tap with Pot Filler 2266743 Wolfen Lead Free Pre Rinse Sink Mixer Tap with Pot Filler - Compact 2266742...
-
Page 6: Unit Components
Pot filler handle body Pex hose Cold Circlip JETF9007 Red fibre washer JETF9009 SS spring washer JETFLF0064 Pot filler spindle Pot filler outlet O-ring O-ring Riser-mixer connection Ring O-ring O-ring Riser body2 Friction ring O-ring JETF0061 Trigger spray holder Check Valve WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer... -
Page 8: Installation Instructions
2 to 5mm gap from the wall. *To ensure longevity of the product we recommend Pressure reduction valves (PRV’s) not pressure limiting valves (PLV’s) set at 350kPa working pressure (hot/cold). WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer... - Page 9 19. Using the open ended spanner provided, screw 2. Using Loxeal the M15 end of the flexible hose into the top of • Insert the white teflon washer into the hose the riser assembly. Do up firmly but do not over adaptor. tighten. Support the weight of the hose and spring • Apply Loxeal to the male thread of the trigger while tightening to prevent cross threading and spray. kinking of the hose. 20. Slide the spring back over the end of the hose • Screw hose connection on to trigger spray then until it sits on top of the riser assembly.
-
Page 10: Year Warranty
The installation of the product is in accordance with • the instructions provided This warranty does not cover products purchased as an ex-display without being fully checked and tested Don’t risk it, use a licensed plumber.™ for sale by the manufacturer. WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer... - Page 11 IF AFTER CHECKING THE INSTALLATION INSTRUCTIONS AND IMPORTANT INFORMATION, THE PROBLEM HAS NOT BEEN IDENTIFIED, PLEASE CONTACT GENTEC CUSTOMER SUPPORT ON: +61 2 9319 4422 or info@gentecaustralia.com.au...
