- Page 1 INSTALLATION MANUAL 2264795 Wolfen Pre Rinse Sink Mixer Tap with Pot Filler Stainless Steel (6 Star) 2264796 Wolfen Pre Rinse Sink Mixer Tap with Pot Filler Stainless Steel - Compact (6 Star) Installation Details | Warranty...
- Page 2 CONTENTS Intro Technical Information Unit Components Installation Instructions Warranty...
- Page 3 Designed for absolute performance, Wolfen’s commercial mixer products set new standards in quality and durability. Ergonomic design combined with precision engineering ensures that every Wolfen product is easy-to-use and made to last. Here are just some of the many innovative features that make Wolfen mixers the smart solution.
- Page 4 Model Pre Rinse Sink Mixer Compact Pre Rinse Sink Mixer Product Code 2264795 2264796 Product Type Pre-Rinse unit Pre-Rinse unit Stainless Satin Finish Stainless Satin Finish Finish Stainless Steel (304) Stainless Steel (304) Material Inlet 15mm 15mm Outlet Blade Spray (Aerator Spray available)
- Page 5 WOLFEN INSTALLATION MANUAL | Technical Information TECHNICAL INFORMATION Stainless Steel Hob Mounted Pre Rinse Unit with Pot Filler 2264795 Stainless Steel Hob Mounted Pre Rinse Unit with Pot Filler 2264795 WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer...
- Page 6 Stainless Steel Compact Hob Mounted Pre Rinse Unit with Pot Filler 2264796 Stainless Steel Compact Hob Mounted Pre Rinse Unit with Pot Filler 2264796...
- Page 7 WOLFEN INSTALLATION MANUAL | Technical Information PRE RINSE TRIGGER SPRAY SS 2266397 PRE RINSE TRIGGER SPRAY SS 2266397 WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer...
- Page 8 Trigger Spray Gun Aerator Kit GPJ1500 Handles "O" Ring Kit Pot filler Aerator Housing Aerator GPJ0064 C/ Disk Catridge GPJ0065 Handle Kit Body GPJ0068 "O" Ring Kit for Pot Filler GPJ9005 Fibre Washer WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer...
- Page 10 Screw on the hex nuts (36) until the mixer base is firmly fixed to the sink. Tighten with a socket set or tube spanner. Connect the hot and cold flexible connectors to the inlet isolation valves. WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer...
- Page 11 WALL BRACKET INSTALLATION The Wall Bracket Installation is an essential part for the correct operation and use of the Stainless Steel Pre Rinse IMPORTANT INFORMATION Unit. • The wall support bar (6) can slide up or down to the Measure and cut the wall support bar (6) to a length desired height by slowly twisting it back and forth with a 2 to 5mm gap from the wall.
- Page 12 Screw hose connection on to trigger spray then tighten firmly against oring. Test to ensure there are no leaks. Note: For optimum operational life, water supply pressure should not exceed 450kPa. WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer...
- Page 13 WOLFEN INSTALLATION MANUAL | Maintenance MAINTENANCE FOR OPTIMUM PERFORMANCE AND DURABILITY Service inspections at regular intervals especially in high usage areas will assist in optimising the operational life of the product. Ensure the Blade Spray nozzle outlet is inspected and cleaned at regular intervals to maintain the units water spray efficiency and effectiveness.
- Page 14 90° angle and/or if the mixer at the base of the product has been left on when not in use. Also check that the water pressure is not above 500kPa as that will also void warranty WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer...
- Page 15 12. The wall bracket doesn’t fit our kitchen, can we remove it or modify it? The wall bracket is designed to support the riser so removing it or extending it will put extra pressure on the riser and lead to leaks from the riser and/or bottom mixer.
- Page 16 • Proof of purchase (including the date of purchase) is provided • The installation of the product is in accordance with the Don’t risk it, use a licensed plumber.™ instructions provided WOLFEN INSTALLATION MANUAL | Wolfen Pre Rinse Sink Mixer...
- Page 17 IF AFTER CHECKING THE INSTALLATION INSTRUCTIONS AND IMPORTANT INFORMATION, THE PROBLEM HAS NOT BEEN IDENTIFIED, PLEASE CONTACT GENTEC CUSTOMER SUPPORT ON: +61 2 9211 4422 or info@gentecaustralia.com.au...
- Page 18 reece.com.au/wolfen...
