TM
INSTALLATION
MANUAL
9508240 Wolfen Timed Flow Basin Mixer (6*)
9508241 Wolfen Timed Flow Basin Tap (Cold) (6*)
9508242 Wolfen Timed Flow Basin Tap (Warm) (6*)
9508243 Wolfen Timed Flow Bib Tap 65 (Cold) (6*)
9508244 Wolfen Timed Flow Bib Tap 65 (Warm) (6*)
9508245 Wolfen Timed Flow Bib Tap 95 (Cold) (6*)
9508246 Wolfen Timed Flow Bib Tap 95 (Warm) (6*)
Installation Details | Warranty
Advertisement
Related Manuals for Wolfen Timed Flow 9508240
Summary of Contents for Wolfen Timed Flow 9508240
- Page 1 9508241 Wolfen Timed Flow Basin Tap (Cold) (6*) 9508242 Wolfen Timed Flow Basin Tap (Warm) (6*) 9508243 Wolfen Timed Flow Bib Tap 65 (Cold) (6*) 9508244 Wolfen Timed Flow Bib Tap 65 (Warm) (6*) 9508245 Wolfen Timed Flow Bib Tap 95 (Cold) (6*)
- Page 2 CONTENTS Intro Technical Information Installation Instructions Cleaning Warranty...
- Page 3 Designed for absolute performance, Wolfen’s commercial timed-flow tapware sets new standards in quality and durability. Ergonomic design combined with precision engineering ensures that every Wolfen product is easy-to-use and made to last. Here are just some of the many innovative features that make Wolfen timed-flow tapware the smart solution.
- Page 4 Max Continuous Flow 500kPa 500kPa Working Pressure Min Continuous 2°C 2°C Working Temperature Max Continuous 50°C 50°C Working Temperature 6 Star Rating 6 Star Rating WELS 3.0 Litres Per Minute 3.5 Litres Per Minute WOLFEN INSTALLATION MANUAL | Wolfen Timed-Flow Tapware...
- Page 5 Wolfen Timed-Flow Mixer WOLFEN �med-flow mixer Wolfen Timed-Flow Taps WOLFEN �med-flow taps...
- Page 6 WOLFEN INSTALLATION MANUAL | Technical Information TECHNICAL INFORMATION Wolfen Timed-Flow Basin Mixer (6*) 9508240 Wolfen Timed-Flow Basin Tap (Cold) (6*) 9508241 Wolfen Timed-Flow Basin Tap (Warm) (6*) 9508242 G1/2" WOLFEN INSTALLATION MANUAL | Wolfen Timed-Flow Tapware...
- Page 7 Wolfen Timed Flow Bib Tap 65 (Cold) (6*) 9508243 Wolfen Timed Flow Bib Tap 65 (Warm) (6*) 9508244 G1/2 Wolfen Timed-Flow Bib Tap 95 (Cold) (6*) 9508245 Wolfen Timed Flow Bib Tap 95 (Warm) (6*) 9508246 G1/2...
- Page 8 All mixers should be installed with isolating This tap has a recommended continuous flow stop cocks (Arco). working pressure of 100kPa to 500kPa Installation Attention R > Ø100mm = OK R < Ø100mm = NOT OK WOLFEN INSTALLATION MANUAL | Wolfen Timed-Flow Tapware...
- Page 9 25 mm max. Ø35mm 2 N.m G1/2˝...
- Page 10 Cold water 15°C / 300 kPa + hot water 60°C / 300 kPa = 38°C Obtain the correct inlet pressures and adjust them to 300 kPa : ΔP < 40kPa To ensure anti-scalding on the mixers, install a thermostatic valve. WOLFEN INSTALLATION MANUAL | Wolfen Timed-Flow Tapware...
- Page 11 MAINTENANCE 5 - Maintenance 5 - Maintenance 5-1 Maintenance of the flow aerator Maintenance of the flow aerator 5-1 Maintenance of the flow aerator 0.5 N.m 0.5 N.m 5-2 Maintenance of the mixer shaft 5-2 Maintenance of the mixer shaft Maintenance of the mixer shaft 2 N.m 2 N.m...
- Page 12 9508241 | 9508242 | 9508243 | 9508244 |9508245 | 9508246 Please flush out new pipe work prior to This tap has a recommended continuous flow connecting the new Timed-Flow Taps. working pressure of 100kPa to 500kPa WOLFEN INSTALLATION MANUAL | Wolfen Timed-Flow Tapware...
- Page 13 MAINTENANCE Maintenance of the flow aerator Maxi 0,5 N.m Maintenance of the head CLEANING We recommend the use of soap water or approved cleaners. This product should not be cleaned with abrasive materials, acid, alkaline or ammonia-based household products. Damage caused by any improper treatment is not covered by the product warranty.
- Page 14 • Proof of purchase (including the date of purchase) is provided • The installation of the product is in Don’t risk it, use a licensed plumber.™ accordance with the instructions provided WOLFEN INSTALLATION MANUAL | Wolfen Timed-Flow Tapware...
- Page 15 IF AFTER CHECKING THE INSTALLATION INSTRUCTIONS AND IMPORTANT INFORMATION, THE PROBLEM HAS NOT BEEN IDENTIFIED, CUSTOMERS ARE TO CONTACT THE BRANCH WHERE THE PRODUCT WAS PURCHASED. THESE DETAILS CAN BE FOUND ON YOUR PURCHASE INVOICE. General contact details for Reece are as follows: Reece Australia Pty Ltd 118 Burwood Hwy Burwood VIC 3125...
- Page 16 reece.com.au/wolfen...
