Parkour: Mega Box
9'W x 12'L x 9'H
Part Number
Panel TE
Top End Panels
Panel TM
Top Middle Panel
Panel BE
Bottom End Panels
Panel BM
Bottom Middle Panel
Panel
Side Left Panels
SL
Panel
Side Right Panels
SR
Panel
Side Middle Panels
SM
Interior Structural
2' x 4' Top & Bottom Plates
Frames
*CUSTOM*
Interior Side Support Posts
*CUSTOM*
Plywood Side Wall Support Panel
*CUSTOM*
2' x 4' 103 1/2" Connector Strip
*CUSTOM*
6' Angular Base Panel End Support Strips
*CUSTOM*
39 1/2" Temporary Frame Stabilizer Strap
P2STBK
2" Screws
PTN3S5
3" Screws
Part Description
Quantity
2
1
2
1
4
4
2
2
2
2
2
2
Need help?
1
Call 1-800-932-3339 or
460
Email info@gymsupply.com
75
Advertisement
Related Manuals for DGS Parkour: Mega Box
Summary of Contents for DGS Parkour: Mega Box
- Page 1 Parkour: Mega Box 9’W x 12’L x 9’H Part Number Part Description Quantity Panel TE Top End Panels Panel TM Top Middle Panel Panel BE Bottom End Panels Panel BM Bottom Middle Panel Panel Side Left Panels Panel Side Right Panels...
- Page 2 Instruction Manual Parkour: Mega Box Recommended Tools: REAR WALL † Power Drill TE TM TE SIDE WALL † Flat Bar SL SM SR † Measuring Tape † Chalk Line Reel SIDE WALL † 8’ Step Ladder FRONT WALL SL SM SR...
- Page 3 Instruction Manual Parkour: Mega Box Step 2: After assembling the two Interior Structual Frames, stand the frames on top of the Temporary Spacer Blocks that are mounted on each frame. Using the Frame Stabilizer Strip, screw in between frames on the opposite side from where the base panels connect so that the frames measure 3 ft on center.
- Page 4 Instruction Manual Parkour: Mega Box IMPORTANT: In order to lay the cube over its base, you must support the base ends to prevent any damage when laying the base down. Step 6: Secure diagonal braces on the outer most 2’ x 4’ plywood rib as illustrated in the picture using (2) 2”...
- Page 5 Instruction Manual Parkour: Mega Box Step 9: Looking at the cube base and two connected frames with base panels labled left to right: BE - BM - BE Apply Panel SL onto edge of Panel BE making sure lower left edge is flush with base edge and secure Panel BE with 2”...
- Page 6 Instruction Manual Parkour: Mega Box Step 11: Continue third frame bay by applying Panel SR, Panel SL, Panel SR and Panel SL. Always secure to base before connecting wall panels. Apply a 2’ x 4’ 103 1/2” Connector Strip to the 9’ x 9’ side panels evenly and secure with 2”...
