SERVICE MANUAL
(without price)
ELECTRONIC CASH REGISTER
FE-5000G
(EX-273-GRE)
FEB. 2004
INDEX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FE-5000G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Casio FE-5000G

Summary of Contents for Casio FE-5000G

  • Page 1 SERVICE MANUAL (without price) ELECTRONIC CASH REGISTER FE-5000G (EX-273-GRE) FEB. 2004 INDEX...

  • Page 2: Table Of Contents

    CONTENTS FE-5000G PAGE 1. SPECIFICATIONS..................1 2. INITILAIZE OPERATION ................3 3. BLOCK DIAGRAM ..................5 4. DISASSEMBLY .................... 6 5. CIRCUIT EXPLANATIONS ................ 14 6. DIAGNOSTIC OPERATION ............... 24 7. ERROR CODE LIST................... 41 8. IC DATA ..................... 45 9.

  • Page 3: Specifications

    1. SPECIFICATIONS 1-1. Electrical specifications 230 V •Power consumption In operation Max. 0.35 A stand-by Max. 0.2 A •Memory protection Back-up battery VL3032/1F2 (Vanadium lithium battery) 60 days (25 °C) Back-up period Battery life Replace the battery every 5 years. Recharge time 48 hours (full charge) Within ±...
  • Page 4 1-4. Drawer List Type Drawer Name Specification • M DL-2776 D-18D2C-A84RM-13 1-5. Option List Device Name Model Note • Roll paper P-588OT • Sheet cover WT-82 • PC cable PRL-CB-2 Com1 port only • Handy scanner HHS-15 Com2 port only •...

  • Page 5: Initilaize Operation

    2. INITIALIZE OPERATION 1) Hard SW Init-SW: located on the main board (on the right). Press this switch for about one second and then release it so that the register enters the Init state. 2) Initialize 1. Turn off the power and remove the battery. 2.
  • Page 6 4) Init2 1. Keep InitSW depressed for about one or two seconds and then release it so that “INIT” “0000000000” is lit. 2. Input four-digit pass code. (The first time is voluntary) Input ****<ΜΕΤΡΗΤΑ>. Ex) 1234 <ΜΕΤΡΗΤΑ> 3. “INIT”, “0” is displayed within five to 44 seconds. Input the Init2 code.

  • Page 7: Block Diagram

    3. BLOCK DIAGRAM POP UP DISPLAY PS-272-2D E273GRE-E2-2 POWER PRINTER PRINTER MAIN DISPLAY E273GRE-E2-1 E272-PR E272-PR DRAWER (PC/MODEM) MODE SW E475-E3 COM 1 Option RAM FISCAL ROM E466-ROM (HAND SCANNER) E273GRE-ROM COM 2 INIT-SW KEY BOARD E273GRE-1 BATTERY WINDER (VL3032/1F2) —...

  • Page 8: Disassembly

    4. DISASSEMBLY UPPER COVER 1. Remove the printer cover. 1 Remove one screw. 2 Slide the DISPLAY PANEL in the direction of the arrow and remove the hook. 3 Slide the DISPLAY PANEL and lift it up. 4 Remove two FPCs (CN2, CN3). 5 Remove the BLIND SHEET.

  • Page 9: Printer Unit

    1 Remove two screws. 2 Slide the KEY UNIT to front side and lift it up. Then remove one FPC (CNKEY1). Screws CNKEY1 (30PIN) PRINTER UNIT 1. Remove the upper cover as shown in steps 1 to 3 of page 5 to 6. 2.
  • Page 10 5. Remove two FPCs (CN2). 6. Remove four screws and one connector (CNWIN1). Screws CNWIN1 7. Removing the PRINTER UNIT 1 Remove five screws. 2 Remove the joint PCB. 3 Remove the PRINTER UNIT while pressing one hook as shown in the figure. Screws opposite side Hook...

  • Page 11: Main Display

    MAIN DISPLAY 1. Remove the upper cover as shown in steps 1 to 3 of page 5 to 6. 2. Remove one FPC (CN1). 3. Remove four hooks and the MAIN DISPLAY. Hooks CN1(23PIN) POWER SUPPLY UNIT 1. Remove the upper cover as shown in steps 1 to 3 of page 5 to 6. 2.
  • Page 12 MAIN PCB 1. Remove the upper cover as shown in steps 1 to 3 of page 5 to 6. 2. Remove six screws and eight connectors, and then the MAIN PCB and BATTERY ASS’Y. CNP 1 ( 0PIN) ( 0PIN) PIN) CNBAT1 CN IN1...
  • Page 13 DRAWER (M type DRAWER) 1. Remove the lower tray. 1 Push the lever in the direction of the arrow and pull out the lower tray. Bottom side 2 Remove the COIN CASE. 3 Remove the BILL CASE. 4 Remove the tray. 2.
  • Page 14 3. Remove the UPPER COVER. 1 Remove four screws. 2 Open the case to some extent and remove the upper cover by lifting it up. Hooks Hooks Screws 4. Remove the upper tray. 5. Remove four screws and then the RAIL. Screws 6.
  • Page 15 7. Remove the upper cover. 1 Remove three screws and the solenoid. 2 Remove the spring. Screws 1 Remove the HOOK LEVER by removing its stopper from the bottom surface. 2 Remove the HOOK LEVER. — 13 —...

  • Page 16: Circuit Explanations

    5. CIRCUIT EXPLANATION 5-1. POWER SUPPLY CIRCUIT The power supply circuit provides the following voltage for the main circuit. Output Pin No. 1 (DC20~31V) For the drawer. Output Pin No. 2 (DC5V) For the logic circuit power. Output Pin No. 3 (DC8V) For the printer.

  • Page 17: Pin Assignment

    5-2. CPU (IC7: uPD784215AGC8038EU) / I/O CONTROLLER (IC23: uPD784215AGC2418EU) 5-2-1. Pin Assignment P120/RTP0 P62/A18 P121/RTP1 P61/A17 P122/RTP2 P60/A16 P123/RTP3 P124/RTP4 P57/A15 P125/RTP5 P56/A14 P126/RTP6 P55/A13 P127/RTP7 P54/A12 P53/A11 P52/A10 P51/A9 P50/A8 P47/AD7 P46/AD6 RESET P45/AD5 P00/INTP0 P44/AD4 P01/INTP1 P43/AD3 P02/INTP2/NMI P42/AD2 P03/INTP3 P41/AD1...
  • Page 18 5-2-2. Block Diagram RxD1/SI1 INTP2/NMI PROGRAMMABLE UART/IOE1 TxD1/SO1 INTERRUPT INTP0, INTP1, BAUD-RATE ASCK1/SCK1 INTP3-INTP6 CONTROLLER GENERATOR RxD2/SI2 TI00 UART/IOE2 TxD2/SO2 TIMER/COUNTER TI01 BAUD-RATE (16 BITS) ASCK2/SCK2 GENERATOR CLOCKED TIMER/COUNTER1 SERIAL (8 BITS) INTERFACE SCK0 AD0-AD7 TIMER/COUNTER2 (8 BITS) A0-A7 A8-A15 TIMER/COUNTER5 BUS I/F TI5/TO5...
  • Page 19 5-2-3. Pin Function PIN NO. PIN NAME DESCRIPTION P120/RTP0 P121/RTP1 P122/RTP2 P123/RTP3 8 bit input/output PORT P124/RTP4 P125/RTP5 P126/RTP6 P127/RTP7 Power Supply Main system Clock Sub system Clock RESET Reset P00/INTP0 P01/INTP1 P02/INTP2/NMI P03/INTP3 7 bit input/output PORT P04/INTP4 P05/INTP5 P06/INTP6 AVDD A/D CONVERTER POWER SUPPLY...
  • Page 20 PIN NO. PIN NAME DESCRIPTION P83/A3 P84/A4 P85/A5 8 bit input/output PORT P86/A6 P87/A7 P40/AD0 P41/AD1 P42/AD2 P43/AD3 8 bit input/output PORT P44/AD4 P45/AD5 P46/AD6 P47/AD7 P50/A8 P51/A9 P52/A10 P53/A11 8 bit input/output PORT P54/A12 P55/A13 P56/A14 P57/A15 P60/A16 P61/A17 P62/A18 P63/A19 8 bit input/output PORT...

  • Page 21: Reset Circuit

    5-3. RAM CIRCUIT (IC17: M5M5408BFP) The RAM circuit is as follows: The RAM are used at high and low data. The data in the RAM will be lost when the battery voltage becomes under 2V. 5-4. RESET CIRCUIT The reset circuit is as follows: CPU will be in a reset state when the low signal input to /RESET.
  • Page 22 5-5. RS-232 CIRCUIT The RS-232 circuit is as follows: The RS-232 transceiver ICs are as IC13 and IC15. COM1 is for PC and modem. COM2 is for handy scanner. 0.33u/25V IC13 0.33u/25V 0.1u 0.047u FORCEON 0.33u/25V PC/MODEM /FOROFF /INVALID P122 COM1 RO2B P123...

  • Page 23: Printer Circuit

    5-6. PRINTER CIRCUIT The printer circuit is as follows: Printing data is clocked serial from the I/O controller. Printings on signal are P40, P41, P124, P125, P126 and P127. Temperature sensor of printer head is connected to P11 and P12. Motor control ICs are as IC26 and IC33.

  • Page 24: Buzzer Circuit

    5-7. BUZZER CIRCUIT The BUZZER circuit is as follows: Buzzer signal is P100 from I/O controller. IC23 PKM22EPT-2001-B R182 P100 DTC114YUA UPD784215AGC2418EU 5-8. DRAWER CIRCUIT The DRAWER circuit is as follows: Drawer signal is P130 from I/O controller. R185 IC23 ERG-1SJ751P RD4.7UJN1 R186...

  • Page 25: Dc/Dc Converter Circuit

    5-10. DC/DC CONVERTER CIRCUIT — 23 —...

  • Page 26: Diagnostic Operation

    6. DIAGNOSTIC OPERATION 6-1. To start the diagnostic program 1. Turn the power on. 2. Press the INT switch. 3. The unit now waits for “INIT CODE” input. Press the numbers <99990000> and then press <#2> key. 4. The diagnostic program boots. * Once the unit enters the diagnostic mode, it cannot leave it.
  • Page 27 6-4. DIAG command system [Function] The status of the device which has the status information is displayed by 7 segments as well as lit/unlit transaction. [Operation] While the register waits for command input, it displays the current condition when CL key is pressed or when the below status condition is changed.
  • Page 28 6-5. Check item The following test can be checked in the diagnostic test. Device to be checked Operation Note Page Batch test Test Device : RAM, Printer, Date, Time, Buzzer, Drawer RAM WRITE/READ test bn011 RAM READ ONLY test bn111 FISCAL ROM WRITE test FISCAL ROM READ test n114...
  • Page 29 6-6. Operation of each test [ 1 ] Batch test [Function] RAM test, test print, time setting, buzzer test and drawer open test are performed continuously. [Operation] Refer to the page for the details of the following tests. ΜΕΡΙΚΟ ΣΥΝΟΛΟ Operation : The following tests are performed automatically.
  • Page 30 * In case the test ends abnormally, the following is printed. When an error occurs during the check of BANK3 of option RAM2, address 0x60400 OPT2WR NG BANK3-60400 * Refer to the following list for the details of printings when the above error occurs. Printing STD WR NG BANK0.***** NG from the address ***** of BANK0 to 1Kbyte of a standard RAM...
  • Page 31 [ 4 ] FISCAL ROM WRITE test [Function] Write test for Fiscal Rom is performed. This test writes into the test area of the Fiscal Rom and can be done up to 16 times. [Operation] ΜΕΡΙΚΟ ΣΥΝΟΛΟ Operation : [7 segment display] Counter in progress A counter is displayed in the 7 segments to indicate that Fiscal Rom test is in progress as well as the number of times left in which the test can be done.
  • Page 32 [ 6 ] FISCAL ROM BLANK CHECK test [Function] Fiscal Rom BLANK CHECK is performed. This test checks whether the data area of the Fiscal Rom is all blank (cleared). [Operation] ΜΕΡΙΚΟ ΣΥΝΟΛΟ Operation : [7 segment display] Counter in progress A counter is displayed in the 7 segments to indicate that the Fiscal Rom BLANK CHECK is in progress.
  • Page 33 [ 10 ] FISCAL ROM DATA DUMP test [Function] Data in all areas of the Fiscal Rom is dumped. By inputting an address, the start address (0x00000 – 0x3FFF0) from which data is dumped can be desig- nated. [Operation] The operation of this function has two steps. First, enter the data dump function by inputting a command. ΜΕΡΙΚΟ...
  • Page 34 [ 11 ] Display test [Function] The test of 7 segment/14 segment display and transaction display is performed as shown below. Command input Pattern 1 Pattern 2 Press Any key Press Any key [Operation] ΜΕΡΙΚΟ ΣΥΝΟΛΟ Operation : [7 segment display] There are two displayed patterns as shown below.
  • Page 35 [ 13 ] Internal printer graphic pattern print test [Function] This test will check the graphic patterns in the receipt/journal of the internal printer. [Operation] ΜΕΡΙΚΟ ΣΥΝΟΛΟ Operation : P1 P1 P1 P2 P2 P2 P1: 0 = Graphic patter 1 (change 8 bit into a decimal number and input it) P2: 0 = Graphic patter 2 (change 8 bit into a decimal number and input it) 0 = One time check (can be omitted) not 0 = Continuous check (To stop the test, press “C”...
  • Page 36 [ 14 ] Internal printer dot rate test [Function] This test will check the printing of the receipt/journal according to the following specifications. The printing specification is reflected in 1/2 line and the only specified number of dot lines are printed in all dots from the 1 dot line.
  • Page 37 [ 15 ] Internal printer print density test [Function] This will set the print density of the internal printer. This setting is kept until the power is off. The setting will return to the default once the power is turned off. [Operation] ΜΕΡΙΚΟ...
  • Page 38 [ 17 ] RS232C PORT batch test [Function] This is the RS232C port batch test. Perform the loop back test for RS232C port is by making the connection shown in the figure. Perform the loop back test between COM1-COM2 one time by the below setting. When performing this test, fix loop back connectors to all COM ports.
  • Page 39 [ 18 ] Time setting [ 19 ] Time display [Function] This sets the time and date. When setting the time, the time and date will be displayed without inputting the fixed value. [Operation] * Date and time setting ΜΕΡΙΚΟ ΣΥΝΟΛΟ Operation : x1 x2 x3 x4 x5 x6 a: 0:time setting x1/x2: time, x3/x4: minutes, x5/x6: second 1: time setting x1/x2: year, x3/x4: month, x5/x6: day...
  • Page 40 [ 20 ] Drawer open test [Function] This test checks whether the drawer opens or not. [Operation] ΜΕΡΙΚΟ ΣΥΝΟΛΟ Operation : n: 0 = One time check not 0 = Continuous check (To stop the test, press “C” key) [Details] The drawer sensor checks every two seconds while the drawer open test is performed infinite times.
  • Page 41 [ 22 ] Temperature rise test [Function] This test measures the temperature rise after the below sequence of operation. Connect the main, cus- tomer displays, scanner and drawer when performing this test. A sequence of following operation is included in one test and is repeated 15 times in a minute; displaying the main/customer displays printing two lines in the journal printing receipt graphic (logo)
  • Page 42 [ 24 ] KEY dipsplay test [Function] The hard key code of a key is displayed every time any key except C key is pressed. The hard key code is arranged as follows. [Operation] ΜΕΡΙΚΟ ΣΥΝΟΛΟ Operation : To stop the test, press “C” key [7 segment display] The hard key code below is printed in the last three digits.

  • Page 43: Error Code List

    7. ERROR CODE 7-1. ERROR CODE LIST This section describes what to do when you have problems with operation. When an error occurs Errors are indicated by an error codes. When this happens, you can usually find out what the problem is as illustrated below.
  • Page 44 Error code Meaning Action E036 Contents of the drawer exceed programmed limit. Perform pick up operation. E037 High amount lock out/low digit lock out error. Enter correct amount. Subtotal amount exceeds 8 digits. Void/return items until the subtotal amount is less than 9 digits. E038 Read/reset operation without declaring cash in drawer.
  • Page 45 Error code Meaning Action E138 Price input compulsory Input price and press <PRICE>. E139 Attempt to register <–> or <CPN> when the balance Enter proper minus/coupon amount. becomes negative. E146 Arrangement file is full. Set the arrangement properly. E180 No receipt message is set. Set logo or commercial message.

  • Page 46: Error Code

    Machine lock printing Machine Lock Code Fiscal ROM unconnected Time and date when the machine locked (always internal actual time) Issued non-reset receipt Error Details The machine is locked after printing up to this point. 7-3. Fatal Error (FErr) List (1) What is a FErr (Fatal Error)? This is an error caused by the runaway of the software.

  • Page 47: Ic Data

    8. IC DATA MAIN PCB (E466-1 PCB) 1. BA10393F (IC28, 29, 35) OUT 1 OUT 2 - IN1 1 CH + IN1 2 CH - IN1 - IN 2 + IN1 + IN 2 2. LB1936V (IC26, 33) 10 F 10 F P-GND Stepping...
  • Page 48 4. MAX3243CPWR (IC13, 15) +3.3V 0.1µF V CC 0.1µF 0.1µF MAX3243 0.1µF 0.1µF T1IN T1OUT 9 R1IN RS-232 LOGIC T2IN T2OUT 10 OUTPUTS INPUTS R2IN T3IN T3OUT 11 MAX3243 R3IN FORCEON R2OUTB R1OUT R1IN 4 R4IN FORCEOFF R5IN INVALID R2OUT R2IN T1OUT R2OUTB...
  • Page 49 7. SN74LV08APW (IC1, 11, 25, 27, 34) FUNCTION TABLE (each gate) INPUTS OUTPUT 8. SN74LV11APW (IC8) FUNCTION TABLE (each gate) INPUTS OUTPUT 9. SN74LV32APW (IC2) FUNCTION TABLE (each gate) INPUTS OUTPUT — 47 —...

  • Page 50: Function Table

    10. SN74LV139APW (IC5) FUNCTION TABLE INPUTS OUTPUTS OUTPUTS SELECT 11. SN74LV244APW (IC31) FUNCTION TABLE (each buffer) INPUTS OUTPUT OUTPUT — 48 —...
  • Page 51 12. SN74LV245APW (IC21) FUNCTION TABLE To Seven Other Channels INPUTS OPERA OPERATION B data to A bus A data to B bus Isolation 13. SN74LV367APW (IC24, 30) FUNCTION TABLE V CC (each buffer/driver) INPUTS OUTPUT To Three Other Channels To One Other Channel —...

  • Page 52: External Dimensions

    14. SN74LVC1G04DCK (IC9, 22) FUNCTION TABLE INPUT OUTPUT 15. SN74LVC1G32DCK (IC12) FUNCTION TABLE INPUTS OUTPUT OUTPUT 16. TF821S (IC36) External Dimensions Features Repetitive peak off-state voltage: V =200, 400, 600V Average on-state current: I (AV)=8A Gate trigger current: I =15mA max Isolation voltage: V =1500V(50Hz Sine wave, RMS) UL approved type available...
  • Page 53 17. XC9502B092AR (IC36) 1 EXT1 EXT2 10 PWM/PFM PWM/PFM EXT2/ EXT1 Controller2 Controller2 2 VDD GND 9 Comparator1 Comparator2 3 FB1 FB2 8 4 PW M1 PW M2 7 Error Amp1 Ramp Wave Ramp Wave Error Amp2 Generator2 Generator1 PWM2 PWM1 5 EN1 EN2 6...
  • Page 54 MAIN DISPLAY PCB (E273GRE-E2-1 PCB) 18. SN74LV374APW (IC1, 4, 5, 8, 9, 10, 12) FUNCTION TABLE V CC (each flip-flop) INPUTS OUTPUT ↑ ↑ To Seven Other Channels 19. TD62003AFG (IC2, 3, 6, 7, 11, 13, 14) COMMON — 52 —...
  • Page 55 FISCAL ROM PCB (E273-ROM PCB) 20. M27C2001-10F1 (IC1) V CC V PP V PP V CC A0-A17 Q0-Q7 M27C2001 M27C2001 V SS A0 - A17 Address Input Q0 - Q7 Data Output Chip Enable Output Enable V SS Program Program Power Power Supply Voltage Ground —...

  • Page 56: Pcb Layout

    9. PCB LAYOUT (Front side) — 54 —...
  • Page 57 (Back side) — 55 —...

  • Page 58: Circuit Diagrams

    10. CIRCUIT DIAGRAM MODEL : FE-5000G (EX-273-GRE) CONTENTS 1. MAIN PCB CIRCUIT ........................ 57 1-1. MAIN PCB CIRCUIT (1/3) ....................57 1-2. MAIN PCB CIRCUIT (2/3) ....................58 1-3. MAIN PCB CIRCUIT (3/3) ....................59 2. MAIN DISPLAY ........................60 3.
  • Page 59 0.1u AVref4V MNA145A470KK MNA145A470KK CONLED R115 HA17431VLP R127 1.5KF IC11 IC12 R124 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u R116 2.49KF 100p 100p Model Board No Name Drawing No. FE-5000G E273GRE-1 MAIN CIRCUIT (1/3) CASIO COMPUTER CO.,LTD. — 57 —...
  • Page 60 RD4.7UJN1 R235 2.7K Vss2 B2B-ZR C104 0.1u BA10393F TEST C105 0.1u DTC114YUA UPD784215AGC2418EU R236 4.7K 2SD1626-TD CNWIN1 FBMH3216HM501NT R238 1SR154-400TE25 R237 ERG-1SJ390P B2B-PH-K-S Model Board No Name Drawing No. FE-5000G E273GRE-1 MAIN CIRCUIT (2/3) CASIO COMPUTER CO.,LTD. — 58 —...
  • Page 61 C117 C118 EXT1 EXT2 56pF 56pF 47uF/25V 100uF/25V 274KF U2GWJ44 R253 PWM1 PWM2 R254 R255 FVCCON DTC114YUA 21KF 42.2KF R256 XC9502 FVPPON DTC114YUA Model Board No Name Drawing No. FE-5000G E273GRE-1 MAIN CIRCUIT (3/3) CASIO COMPUTER CO.,LTD. — 59 —...
  • Page 62 RA21 MNR34J5ABJ121 Max.40mA Max.40mA Max.40mA 74LV374A 0.1u Max.40mA Max.40mA Max.40mA RA22 MNR34J5ABJ121 TD62003AFG IC14 Max.40mA MNA145A101KK Max.40mA 52807-1210 Max.40mA 120 1/8W Max.40mA Max.40mA TD62003AFG Model Board No Name Drawing No. FE-5000G E273GRE-E2-1 MAIN DISPLAY CASIO COMPUTER CO.,LTD. — 60 —...
  • Page 63 S1DP 52807-1310 DSP1 DSP2 DSP3 DSP4 DSP5 HDSP521G HDSP521G HDSP521G HDSP521G HDSP521G 52807-1210 Model Board No Name Drawing No. FE-5000G E273GRE-E2-2 POP_UP DISPLAY CASIO COMPUTER CO.,LTD. — 61 —...
  • Page 64 GND1 GND2 MNR15E0RPJ563 GND3 MNR18E0APJ101 GNDC GND4 GND5 VppC 0.1uF 0.1uF GND6 GND7 40FLZT-SM1-TF M27C1001-10F1 Model Board No Name Drawing No. FE-5000G E273GRE-ROM ROM BOARD CASIO COMPUTER CO.,LTD. — 62 —...

  • Page 65: Parts List

    2. As for spare parts order and supply, refer to the “GUIDEBOOK for Spare Parts Supply”, published separately. 3. The numbers in item column corespond to the same numbers in drawing. 4. CASIO does not supply the spare parts without parts code. 5. Remarks Q'ty :...

  • Page 66: Explode View

    — 64 —...
  • Page 67 22 ~ 33 22 ~ 33 — 65 —...

  • Page 68: Main Pcb Block

    Price Qt'y Rank Item Code No. Parts Name Specification Code 1. MAIN PCB BLOCK 1 1014 5147 PCB ASSY/E273GRE-1 RJE500933*001V01 1012 0082 LSI UPD784215AGC8038EU N IC23 1014 6170 LSI UPD784215AGC2418EU IC17 1012 9718 LSI M5M5408BFP-70H N IC16 1014 6549 IC M27C160-100F1 IC26,33 1008 9452 IC...
  • Page 69 Qt'y Price Rank Item Code No. Parts Name Specification Code R117 RESISTOR/CHIP MCR03EZHJ201 R239,245 RESISTOR/CHIP MCR10EZHJ301 R118-123,125,126 RESISTOR/CHIP MCR03EZHJ331 R78,80,141,142,147,182, RESISTOR/CHIP MCR03EZHJ102 186,208,210,242,244 R149,164-167 RESISTOR/CHIP MCR03EZHJ222 R12,130,146,150,180,195, RESISTOR/CHIP MCR03EZHJ472 212,227,228,231,236,243, R2,4-6,9,14,15,26,33,34,37, RESISTOR/CHIP MCR03EZHJ103 38,40,42,44,46,48,50,51,53, 55,59,62,65,73,74,87,89, 97-105,131-134,143-145, 148,168,169,175,177,183, 184,189,193,196,209,211, 219,220,238,248-250,253, 256,258-280,295-322 R172,173 RESISTOR/CHIP MCR03EZHJ153...

  • Page 70: Main Display Pcb Block

    Qt'y Price Rank Item Code No. Parts Name Specification Code C7,65,90,100,107 CAPACITOR/CHIP RV2-16V101MS-R C106 CAPACITOR/CHIP UUR1H101MNR1GS CNBAT1 3500 7122 CONNECTOR 53253-0310 CNLED1 3540 4836 CONNECTOR 52045-2345 CNKEY1 3501 5460 CONNECTOR 52045-2845 CNPR1,2 1007 2590 CONNECTOR 52806-3010 CNWIN1 3501 6244 CONNECTOR B2B-PH-K-S CNPOW1 3580 2371 CONNECTOR...

  • Page 71: Button Block

    Qt'y Price Rank Item Code No. Parts Name Specification Code 4. BUTTON BLOCK 9 1007 2604 FLAME/KB E272 E140462-1 10 1014 6216 FPC/E273GRE RJE500856-001V01 11 1007 2606 SPACER/E272 E341247-1 12 1007 2607 SHEET/COMMON E272 E341246-1 13 1007 2608 CHASSIS/KB E272 E341248-1 14 1007 2609 KEYTOP/S E272 E341250-1...

  • Page 72: Upper Case Block

    Qt'y Price Rank Item Code No. Parts Name Specification Code PLATE/S2-23 RJE500866-023 PLATE/S2-24 RJE500866-024 PLATE/S2-25 RJE500866-025 PLATE/S2-26 RJE500866-026 PLATE/S2-27 RJE500866-027 PLATE/S2-28 RJE500866-028 PLATE/S2-29 RJE500866-029 PLATE/S2-30 RJE500866-030 PLATE/S2-31 RJE500866-031 PLATE/S2-32 RJE500866-032 PLATE/S2-33 RJE500866-033 PLATE/S2-34 RJE500866-034 PLATE/S2-35 RJE500866-035 PLATE/S2-87 E240848-87 PLATE/S2-89 E240848-89 PLATE/L2-1 RJE500867-001 PLATE/L2-2...

  • Page 73: Power Supply Block

    Qt'y Price Rank Item Code No. Parts Name Specification Code 64 1007 8847 SHAFT/HINGE E441281-1 65 5430 0208 E-RING 3 NI 66 1007 2642 COVER/RIGHT E140472-1 67 1007 8723 CASE/LOWER E140475-1 68 1007 8724 COVER/LIFT E140474-1 69 1007 8848 PLATE/JOURNAL E441282-1 SCREW 3X6 ZMC-3...

  • Page 74: Drawer (Dl-2776)

    12. DRAWER DL-2776 (M type) 22 27 — 72 —...
  • Page 75 DRAWER DL-2776 (M type) I t e m Code No. Parts Name Specification Q t ' y P r i c e R a n k c o d e 1. MAIN CASE BLOCK 1007 8897 CASE/MAIN E140494-1 5500 0619 ROLLER/DELRIN DR-19B1 1007 9066...
  • Page 76 CASIO TECHNO CO.,LTD. Overseas Service Division 6-2, Hon-machi 1-Chome Shibuya-ku, Tokyo 151-8543, Japan...
