- Page 1 NAVLINK BLUE NMEA2000 SERVER Version 1.00...
-
Page 2: Before You Start
1. Introduction Congratulations on the purchase of your NAVLink Blue Wireless NMEA 2000 Server. This product uses low energy wireless technology to send NMEA 2000 data to compatible products. It is recommended that your product is installed by a professional installer, particularly when it comes to interfacing with other equipment. - Page 3 • If you are creating a new NMEA2000 network, then you may wish to consider Digital Yacht’s NMEA2000 Starter Kit, that provides all of the cables, connectors and terminators required for a basic NMEA2000 network. •...
- Page 4 3.3 – Powering NAVLink Blue • Apply power to the NMEA 2000 network and the NAVLink Blue the LEDs should start to illuminate or flash, as per Table 1… STATUS DATA IN ERROR DATA OUT LINK Condition (Green) (Yellow) (Red) (Yellow) (Green) Wi-Fi...
- Page 5 • Any device, connected to NAVLink Blue, can access its web interface by typing http://192.168.1.1 http://NAVLinkBlue.local into its browser’s address bar. • This will display the Home page shown in Figure 1, from which you can go to the NMEA 2000 Devices and PGNs pages and Settings page. Figure 1 3.5 –...
- Page 6 • If the device is outputting wrong/bad data or duplicated data, then you can instruct the NAVLink Blue to black list the device by clicking on the switch in the top left corner. Figure 2 Figure 3...
- Page 7 • To query the Product or Configuration Info of an NMEA 2000 Device, click on its “Eye” icon – to the right of the Green Heart icon. A pop-up window will appear showing the Product Info (Fig 4) or if you click the Config Info tab, the Configuration Info (Fig 5) Figure 4 Figure 5...
- Page 8 3.6 – NMEA 2000 PGNs Page • If you wish to dig even deeper in to the NMEA 2000 data on the network, from the web interface Home Page, click on the PGNs page and a list of PGNs being received will be displayed – see Fig 6. Figure 6 •...
- Page 9 Figure 7 3.7 – SETTINGS Page • To access the NAVLink Blue settings click on the SETTINGS button on the Home page and the page show in Fig 8 will appear. Figure 8...
- Page 10 • If you are using NAVLink Blue to send Bluetooth data to an App like NMEA Remote, then the default settings will in most cases be fine. However, there are some configuration settings that may be required for other applications. •...
- Page 11 Figure 10 • Also on the Settings page you can check what firmware version the NAVLink Blue has and update the firmware if required. Figure 11...
