- Page 1 VADI Respiratory Humidifier VH-1500 User Manual Made In Taiwan Issued Date: 2024.10.01 VA-1-VH-1500-EN.MDD_01...
-
Page 2: Table Of Contents
Table of Content Manufacture Information ..........................1 Intended Use ..............................2 Product Introduction ............................ 3 Introduction of Display Icons and Indicators ..................3 Installation ..............................5 Product Operation ............................6 Alarm System ..............................7 Troubleshooting ............................8 Cleaning and Service ........................... 8 Recycling and Waste Disposition ...................... -
Page 3: Manufacture Information
Manufacture Information VADI Medical Technology Co. Ltd. Yangmei Address: No. 198, Lane 298, Huandong Road, Zhongshan Village, Yangmei District, Taoyuan City 32665, Taiwan TEL: +886-3-475-9911 E-mail: sales@vadimedical.com.tw FAX: +886-3-475-9922 Website: www.vadimedical.com.tw MedNet EC-REP IIb GmbH Borkstrasse 10, 48163 Münster, Germany... -
Page 4: Intended Use
Intended Use VADI Respiratory Humidifier is intended to provide heat and humidity to respiratory gases delivered to patients. It is for use in a hospital or long-term care facility by a health professional. Indication For Use VADI Respiratory Humidifier is intended to provide heat and humidity to respiratory gases delivered to patient. -
Page 5: Product Introduction
Product Introduction VH-1500 USER MANUAL Respiratory Humidifier User Manual Introduction of Display Icons and Indicators Power Switch ① Heated Plate Level ② Display of Heated Plate Level ③ ③ Enhance Heated plate level / Mute Button ④ ① ④ Lessen heated plate level / Mute Button ⑤... - Page 6 Power Switch This button is used to power ON or OFF the device. Pressing this button for 1 second, you may turn on or turn off the device. Heated Plate Level The heated plate has 9 levels, each corresponding to a different temperature. Display of Heated Plate Level Screen displays level of heated plate.
-
Page 7: Installation
Installation When installing a Respiratory Humidifier close to a patient, the Respiratory Humidifier is always securely mounted and positioned lower than the patient. To avoid the risk of electric shock, this equipment must only be connected to electrical power with protective earth. The AC electrical power plug is served to easily connect and ... -
Page 8: Product Operation
VADI authorized distributor. Do not touch heated plate while the device is in use. ... -
Page 9: Alarm System
Alarm System VADI Respiratory Humidifier alarms are medium priority, alarm settings comply with ISO 3744. Indicator Buzzer Symbols Color Frequency Duty Frequency Sound Pressure Yellow 0.5 Hz 796 Hz > 45 dB(A)@1 Meter If multiple alarms occur at the same time, the humidifier will display the highest priority alarm(medium priority alarm Sensor Error is first priority). -
Page 10: Troubleshooting
Troubleshooting When alarm message and indicator lights up, please flow troubleshooting corrective action. Message Display Possible Cause Corrective Action Sensor Please replace it with a new Heated plate sensor Error humidifier disconnected or abnormal. High Turn off the device, unplug the Heated plate temperature Temperature exceed 85℃, this device will... - Page 11 Cleaning Please clean the device before and after each use. Please use a damp cloth with 75% ethyl alcohol to clean the device exterior appearance and power cord. Service Equipment maintenance and service are restricted to qualified personnel only. DO NOT attempt to dismantle and repair malfunction device, ...
- Page 12 After turning on the device, random press panel button to confirm message display and keypad tone function normally; if device’ panel unable display message or speaker malfunction, please replace it with a new humidifier and contact VADI authorized distributor.
-
Page 13: Recycling And Waste Disposition
EEA States for the collection, treatment and recycling of waste electronic products. VADI products that are marked with the crossed-out wheeled bin WEEE symbol should not be disposed as unsorted municipal waste. The marked equipment should be collected separately and returned to the designated recycling service (please refer to European (Union) Country Recycling Services). -
Page 14: Specification
Specification 175mm × 135mm × 140mm Dimension (D×W×H) 1.1 kg Weight 100-120 Vac or 200-240 Vac Input Voltage 50/60 Hz Frequency 180 W Max. Power 150 W Power of Heated Plate Class I Electrical Classification Category 1 Humidifier Classification IPX1 Protection Against Ingress of Water Degree of Protection Against Electric Shock Type BF applied part... - Page 15 Humidity Output Absolute Humidity is 33 mg/L, limited to level 7-9. 5-40 L/min Flow Rate Range < 30 min Warm-up Time > 45 dB(A) Alarm Sound Pressure Level Forced Power Cut-off Method Pull out the plug...
-
Page 16: Symbol Definition
Symbol Definition Refer to instruction manual/ Manufacturer booklet Electricity Warning Date of manufacture Hot surface Use-by date General warning sign Fragile, handle with care TYPE BF Applied Part Keep dry Protection against insertion of Handle with care IPX1 large objects and dripping water. Alarm Keep away from sunlight Power On/Off (Standby) -
Page 17: Emc Information
IEC 61000-3-3 Guidance and Manufacturer’s Declaration – Electromagnetic Immunity The VH-1500 is intended for use in the electromagnetic environment specified below. The customer or the user of the VH-1500 should assure that it is used in such an environment. Electromagnetic... - Page 18 0% residual voltage for 1 cycle Power Supply Input environment. 70% residual voltage for 25/30 cycle Lines IEC 61000-4-11 If the user of the VH-1500 Voltage Interruptions: requires continued 0% residual voltage for 250/300 cycle operation during power @0~360° step 45°...
- Page 19 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the VH-1500 is used exceeds the applicable RF compliance level above, the VH-1500 should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the VH-1500.
